INTERSECTOR UNDER MIRROR LED LIGHT

ELECTRICAL INSTRUCTIONS:

ADVANCE PATTERN
Flash pattern can only be changed when the LED module is
in a flashing mode (disabled in cruise or steady ON func-
tions). When the light is flashing, momentarily touch the
white wire to ground for >250ms and <1s (light will go
steady high) then release. The flash pattern will advance to
the next pattern. If the light module was at the last pattern,
the pattern will reset to the 1st pattern.
BACKUP PATTERN
This function is only valid when the LED module is in a flash-
ing mode (disabled in cruise or steady ON functions). When
the light is flashing, momentarily touch the white wire to
ground for >1s and < 2s (light will go steady high, steady
low) then release. The flash pattern will backup to the previ-
ous pattern. If the light module was at the first pattern, the
pattern will change to the last pattern on the list.
COLOR SWAP
This function is only valid for dual color light modules and
can only be changed when the light module is in a flash-
ing mode (disabled for single color modules and when
light module is operating in cruise or steady ON functions).
When the light is flashing, momentarily touch the white wire
to ground for >2s and <3s (light will go steady high, steady
low, off) then release. The light module will switch between
Color Swap OFF and Color Swap ON. When Color Swap
is OFF, the 1st color will flash 1st on a dual color pattern.
When Color Swap is ON, the 2nd color will flash 1st on a
dual color pattern.
SIMULTANEOUS/ALTERNATE
This function can only be changed when the LED module is
in a flashing mode (disabled in cruise or steady ON func-
tions) and only has an effect when at least 2 LED modules
have the green sync wire connected together.
SECONDS
FROM TO VISUAL FEEDBACK
0 1 STEADY-HIGH (60%)
1 2 STEADY-LOW (30%)
2 3
3 4 STEADY - HIGH (60%)
4 5 STEADY - LOW (30%)
5 6
6 7 STEADY-HIGH (60%)
7 8 STEADY - LOW (30%)
If held longer than 8 seconds, the light will go back to flashing the current pattern and no action will be taken.
4
1.800.338.7337 / www.soundoffsignal.com
SETUP TABLE
OFF
OFF
FACTORY RESET (PATTERN 1, COLOR SWAP: OFF, SIMULTANEOUS)
When the light is flashing, momentarily touch the white
wire to ground for >3s and <4s (light will go steady high,
steady low, off, steady high) then release. The light mod-
ule will switch between Simultaneous and Alternate each
time this sequence is done. To have light modules flash
simultaneously, both light modules need to be set to the
same sequence type (Set-Up Table). To have light mod-
ules flash alternately, the light modules need to be set to
different sequence types (Set-Up Table).
PATTERN RESET
This function is only valid when the LED module is in a
flashing mode (disabled in cruise or steady ON functions).
When the light is flashing, momentarily touch the white
wire to ground for >5s and <6s (light will go steady high,
steady low, off, steady high, steady low, off) then release.
The flash pattern will reset to the 1st pattern in the list.
FACTORY RESET
This function is only valid when the LED module is in a
flashing mode (disabled in cruise or steady ON functions).
When the light is flashing, momentarily touch the white
wire to ground for >6S and <7S (light will go steady high,
steady low, off, steady high, steady low, off, steady high)
then release. The LED module will reset to: pattern=1,
Function Table=1, Color Swap=OFF, Simultaneous.
LOCKOUT CONFIGURATION WIRE
This function will disable the wire tap configuration mode
that is activated by holding the white wire to ground. The
lock out is activated by applying ground to the white wire
for >7 seconds and <8 seconds per the table below. The
function can be disabled by tapping the wire to ground
and releasing 8 times within 5 seconds. The light will flash
8 times when the feature is enabled or disabled to notify
the user of a setting change.
USER INTERFACE
ACTION TAKEN
FORWARD ONE PATTERN
BACKWARD ONE PATTERN
COLOR SWAP (OFF OR ON )
SEQUENCE TYPE: SIMULTANEOUS OR ALTERNATE
SEE FUNCTION TABLE
RESET TO PATTERN 1
SEPARATE COLOR CONTROL: OFF
LOCK OUT WHITE CONFIGURATION WIRE
INTERSECTOR UNDER MIRROR MOUNT
