Appendix A: Physical specification
Measurement
Weight
Length
Depth
Height
Appendix B: Performance specification
Measurement
Input impedance
Output impedance
Current draw
Power supply requirements
Appendix C: Connector pin outs
Instrument & Amplifier 1/4" TS sockets:
Pin
Tip
Sleeve
Unboxed
620g (21.8oz)
143mm (5.62")
66mm (2.6")
65mm (2.56")
Boxed
700g (24.6oz)
170mm (6.6")
100mm (3.9")
75mm (2.9")
Value
1MΩ
1kΩ
100mA
9VDC 2.1mm centre negative connector
Description
Signal
Ground
RevivalDrive Compact
13
