Summary of Contents for Citronic CMB-10
- Page 1 Item ref: 170.890UK CMB-10 Compact Mixer with FX/BT/USB User Manual Version 1.0 Caution: Please read this manual carefully before operating Damage caused by misuse is not covered by the warranty...
-
Page 2: Safety Symbol And Message Conventions
Introduction Thank you for choosing a Citronic CMB-10 mixer as part of your professional sound system. This product has been developed to provide a wide range of facilities for professional and reliable sound reinforcement. Please read and keep this manual to achieve the best results from your purchase and avoid damage through misuse. -
Page 3: Console Layout
Console layout Each CMB-10 compact mixing console has a bank of mono input channels which can accept a balanced microphone input or switchable line/instrument input. There is also a stereo input for playback devices or line level instruments. All preamps have studio grade, low noise architecture for the cleanest possible path throughout the signal chain. -
Page 4: Stereo Inputs
Rotary Volume control for stereo 3.5mm line channel with signal LED. Bluetooth Wireless Receiver & MP3 Player CMB-10 mixers have a Bluetooth receiver and USB mp3 audio player/recorder 19. MP3 VOL Volume control for USB mp3 playback with signal LED 20. -
Page 5: Dsp Effects
REC = Record (recorded tracks are stored on the USB flash drive as numbered files) DSP Effects CMB-10 mixers have an internal 24-bit DSP processor for audio effects, as detailed on the DSP Table in the appendix of this manual. 27. Display The lower part of the LED display shows the DSP preset number &... - Page 6 A mono AUX SEND output (38) may be used to feed outboard audio processors, such as effects machines, or as a separate monitor mix feed and controlled by the AUX SEND volume control (34). CMB-10 Mixer User Manual...
-
Page 7: Operation
There are 99 pre-set types available by rotating and pressing the preset selector (28) including digital reverbs, delays and modulation effects. Each effect has 2 adjustable parameters (29, 30) to enable you to tailor the effect as required. Experimentation is advised to achieve the best results from this section. CMB-10 Mixer User Manual... -
Page 8: Specifications
If a smart phone or tablet is to be connected as a wireless music source, press the BT PAIR button (21) and it will flash blue rapidly. Search on the smart phone or tablet for a device called “Citronic” and select to connect for audio playback. The BT PAIR button (21) will be lit blue constantly when paired successfully. - Page 9 Delay Time Echo 2 100 DlyTime Decay Time Slap Mid None Delay Time Echo 2 400 DlyTime Decay Time Slap Long None Delay Time Echo 3 100 DlyTime Decay Time Echo 3 400 DlyTime Decay Time CMB-10 Mixer User Manual...
