Pole Mount Kits
Installation Guide
Models Include:
PMK1
- Accommodates Altronix WP1, WP3, and WP4 outdoor rated enclosures.
- 1.96" x 12" x 2.25" (49.8mm x 304.8mm x 57.2mm)
PMK2
- Accommodates Altronix WP2 outdoor rated enclosure.
- 1.96" x 14" x 2.25" (49.8mm x 355.6mm x 57.2mm)
Rev. 062718
More than just power.
TM
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Altronix PMK1
Summary of Contents for Altronix PMK1
-
Page 1: Installation Guide
Pole Mount Kits Installation Guide Models Include: PMK1 - Accommodates Altronix WP1, WP3, and WP4 outdoor rated enclosures. - 1.96” x 12” x 2.25” (49.8mm x 304.8mm x 57.2mm) PMK2 - Accommodates Altronix WP2 outdoor rated enclosure. - 1.96” x 14” x 2.25” (49.8mm x 355.6mm x 57.2mm) More than just power. -
Page 2: Specifications
Altronix PMK1 and PMK2 outdoor pole mount kits are designed to simplify the installation of Altronix outdoor rated power supplies and accessories housed in models WP1, WP2, WP3 and WP4 NEMA rated enclosures. PMK1 and PMK2 can be mounted on 2” to 8” (50.8mm to 203.2mm) diameter round or 5” (127mm) square poles. Specifications: Metal Bracket Dimensions (approx.):... - Page 3 3. Attach the bottom bracket to the enclosure by inserting bolts through the flange of the enclosure and into the bracket, tightening bolts with a 7/16” hex socket (Fig. 3, pg. 3). 4. Thread the second wormgear quick release strap through the slots on the back of the bottom mounting bracket (Fig.
- Page 4 4.5” (114.3mm) 3.9” (99.1mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Made in U.S.A. MEMBER IIPMK F27R - 4 -...
