Vox

Installation Instructions

works with the

Google Assistant

Table of Contents

Need help?

Do you have a question about the Vox and is the answer not in the manual?

Questions and answers

Summary of Contents for Modern Forms Vox

Page 1 Installation Instructions works with the Google Assistant...
Page 2 Please read and save these instructions before installation DO NOT RETURN TO STORE FR- W 1 8 0 2 Vox Instructions...
Page 3: General Inquiries
For fast service have the following information below when you call: Model Name and Number 2. Part Number and Part Description 3. Date Of Purchase and Purchase Location 1-866-810-6615 option 2 MON-FRI 8AM-8PM EST Email: fansupport@modernforms.com FR -W 1 80 2 Vox Instructions 3...
Page 4: Safety Rules
All set screws must be checked and re-tightened where necessary before installation. FR- W 1 8 0 2 Vox Instructions...
Page 5 Modern Forms. Substitution of parts or accessories not designated for use with this product by Modern Forms could result in personal injury or property damage and will void the warranty. Contact an authorized dealer or the manufacturer if any parts are damaged or missing.
Page 6 UL/cUL safety regulations. Finished and rated for interior and exterior use Premium smart features: complement high quality materials Quiet, reliable, and up to 70% MOTOR F-RCBT-WT Accessories: personalize your experience F-WCBT-WT FR - W 1 8 0 2 Vox Instructions...
Page 7: Table Of Contents
6. Installing the Optional Wall Control 7. Finishing the Installation 8. Installing the Luminaire Module 9. Controlling the Fan 10. Reset 11. Breeze Mode 12. Application 13. Accessories 14. Troubleshooting 30-32 Tools Required FR-W 1 80 2 Vox Instructions 7...
Page 8: Package Contents
Ø10xØ4mm flat washers (2) Self-Tapping Screws (1) Before discarding packaging materials be certain all parts have been removed. Place the parts from the hardware bag into a small container to keep them from being lost. FR - W 1 8 02 Vox Instructions...
Page 9 Hanging Weight: IMPORTANT: Please make note of the MAC ID on the receiver and keep it in a safe place. FR-W 1 80 2 Vox Instructions 9...
Page 10: Mounting Options
45° (Fig. 1B). NOTE: You may need a longer downrod to maintain proper blade clearance when installing on a steep, sloped ceiling (Fig. 1B). FR- W 1 8 0 2 Vox Instructions...
Page 11 Support Brace 2. Outlet Box 3. Joist Outlet Box Support Ceiling Max 30° Angle Support Brace 2. Mounting Bracket 3. Recess Outlet Box Outlet Box FR-W 1 80 2 Vox Instructions 11...
Page 12: Installing The Mounting Bracket
3. Attaching the Fan Blade Place blade on motor and secure with the blade attachment, screws and washers. 2. Insert blades in slots, aligning with motor assembly holes. 3. Secure blades with blade attachment screws & washers. FR-W 1 8 0 2 Vox Instructions...
Page 13 Electrical Box 2. Wires 3. Mounting Bracket 4. Screws Slot 2. Blade 3. Screws FR-W 1 80 2 Vox Instructions 13...
Page 14: Hanging The Fan
5. Secure the safety cable into the structure beams using the wood screw, washers, and spring washers provided (Fig. 4C). NOTE: Safety cable is required for all ceiling fan installations in Canada. Safety cable is required for ceiling fan and light (combo) United States. FR-W 1 8 0 2 Vox Instructions...
Page 15 Safety Cable 2. Screws (2) 3. Cotter Pin 4. Motor Wires 5. Downrod 6. Collar Clevis Pin Wood Screw 2. Safety Cable FR-W 1 80 2 Vox Instructions 15...
Page 16: Making The Electrical Connections
Connect the black (hot) wire from the ceiling to the black wire marked “AC in L” from the receiver. 8. Connect the white (neutral) wire from the ceiling to the white wire marked “AC in N” from the receiver. FR- W 1 8 0 2 Vox Instructions...
Page 17 Follow the steps above to connect the fan to your household wiring. Use the plastic wire nuts with your fan. Secure the plastic wire nuts with electrical tape. Make sure there are no loose strands or connections. FR-W 1 80 2 Vox Instructions 17...
Page 18: Installing The Optional Wall Control
Fasten the wall plate to the wall mounting plate (Fig. 6A). to Fan House Wires Wall Switch Wires (Hot) (Hot In) (Neutral) (Neutral) (Copper/Ground) (Ground) Fan Switch leg (Hot out to Fan) From Breaker * Home Wiring may vary FR- W 1 8 0 2 Vox Instructions...
Page 19 Individually pair each of the wall controls with the fan receiver using the pairing instruction. See page 25. If Applicable Wallcontroller 1 Wallcontroller 2 Wallcontroller 3 Wall Control 3 Wall Control 1 Wall Control 2 Line/Hot Green (Green or Bare) Neutral/White FR-W 1 80 2 Vox Instructions 19...
Page 20: Finishing The Installation
7. Finishing the Installation Secure wire connectors with supplied wire ties. 2. Install canopy to mounting bracket with the screw removed in section 2. 3. Install canopy screw ring as shown (Fig. 7). FR- W 1 8 0 2 Vox Instructions...
Page 21 Outlet Box 2. Hanger Bracket 3. Screws 4. Canopy 5. Canopy Screw Cover FR-W 1 80 2 Vox Instructions 21...
Page 22: Installing The Luminaire Module
4. Remove 3 screws from the outer perimiter of the adapter plate. 5. Secure the luminaire module with the 3 screws to the adapter plate (Fig. 8A). 6. Install glass shade without over-tightening (Fig. 8B). FR - W 1 8 02 Vox Instructions...
Page 23 FR-W 1 80 2 Vox Instructions 23...
Page 24: Controlling The Fan
Synchronizing Control Across Multiple Fans If you are controlling multiple fans with one controller, fans/lights may be synced by referring to Fig. 9B and instructions on the next page. FR- W 1 8 0 2 Vox Instructions...
Page 25 Direction: Press and hold button for 4 seconds. The LED on the remote will received. All fans will be set to summer mode (CCW rotation). This will bring all fans controlled by the remote into sync. FR-W 1 80 2 Vox Instructions 25...
Page 26: Reset
In addition to the included remote control, you can control your fan with a wall control (sold separately) or through the Modern Forms app. To use the Modern Forms app, download it for free from the App Store or Google Play.
Page 27 Press the reset button on the receiver until the fan emits 3 beeps indicating the reset receiver emits 3 beeps indicating the reset For support videos on installation and smart home device intergration FR-W 1 80 2 Vox Instructions 27...
Page 28: Accessories
Bluetooth Remote Control Dims light to 1% | ON/OFF 6 fan speeds F-RCBT-WT White Bluetooth Wall Control Dims light to 1% | ON/OFF 6 fan speeds| Sold separately F-WCBT-WT White FR- W 1 8 0 2 Vox Instructions...
Page 29 XF-I Downrod XF-12 - 12” Downrod | XF-18 - 18” Downrod XF-24 - 24” Downrod | XF-36 - 36” Downrod XF-48 - 48” Downrod | XF-60 - 60” Downrod XF-72 - 72” Downrod FR-W 1 80 2 Vox Instructions 29...
Page 30: Troubleshooting
5. Make sure the gaps between the blades are evenly distributed or make sure you are using an approved cUL/UL listed outlet box and it is installed correctly. FR- W 1 8 0 2 Vox Instructions...
Page 31 Your fan supports connection with 2.4GHz 802.11b/g/n networks. settings or contact your router manufacturer. 2. Make sure your network’s SSID is not hidden. 3. Your fan does not support 5 GHz network connectivity. connection. FR -W 1 80 2 Vox Instructions...
Page 32 Power cycling is the act of temporaily removing the power source for your fan. If the fan is powered through a wall switch, turn the switch back on. If your fan is wired through a Modern Forms wall control (P/N: F-WCBT-WT) pull the Air-Gap Switch on your wall control, wait 10 seconds, and re-insert.
Page 33 What is Pairing? Pairing is the process of connecting your Modern Forms remote or wall control to your fan. Your fan comes pre-paired to your included remote control. However, if you want additional controls for your fan or if you’re replacing a control, refer to the pairing and unpairing section of the instructions.
Page 34 For coastal locations, some corrosion and/or deterioration is problem cannot be resolved, an RGA number will be issued. Modern Forms obligation is expressly limited to repair or replacement, without charge, at the Modern Forms factory after prior written return authorization has been granted.
Page 35 Esta garantía no se aplicará a los productos que hayan sido alterados, instalados Modern Forms dentro de los cinco (5) años a partir de la fecha de compra (o según el período de tiempo indicado en el material). Quedan excluidos de la garantía todos los componentes de terceros que tengan la garantía de su propio fabricante.
