Access & Power Integration
Altronix/Honeywell Rack Kits
Models Include:
T1RHW3F4
4 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove1R rack enclosure with
THW1R Altronix/Honeywell backplane
- (1) eFlow6NB - Power Supply/Charger
- (1) VR6 - Voltage Regulator
- (1) PDS8 - Fused Dual Output
Power Distribution Module
- (1) ACM4 - Fused Access Power Controller
All components of these Trove kits are UL Listed sub-assemblies.
Please refer to the included corresponding Sub-Assembly Installation Guides for further information.
Installation Guide
Rev. T1RHW3F4_032019
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
T1RHW3F4D
4 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove1R rack enclosure with
THW1R Altronix/Honeywell backplane
- (1) eFlow6NB - Power Supply/Charger
- (1) VR6 - Voltage Regulator
- (1) PDS8CB - PTC Dual Output
Power Distribution Module
- (1) ACM4CB - PTC Access Power Controller
More than just power.
TM
Advertisement
Related Manuals for Altronix TROVE T1RHW3F4
Summary of Contents for Altronix TROVE T1RHW3F4
- Page 1 Access & Power Integration Altronix/Honeywell Rack Kits Models Include: T1RHW3F4 T1RHW3F4D 4 Door Kit with Fused Outputs 4 Door Kit with PTC Outputs Fully assembled kit includes: Fully assembled kit includes: - Trove1R rack enclosure with - Trove1R rack enclosure with...
-
Page 2: Configuration Chart
Overview: Altronix T1RHW3F4 and T1RHW3F4D rack kits are pre-assembled and consists of Trove1HW1R enclosure/ backplane with factory installed Altronix power supply/charger and sub-assemblies. These kits also accommodate various combinations of Honeywell boards for up to four (4) doors in a single enclosure. - Page 3 1. Remove backplane from enclosure prior to installing into rack cabinet (do not discard hardware). 2. In order to mount included UL Listed tamper switch (Altronix Model TS112 or equivalent) turn the enclosure upside down. Punch out the knockout in designated location, on the back of the unit, from outside of the drawer (Fig.
- Page 4 Assembling and Attaching Z Bracket Wire Management Accessory (included): Altronix Trove Rack enclosures include Z Bracket, a convenient and reliable wire management accessory. Hardware (included): Fig. 3 Ten (10) bolts and eight (8) lock nuts. 1. Carefully unpack Z Bracket. Do not discard hardware (included) (Fig.
- Page 5 Access Controller Position Chart for the Following Models: Honeywell Board Pem Mounting PRO32E1PS, PRO32IC, PRO32R2, PRO32IN, PRO32OUT, PW6K2E2PS, PW6K1IC, PW6K1IN, PW6K1OUT, PW6K1R2. Fig. 5 To IEC connector Altronix eFlow6NB PWR1+ PWR1+ Altronix PDS8(CB) OUT1 OUT2 OUT3 OUT4 OUT5 OUT6 OUT7 OUT8 COM(-) Fig. 5a...
- Page 6 Notes: - 6 - T1RHW3F4(D) Installation Guide...
- Page 7 Notes: T1RHW3F4(D) Installation Guide - 7 -...
- Page 8 116.1mm 26.5” 673.1mm 19” (482.6mm) 3.375” 85.8mm Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty IIT1RHW3F4(D) C22X...
