- Page 1 Ture Diversity MIC System User Manual T-521UH T-521UT T-521UL Before using the system, please read this manual first...
- Page 2 Thank you for choosing our UHF wireless microphone. Please read the manual carefully before operation, to study the correct operation method to gain the best application effect. This device adopts UHF double diversity reception and DPLL multi-channel frequency synthesis technology. It provides 200 channel selections for each frequency bandwidth 800MHz, 700MHz and 600MHz by 250KHz channel spacing, in order to avoid interference easily.
- Page 3 1. Transmitter Framework and Function Front Panel TELETRON ① ② ③ ④ ⑤ ② ③ ④ ⑥ Back Panel DC INPUT 12-15V 800mA ANT B ANT A UNBAL OUT UNBAL A BAL B OUT BAL A OUT ⑦ ⑧ ⑧ ⑨...
- Page 4 and negative outside. 8) Antenna pedestal. BNC pedestal. 9) Audio balance output. Adopt “XLR” plug seat, two channel signal output separately. 10) Toggle switch to A+B. Two channels will be combined to one channel as unbalanced output. 11) Toggle switch to B. B channel unbalanced output. 12) Toggle switch to A.
- Page 5 4) 3 open the transmitter power, such as transmitter and receiver to different frequency, the frequency 3.Operating instruction of the liquid crystal display panel (1) LCD full bright display ① 8 RF display: display the received radio frequency signal strength ②...
- Page 6 (2) Key functions and operation Press "SET" key to choose menu and confirm the configuration. Press “▲”“▼”adjust the currently selected menu, then press "SET" to confirm to setting. Long press “▲” and "▼" keys can quickly set frequency, channels. (3) Instructions for the LCD panel A Frequency setting: press "SET"...
- Page 7 Please click the "SET" key to confirm after your selection, otherwise it is invalid, the main column will keep the previous display. When you changed the choice but not confirm the LCD screen after 2-3 seconds, it will remind by flashing, press the "SET"...
- Page 8 After 2-3 seconds it will display: This menu is used to adjust the receiver noise, in order to enhance anti-jamming capability of the system. Adjust the range is from 0 to 40 db, the greater the value, the lower the sensitivity, the closer distance, the stronger anti-interference ability.
- Page 9 After 2-3 seconds it will display: (Note:Which of the above will be showed depends on the previous set) This menu function is, whether lock the current receiver working status (channel, sensitivity, in the main display column, the power switch, etc.), if shows "LOC ON", it can't change the current working status and the machine can not be turned off;...
- Page 10 (1) net head and a sound head module: net head is used to protect the voice into the sound head module of audio signals, eliminating tuency / channel and battery. (2) liquid crystal display: display freq he boot state; 3 seconds long for shutdown state.
- Page 11 crystal display the current working channel and battery. If you need to change the channel, the receiver channel should be changed first. And then match the transmitter and receiver for infrared alignment frequency window, and press the "SET receiver". Then the new frequency channel parameters will be sent to the transmitter.
- Page 12 (1) Audio input connector (2) Power switching: turn the switch to “ON” position when using; turn it to “OFF” position when not using (3) Status indicator: when the switch is turned to “ON” position, the indicator will flash, which means the battery level is normal; if it does not flash, it means the battery is no power or not well installed;...
- Page 13 wires, otherwise it will reduce the use effect. (2) The sensitivity should be adjusted according to different audio sources and mics. (3) While using the clip mics, in order to keep the voice not up and down by the rotation of the head, you should put the clip mic in the middle position and fix the mic wire to avoid any friction noise.
- Page 14 transmission direction. (4) If receiving condition is not good, extension cord and high gain antenna can be adopted， or even to add antenna amplifier to get a very obvious long distance transmission effect. (5) When receiver panel face to the application direction, or that when receiver is put in metal box, connect the antenna to front panel shall gain a better receiving effect.
- Page 15 7. Fault processing and preservation Fault Phenomenon Fault Reasons No indication from the The battery of transmitter runs out or the Transmitter and Receiver power connection of the receiver is loose. No radio The received frequencies are different or wave from the receiver out of the receiving range There is radio wave The mic of transmitter is not connected or...
- Page 16 Operation and Preservation: Don't put the unit in high humidity or strong magnetic field, or under strong direct sunlight, or high temperature environments. The receiver power and transmitter batteries should be brought out if there is no operation for a long time.
- Page 17 8. Specifications Frequency range: 640-690MHz and 740-790MHz，,807-857MHz Frequency oscillation mode: phase-locked loop Total channels: 600 CH Frequency response: 50Hz---18KHz Working distance: 300 Frequency bandwidth: 25MHz Carrier Wave stability: ±5PPm≤10KHz Cross talk: >80dB S/N Ratio: >105dB(1KHz-A) Sensitivity: -105dBm(12dB S/N AD) THD: <0.5%@1kHz Output Impedance: 2.2kΩ...
