Appendix A: Physical Specification
Measurement
Weight
Length
Depth
Height
Appendix B: Performance Specification
Measurement
Input impedance
Output impedance
Current draw
Power supply requirements
Appendix C: Connector Pin Out
Instrument & Amplifier 1/4" TS Sockets:
Pin
Tip
Sleeve
Unboxed
500g (18oz)
124mm (4.8")
64mm (2.5")
58mm (2.3")
DELUXE55 Tweed Recreation
Boxed
570g (20oz)
135mm (5.3")
90mm (3.5")
85mm (3.3")
Value
1M Ω
1k Ω
100mA
9VDC 2.1mm centre negative connector
Description
Signal
Ground
