R615DC220 Series
Rack Mount DC CCTV Power Supplies
Installation Guide
Models Include:
R615DC416220
- 6-15VDC @ 4A.
- Sixteen (16) Fuse Protected Outputs.
R615DC616220
- 6-15VDC @ 6A.
- Sixteen (16) Fuse Protected Outputs.
R615DC1016220
- 6-15VDC @ 10A.
- Sixteen (16) Fuse Protected Outputs.
Rev. 120403
R615DC416CB220
- 6-15VDC @ 4A.
- Sixteen (16) PTC Protected Outputs.
R615DC616CB220
- 6-15VDC @ 6A.
- Sixteen (16) PTC Protected Outputs.
R615DC1016CB220
- 6-15VDC @ 10A.
- Sixteen (16) PTC Protected Outputs.
More than just power.
TM
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Altronix R615DC220 Series
Summary of Contents for Altronix R615DC220 Series
- Page 1 R615DC220 Series Rack Mount DC CCTV Power Supplies Installation Guide Models Include: R615DC416220 R615DC416CB220 - 6-15VDC @ 4A. - 6-15VDC @ 4A. - Sixteen (16) Fuse Protected Outputs. - Sixteen (16) PTC Protected Outputs. R615DC616220 R615DC616CB220 - 6-15VDC @ 6A.
- Page 2 Overview: Altronix R615DC220 Series Rack Mount CCTV Power Supplies provide 6-15VDC distributed via sixteen (16) fuse or PTC protected outputs for powering CCTV cameras, heaters, and other video accessories. Sixteen (16) Output Rack Mount Configuration Reference Chart: Total Output 220VAC...
- Page 3 (servicing) instructions in the literature accompanying the appliance. CAUTION: To reduce the risk of electric shock do not open enclosure. There are no user serviceable parts inside. Refer servicing to qualified service personnel. R615DC220 Series - 3 -...
- Page 4 0.75" 19mm Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IIR615DC220 Series E22R...
