- Page 1 Wireless Omnidirectional Microphone User Manual TV-S63WB Please read this manual carefully before usage.
-
Page 2: Important Safety Precautions
(Instructions for Fire, Electric Shock or Human Injury) Important Safety Precautions When using this electrical product, take the following basic precautions: 1. Please read all safety precautions carefully before using this product; 2. Please do not try to change the connection cable of the product without permission. If the length is not suitable, please consult our after-sales personnel;... -
Page 3: Table Of Contents
Content 1. Product description........................- 3 - 2. Button function and LED display....................- 3 - 3. Charging overview.........................- 4 - 4. Switch description......................... - 5 - 5. USB Connection..........................- 5 - 6. External device interface description................... - 6 - 7. -
Page 4: Product Description
1. Product description TV-S63WB is a professional USB HD omnidirectional microphone with 3 built-in microphones and supports wireless 2.4G, allowing for convenient and pleasant remote communication anytime and anywhere. Equipped with a new network conference system, it features powerful functions and simple operations. -
Page 5: Charging Overview
PC/Audio terminal This interface can be connected to the 3.5mm port of the connector PC/audio and video terminal for communication The USB cable can be connected to this interface to USB port/charging communicate/charge the product; when charging, the port power light will turn red, and turn green when fully charged Note: When the battery is low, all LED lights flash green three times every 30 seconds. -
Page 6: Switch Description
4. Switch description Long press the power button of the controller " " for 3 seconds to turn on or off the power; in addition, when the USB port of the controller is connected to a computer or an external audiovisual terminal, the controller will automatically turn on. -
Page 7: External Device Interface Description
6. External device interface description A 3.5mm audio cable can be used to connect the controller with external devices such as headphones/audio equipment through the " " port of the controller. 7. IN/OUT connection 1. When the terminal device connection port is a four-core audio interface, the "I/O" port of this product can be connected to the terminal device through a 3.5mm four-core audio cable;... -
Page 8: Cascading Operations
9. Cascading operations The master works normally, and the slave starts normally. Use a dedicated 3.5mm audio cable to insert into the " " port of the controller, and the other end into the "I/O" port of the slave, that is, the connection is successful. 10. -
Page 9: Features
Note: When the status indicator (ring LED light) in the middle of the controller is off, it means the speaker is muted. Check the battery level (for wireless version) When the controller is working, short press the power button, the brightness of the status indicator (ring LED light) in the middle of the controller will change with the battery power. -
Page 10: Specification
13.Specification Model TV-S63WB Bidirectional Noise 18dB Compression (NC) Microphone Automatic Support Direction Searching (EMI) Automatic Gain Control (AGC) Support Echo cancellation length ≥500ms Mic frequency response 100Hz-22KHz Mic pickup radius 3 meters, 360° full range Windows 10, Windows Vista, Windows 7, Windows 8, Mac... -
Page 11: Product Packaging
14.Product packaging (This product is under continuous improvement. Specifications and details are adjusted without prior notice, please refer to the actual product.) 15. Warranty 1. When purchasing this product, please fill in this card and read the following warranty terms carefully to ensure that the product is effectively guaranteed: 1) User carefully keeps the card when purchasing the product;...
