Introduction
This system board is available in different configuration levels. Depending on the
i
hardware configuration of your device, it may be that you can find several options in the
system board, even though they are not described.
Notational conventions
The meanings of the symbols and fonts used in this manual are as follows:
Pay particular attention to texts marked with this symbol. Failure to observe this warning
!
endangers your life, destroys the system, or may lead to loss of data.
This symbol is followed by supplementary information, remarks and tips.
i
Texts which follow this symbol describe activities that must be performed in the order shown.
This symbol means that you must enter a blank space at this point.
This symbol means that you must press the Enter key.
Texts in this typeface are screen outputs.
Texts in this bold typeface are the entries you make via the keyboard.
Texts in italics indicate commands or menu items.
"Quotation marks" indicate names of chapters and terms that are being emphasized.
A26361-D1161-Z120-1-7619
English - 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Fujitsu Siemens Computers D1161
Summary of Contents for Fujitsu Siemens Computers D1161
-
Page 1: Introduction
Texts in this typeface are screen outputs. Texts in this bold typeface are the entries you make via the keyboard. Texts in italics indicate commands or menu items. "Quotation marks" indicate names of chapters and terms that are being emphasized. English - 1 A26361-D1161-Z120-1-7619... -
Page 2: Important Notes
There is a danger of burns! The warranty is invalidated if the device is damaged during the installation or replacement of system expansions. Information on which system expansions you can use is available from your sales office or the customer service. 2 - English A26361-D1161-Z120-1-7619... - Page 3 The equipment and tools you use must be free of static charges. • Pull out the power plug before inserting or pulling out boards containing ESDs. • Always hold boards with ESDs by their edges. • Never touch pins or conductors on boards fitted with ESDs. English - 3 A26361-D1161-Z120-1-7619...
-
Page 4: Features
• AMI Plug and Play flash BIOS. • Deep Green, Energy Star, ACPI, Year 2000, and PC98 compliant. • Soft power-down, multiple boot options. • Win98/NT5 ready, DMI 2.0 compliant. • PCI 2.1, APM 1.1 compliant. 4 - English A26361-D1161-Z120-1-7619... - Page 5 Two serial ports (16550 UARTs). • One ECP/EPP parallel port. • One Serial IR (InfraRed) I/O interface port. • Two USB rev 1.2 (universal serial bus) connectors. • One PS/2 mouse connector. • One PS/2 keyboard connector. English - 5 A26361-D1161-Z120-1-7619...
-
Page 6: Interfaces, Connectors And Jumpers
PCI slot 4 National LM79 PCI slot 5 JP24 ISA slot 2 JP21 Flash BIOS ISA slot 1 The tiny "1" next to jumpers of 3 pins or more indicate the position of pin 1 for that jumper. 6 - English A26361-D1161-Z120-1-7619... -
Page 7: Connectors And Setting Jumpers
Fan2 connector corresponds to CPU 1 slot. − Fan3 connector corresponds to CPU 2 slot. − Fan4 connector corresponds to Front Chassis Fan (Not used). JP15 (Wake-on LAN) Standby 5 V Wake (Power On, Active High) FAN1-4 Fan Monitor English - 7 A26361-D1161-Z120-1-7619... -
Page 8: Clear Cmos And Reset Password (Jumper Jp3)
The system board uses flash memory to store BIOS firmware. It can be easily updated if necessary using the Flash BIOS Update Disk (see chapter "BIOS Configuration"). Siemens does not recommend flashing the BIOS unnecessarily. Check the Siemens web site for the latest BIOS revision. 8 - English A26361-D1161-Z120-1-7619... -
Page 9: Add-On Modules
You must install the universal retention module in the slot for the second processor if you want to upgrade a second processor. Installing the retention module Install the universal retention module. Secure by pressing the four body-bound rivets (1) firmly. English - 9 A26361-D1161-Z120-1-7619... - Page 10 If the processor is equipped with a fan, then disconnect the plug-in connection of the related cable. Press the clamps (2) on either side of the processor slightly outwards and pull the processor up and out. 10 - English A26361-D1161-Z120-1-7619...
-
Page 11: Upgrading Main Memory
Insert the memory module in the slot while folding the side holders up until the memory module engages (2). Removing a memory module Flip the holders to the right and left of the location outwards (1). Pull the memory module out of its location (2). English - 11 A26361-D1161-Z120-1-7619... -
Page 12: Installing Network Board With Wol
Make sure that you insert the battery the right way round. The plus pole must be on the top! Lift the contact (1) a few millimeters and remove the battery from its socket (2). Insert a new lithium battery of the same type in the socket (3). 12 - English A26361-D1161-Z120-1-7619... -
Page 13: Bios Configuration
Drawings have been included for ease of reference. Overall, the AMIBIOS Setup program is easy to use, and fairly intuitive. Note that the graphics in the manual are simpler than those that appear on your screen. English - 13 A26361-D1161-Z120-1-7619... -
Page 14: Main Setup
You can type the date and time in directly, or select the portion of the date or time that you want to modify and adjust it using the cursor keys. The clock runs on a 24-hour cycle (i.e. 1:00 PM is 13:00). [System Date Setting] [System Time Setting] MM/DD/YY: Jan 1 1999 Current Time 12:00:00 14 - English A26361-D1161-Z120-1-7619... -
Page 15: Floppy Drive A: And B
CD-ROM: Use for ATAPI Maximum Capacity CD-ROM drives LBA Mode Double click [AUTO] to Block Mode set all HDD parameters Fast Programmed I/O Modes automatically 32 Bit Transfer Mode ESC:Back Enter:Select -—:Select Items F5:Setup Defaults F6:Original Values English - 15 A26361-D1161-Z120-1-7619... -
Page 16: Ide Device Configuration
504 MB. This can be autodetected (when you select Auto for Type), or you can turn the modes On or Off yourself. Block Mode: If On, Block Mode automatically detects the optimal number of block read/writes per sector that the drive can support. 16 - English A26361-D1161-Z120-1-7619... -
Page 17: Fast Programmed I/O Modes
34 sectors per track. SCSI and IDE drives have even more sectors per track. Size The formatted capacity of the drive is the number of heads times the number of cylinders times the number of sectors per track times 512 (bytes per sector). English - 17 A26361-D1161-Z120-1-7619... -
Page 18: Auto-Detect Hard Disks
Exit Saving Changes Write the current settings to CMOS and exit. Exit Discarding Changes Exit without saving the current settings. Load Optimal Defaults The Optimal default values provide optimum performance settings for all devices and system features. 18 - English A26361-D1161-Z120-1-7619... -
Page 19: Load Fail-Safe Defaults
Change Language Setting English - Previous Item — Next Item -® Select Menu ESC:Exit Enter:Select F5:Setup Defaults F6:Original Values F10:Save & Exit Advanced CMOS Setup Choose Advanced CMOS Setup on the AMIBIOS Setup Advanced menu. English - 19 A26361-D1161-Z120-1-7619... -
Page 20: Advanced Cmos Setup Default Settings Chart
Cached C400, 16K Shadow Cached Cached C800, 16K Shadow Disabled Disabled CC00, 16K Shadow Disabled Disabled D000, 16K Shadow Disabled Disabled D400, 16K Shadow Disabled Disabled D800, 16K Shadow Disabled Disabled DC00, 16K Shadow Disabled Disabled 20 - English A26361-D1161-Z120-1-7619... -
Page 21: Quick Boot
Set this option to Yes to instruct AMIBIOS to attempt to boot from any other drive in the system if it cannot find a boot drive among the drives specified in the 1st Boot Device, 2nd Boot Device, and 3rd Boot Device options. The settings are Yes or No. English - 21 A26361-D1161-Z120-1-7619... -
Page 22: Initial Display Mode
If Setup is chosen, the password prompt appears if AMIBIOS is executed. Boot To OS/2 Set this option to Yes if you are running an OS/2 operating system and using more than 64 MB of system memory on the system board. The settings are Yes or No. 22 - English A26361-D1161-Z120-1-7619... -
Page 23: Internal Cache
The contents of the video ROM area from C000h-C7FFFh are copied (shadowed) from ROM to RAM for faster execution. Cached The contents of the video ROM area from C000h-C7FFFh are copied from ROM to RAM and can be written to or read from cache memory. English - 23 A26361-D1161-Z120-1-7619... -
Page 24: C800, 16K Shadow; Cc00, 16K Shadow; D000, 16K Shadow; D400, 16K Shadow; D800, 16K Shadow; And Dc00, 16K Shadow
Load configuration Plug and Play Setup [Enter] settings giving Peripheral Setup [Enter] highest performance Change Language Setting English - Previous Item — Next Item -® Select Menu ESC:Exit Enter:Select F5:Setup Defaults F6:Original Values F10:Save & Exit 24 - English A26361-D1161-Z120-1-7619... -
Page 25: Advanced Chipset Setup Default Settings Chart
Normal ISA Normal ISA DMA-4 Type Normal ISA Normal ISA DMA-5 Type Normal ISA Normal ISA DMA-6 Type Normal ISA Normal ISA DMA-7 Type Normal ISA Normal ISA CPU Bus Frequency Auto Auto Setting option not selectable English - 25 A26361-D1161-Z120-1-7619... -
Page 26: Usb Function
USWC posted writes to I/O are disabled. BX Master Latency Timer (Clks) This option specifies the master latency timer (in PCI clocks) for devices in the computer. The settings are Disabled, 32, 64, 96, 128, 160, 192, or 224. 26 - English A26361-D1161-Z120-1-7619... -
Page 27: Multi-Trans Timer (Clks)
(CHANGE) This option specifies the length of the RAS precharge part of the DRAM system memory access cycle when SDRAM system memory is installed in this computer. The settings are Auto, 2 SCLKs, or 3 SCLKs. English - 27 A26361-D1161-Z120-1-7619... -
Page 28: Power Down Sdram
Disabled. 8 bit I/O Recovery Time This option specifies the length of a delay inserted between consecutive 8-bit I/O operations. The settings are Disabled and from 1 to 8 Sysclk (system clocks) in increments of one. 28 - English A26361-D1161-Z120-1-7619... -
Page 29: Bit I/O Recovery Time
(Auto) be selected. Unpredictable situations may arise if the Intel default CPU bus speed is not used. The settings are Auto, 66.8 MHz, 68.5 MHz, 75 MHz, 83.3 MHz, 100 MHZ, 103 MHz, or 112 MHz. English - 29 A26361-D1161-Z120-1-7619... -
Page 30: Power Management Setup
Standby / Suspend Timer Unit 4 min 4 min Standby Time Out Disabled Disabled Suspend Time Out Disabled Disabled Slow Clock Ratio 50 % - 62.5 % 50 % - 62.5 % Display Activity Ignore Ignore 30 - English A26361-D1161-Z120-1-7619... -
Page 31: Acpi Aware O/S
This option specifies the power state that the green PC-compliant video monitor enters when AMIBIOS places it in a power saving state after the specified period of display inactivity has expired. The settings are Off, Stand By, or Suspend. English - 31 A26361-D1161-Z120-1-7619... -
Page 32: Video Power Down Mode
This option specifies the speed at which the system clock runs in the Standby Mode power saving state. The settings are expressed as a percentage of the normal CPU clock speed. The settings are 0-12.5%, 12.5%-25%, 25%-37.5%, 37.5%-50%, 50%-62.5%, 62.5%-75%, or 75-87.5%. 32 - English A26361-D1161-Z120-1-7619... -
Page 33: Display Activity
POST before it was last shut down (i.e. if you turn the system off before the POST, the registry will not be set, and the system will not be able to wake up using this function). The settings are Enabled or Disabled. English - 33 A26361-D1161-Z120-1-7619... -
Page 34: Plug And Play Setup
*Off Board PCI IDE Primary IRQ Disabled Disabled *Off Board PCI IDE Secondary IRQ Disabled Disabled PCI Slot1&5 IRQ Priority Auto Auto PCI Slot2 IRQ Priority Auto Auto PCI Slot3 IRQ Priority Auto Auto PCI Slot4 IRQ Priority Auto Auto 34 - English A26361-D1161-Z120-1-7619... -
Page 35: Plug And Play Aware O/S
The settings are No or Yes. PCI Latency Timer (PCI Clocks) This option specifies the latency timings (in PCI clocks) for PCI devices installed in the PCI expansion slots. The settings are 32, 64, 96, 128, 160, 192, 224, or 248. English - 35 A26361-D1161-Z120-1-7619... -
Page 36: Pci Vga Palette Snoop
The settings are Disabled, Hardwired, INTA, INTB, INTC, or INTD. Offboard PCI IDE Secondary IRQ This option specifies the PCI interrupt used by the secondary IDE channel on the offboard PCI IDE controller. The settings are Disabled, Hardwired, INTA, INTB, INTC, or INTD. 36 - English A26361-D1161-Z120-1-7619... -
Page 37: Pci Slot N Irq Priority
First-Last or Last-First. BIOS Devnode for Shadow RAM This option is used for some add-on card ROMs which do not claim the correct memory range that they occupy. The settings are Disabled or Enabled. English - 37 A26361-D1161-Z120-1-7619... -
Page 38: Peripheral Setup
LM79 IN4 LM79 IN5 LM79 IN6 LM79 FAN1 LM79 FAN2 LM79 FAN3 Onboard FDC Auto Auto Onboard Serial Port 1 3F8h 3F8h Onboard Serial Port 2 2F8h 2F8h Serial Port 2 Mode Normal Normal *IR Duplex Mode 38 - English A26361-D1161-Z120-1-7619... -
Page 39: Power Interruption
This option specifies the base I/O port address of serial port 1. The settings are Auto, Disabled, 3F8h, 2F8h, 3E8h, or 2E8h. Onboard Serial Port2 This option specifies the base I/O port address of serial port 2. The settings are Auto, Disabled, 3F8h, 2F8h, 3E8h, or 2E8h. English - 39 A26361-D1161-Z120-1-7619... -
Page 40: Serial Port2 Mode
The parallel port can be used with devices that adhere to the Extended Capabilities Port (ECP) specifications. ECP uses the DMA protocol to achieve data transfer rates of up to 2.5 Megabits per second. ECP provides symmetric bi- directional communication. 40 - English A26361-D1161-Z120-1-7619... -
Page 41: Epp Version
The settings are 0 through 7 in increments of one. Onboard IDE This option specifies the IDE channel used by the onboard IDE controller. The settings are Disabled, Primary, Secondary, or Both. Language Utility Currently, the BIOS Setup program is available only in English. English - 41 A26361-D1161-Z120-1-7619... -
Page 42: Supervisor And User Security
In either the Supervisor or User Security options, pressing <Enter> once when asked for a new password, and a second time when asked to confirm the new password, will uninstall the existing password. Note that uninstalling the Supervisor password uninstalls the User password as well. 42 - English A26361-D1161-Z120-1-7619... -
Page 43: Flash Writer Utility
It is not possible to update the BIOS with a LS-120 120 MB UHD Floppy disk drive. To update the BIOS, you have to connect a standard 1.44 MB floppy disk drive temporary. English - 43 A26361-D1161-Z120-1-7619... -
Page 44: Beep Codes
If it still beeps, replace the cache memory. 4, 5, 7, or 10 times... for 5 or 7 beeps, first test with a new CPU - if that does not solve the problem, then system board must be replaced. 44 - English A26361-D1161-Z120-1-7619... -
Page 45: Displayed Error Messages
Display Switch Not Some systems require a video switch be set to either color or Proper monochrome. Turn the system off, set the switch properly, then power on. DMA Error Error in the DMA controller. English - 45 A26361-D1161-Z120-1-7619... - Page 46 XXXX is the hex address where the error occurred. Run AMIDiag to find and correct the problem. Parity Error ???? Parity error in system memory at an unknown address. Run AMIDiag to find and correct the problem. 46 - English A26361-D1161-Z120-1-7619...
-
Page 47: Glossary
Closed and open jumpers. Jumpers and jumper pins are active when they are On or Closed, and inactive when they are Off or Open. CMOS Complementary Metal-Oxide Semiconductors are chips that hold the basic start-up information for the BIOS. English - 47 A26361-D1161-Z120-1-7619... - Page 48 IRQ An Interrupt Request is an electronic request that runs from a hardware device to the CPU. The interrupt controller assigns priorities to incoming requests and delivers them to the CPU. It is important that there is only one device hooked up to each IRQ line; doubling up devices on IRQ 48 - English A26361-D1161-Z120-1-7619...
- Page 49 (that is, the data is transmitted in serial form, one bit after another). SIMM Single In-line Memory Modules are the most common form of RAM. They must be installed in pairs, and do not have the carrying capacity or the speed of DIMMs. English - 49 A26361-D1161-Z120-1-7619...
- Page 50 ZIF socket Zero Insertion Force sockets make it possible to insert CPUs without damaging the sensitive pins. The CPU is lightly placed in an open ZIF socket, and the metal lever pulled down. This shifts the processor over and down, guiding it into place on the board. 50 - English A26361-D1161-Z120-1-7619...
-
Page 51: Table Of Contents
Devices....................21 Initial Display Mode ......................22 Floppy Access Control ....................22 Hard Disk Access Control ....................22 S.M.A.R.T. for Hard Disks....................22 Boot Up Num-Lock......................22 PS/2 Mouse Support ....................... 22 Primary Display....................... 22 Password Check ......................22 A26361-D1161-Z120-1-7619... - Page 52 ACPI Aware O/S......................31 Power Management/APM....................31 Power Button Function ....................31 Green PC Monitor Power State ..................31 Video Power Down Mode ....................32 Hard Disk Power Down Mode ..................32 Hard Disk Time Out (Minute) ................... 32 A26361-D1161-Z120-1-7619...
- Page 53 Parallel Port DMA Channel ..................... 41 Onboard IDE ........................41 Language Utility ........................41 Supervisor and User Security....................42 Flash Writer Utility........................... 43 Beep Codes ............................ 44 Troubleshooting System Problems..................44 Displayed Error Messages ...................... 45 Glossary ............................47 A26361-D1161-Z120-1-7619...
- Page 54 A26361-D1161-Z120-1-7619 System board D1161 Technical Manual April 1999 edition Intel, Pentium and Celeron are registered trademarks and MMX and OverDrive are trademarks of Intel Corporation, USA. INTEL, Pentium II, Pentium III, Celeron, Xeon are trademarks of Intel Corporation. Microsoft, MS, MS-DOS and Windows are registered trademarks of Microsoft Corporation.
