Access & Power Integration
T1RV3F4
Fully assembled kit includes:
- Trove1R rack enclosure with Altronix/HID VertX
- (1) eFlow6NB - Power Supply/Charger
- (1) VR6 - Voltage Regulator
- (1) PDS8 - Fused Dual Output Power Distribution Module
- (1) ACM4 - Fused Access Power Controller
Installation Guide
All registered trademarks are property of their respective owners.
Rev. T1RV3F4111918
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
®
backplane (TV1R)
More than just power.
TM
Advertisement
Table of Contents
Related Manuals for Altronix Trove T1RV3F4
Summary of Contents for Altronix Trove T1RV3F4
- Page 1 Access & Power Integration T1RV3F4 Fully assembled kit includes: ® - Trove1R rack enclosure with Altronix/HID VertX backplane (TV1R) - (1) eFlow6NB - Power Supply/Charger - (1) VR6 - Voltage Regulator - (1) PDS8 - Fused Dual Output Power Distribution Module...
- Page 2 Overview: Altronix T1RV3F4 rack kit is pre-assembled and consist of Trove1V1R enclosure/backplane with factory installed Altronix power supply/charger and sub-assemblies. This kit also accommodates various combinations of ® HID VertX boards for up to six (6) doors in a single enclosure.
- Page 3 1. Remove backplane from enclosure prior to installing into rack cabinet (do not discard hardware). 2. In order to mount included UL Listed tamper switch (Altronix Model TS112 or equivalent) turn the enclosure upside down. Punch out the knockout in designated location, on the back of the unit, from outside of the drawer (Fig.
- Page 4 Assembling and Attaching Z Bracket Wire Management Accessory (included): Altronix Trove Rack enclosures include Z Bracket, a convenient and reliable wire management accessory. Hardware (included): Fig. 3 Ten (10) bolts and eight (8) lock nuts. 1. Carefully unpack Z Bracket. Do not discard hardware (included) (Fig.
- Page 5 Access Controller Position Chart for the Following Models: ® HID VertX Board Pem Mounting V100, V200, V300, V1000, V2000 Fig. 5 To IEC connector Altronix eFlow6NB PWR1+ PWR1+ Altronix PDS8/VR6 Fig. 5a COM(-) Pan Head Screw OUT1 OUT2 OUT3 OUT4 OUT5 OUT6 OUT7 OUT8...
- Page 6 Notes: - 6 - T1RV3F4 Installation Guide...
- Page 7 Notes: T1RV3F4 Installation Guide - 7 -...
- Page 8 116.1mm 26.5” 673.1mm 19” (482.6mm) 3.375” 85.8mm Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty MEMBER IIT1RV3F4...
