Access & Power Integration
T1RAL3F8
8 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove1R rack enclosure with Altronix backplane (TAL1R)
- (1) eFlow6NB - Power Supply/Charger
- (1) VR6 - Voltage Regulator
- (1) PDS8 - Fused Dual Output Power Distribution Module
- (1) ACMS8 - Fused Dual Output Access Power Controller
T1RAL33F16
16 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove1R rack enclosure with Altronix backplane (TAL1R)
- (2) eFlow6NB - Power Supply/Chargers
- (2) ACMS8 - Fused Dual Output Access Power Controllers
All components of these Trove kits are UL Listed sub-assemblies.
Please refer to the included corresponding
Sub-Assembly Installation Guides for further information.
Installation Guide
All registered trademarks are property of their respective owners.
Rev. T1RAL111518
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
More than just power.
TM
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Altronix T1RAL3F8
Summary of Contents for Altronix T1RAL3F8
- Page 1 T1RAL3F8 8 Door Kit with Fused Outputs Fully assembled kit includes: - Trove1R rack enclosure with Altronix backplane (TAL1R) - (1) eFlow6NB - Power Supply/Charger - (1) VR6 - Voltage Regulator - (1) PDS8 - Fused Dual Output Power Distribution Module...
-
Page 2: Configuration Chart
Overview: Altronix Trove Rack kits are pre-assembled and consist of Trove1AL1R enclosure/backplane with factory installed Altronix power supply/charger(s) and sub-assemblies. Configuration Chart: Nominal DC Maximum Supply Output Voltage Power Power Current for Main [DC] [Aux] 120VAC Supply Supply and Aux. Outputs on... - Page 3 1. Remove backplane from enclosure prior to installing into rack cabinet (do not discard hardware). 2. In order to mount included UL Listed tamper switch (Altronix Model TS112 or equivalent) turn the enclosure upside down. Punch out the knockout in designated location, on the back of the unit, from outside of the drawer (Fig.
- Page 4 Assembling and Attaching Z Bracket Wire Management Accessory (included): Altronix Trove Rack enclosures include Z Bracket, a convenient and reliable wire management accessory. Hardware (included): Fig. 3 Ten (10) bolts and eight (8) lock nuts. 1. Carefully unpack Z Bracket. Do not discard hardware (included) (Fig.
- Page 5 T1RAL3F8 Configuration: Fig. 5 To IEC connector Altronix eFlow6NB 24VDC Altronix VR6/PDS8 COM-- GND GND Altronix ACMS8 To LED lense Trove1RAL Series Installation Guide - 5 -...
- Page 6 T1RAL33F16 Configuration: Fig. 6 To IEC connector Altronix eFlow6NB 24VDC COM-- GND GND Altronix ACMS8 Altronix eFlow6NB 12VDC COM-- GND GND Altronix ACMS8 To LED lenses - 6 - Trove1RAL Series Installation Guide...
- Page 7 Notes: Trove1RAL Series Installation Guide - 7 -...
- Page 8 26.5” 673.1mm 19” (482.6mm) 3.375” 85.8mm Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty MEMBER IITrove1RAL Series...
