- Page 1 Fully Digital Congress System User Manual TS-0230/0230A Before using this system, please read this manual carefully...
- Page 2 Notification WARNING To ensure the reliability of the equipment and the safety of personnel, please observe the following when installing, using and maintaining: ● If any of the following conditions are found, please immediately turn off the power, plug out and quickly contact your nearest dealer.
- Page 3 ● This product uses a power plug or appliance input socket as a disconnecting device with the power supply, and must be disconnected if necessary for safety reasons. ● This equipment is only suitable for safe use at altitudes above 2000 meters. Precautions 1.
- Page 4 5. Agreement Please strictly follow the instructions in this manual. The software, hardware and appearance of this product will be upgraded and updated continually. The above changes will be made without notice. Non-professional maintenance personnel, do not remove the product, to avoid damage and electric shock.
-
Page 5: Table Of Contents
2.1 Full digital lifting chairman/delegate discussion unit.............. 7 2.2 Features............................. 7 2.3 Product Function Introduction....................8 2.4 Specification..........................9 3. Conference system units TS-0230/0230A operating introduction..........10 3.1 Power On..........................10 3.2 The Unit type.......................... 10 3.3 ID setting test.......................... 10 3.4 Conference management......................10 3.5 Sign in............................. -
Page 6: System Introduction
1. System introduction 1.1 Brief description TS-0200 series fully digital conference system adopts ITC’s original network communication and digital transmission processing technology with completely independent intellectual property rights, and applies digital technology and network technology to conference system products, which makes the conference field have a new breakthrough. -
Page 7: Product Description
2. Product Description 2.1 Full digital lifting chairman/delegate discussion unit TS-0230 Chairman unit TS-0230A Delegate unit 2.2 Features The product adopts embedded lifting design, the overall simple and classy appearance, easy and intuitive operation, present strong sense of modern technology. -
Page 8: Product Function Introduction
13. The intelligent control microphone can only turn on the microphone when it is lifted to the top, and automatically turn off the microphone when the microphone is lowered. 2.3 Product Function Introduction TS-0230(Chairman unit)： TS-0230A(Delegate unit)： ① Chairman unit microphone button ②... -
Page 9: Specification
2.4 Specification Model TS-0230/TS-0230A Microphone Type Heart-shaped oriented electrets Frequency Response 80Hz-16KHz Microphone Input Impedance 1KΩ Sensitivity -46dBV/Pa Max SPL 125dB（THD>3%） >80dB(A) Dynamic Range >80dB <0.1% Power Consumption Compliant Norm IEC60914 Connector With 2M aviation extension cable of six-core Power Supply 110~220V AC（50/60Hz）... -
Page 10: Conference System Units Ts-0230/0230A Operating Introduction
3. Conference system units TS-0230/0230A operating introduction 3.1 Power On A few seconds after turning on the power of conference system controller, if unit can be turn on/off successfully, the system is normal. Otherwise the solution shall be worked out. -
Page 11: Other Functions
3.7 Other functions 3.7.1 Timed speaking and timing speaking The function is controlled and switched by conference PC software, detailed information please refer to PC software manual. The function is for turning on/off microphone. When unit is in timed speaking mode, PC issues the specified time limitation and unit counts down to show the rest time. Microphone will be off when time is up. -
Page 12: Desktop Opening Drawing
4. Desktop opening drawing Desktop Installation steps: 1. As shown in the drawing, first open the slot on the desktop with a size of 161x71x4mm and round the 2. Then open a through hole with size of 147*62mm in the middle of the above slot. 3. - Page 13 Fully Digital Congress System VersionV0.1...
