- Page 1 USER MANUAL VOICE EVACUATION & PUBLIC ADDRESS SYSTEM VA-6ZRM Thanks for using ITC Voice Evacuation& Public Address System. For better operation, please read this manual carefully before operating the system.
- Page 2 Notification WARNING To ensure the reliability of the equipment and the safety of personnel, please observe the following when installing, using and maintaining: ● If any of the following conditions are found, please immediately turn off the power, plug out and quickly contact your nearest dealer.
- Page 3 Precautions 1. The installation environment When installing the unit, in order to ensure the normal cooling of the host, should avoid the poor ventilation of the place or high temperature environment, to avoid direct sunlight. Recommend to install cabinet or other well-ventilated place indoor. If you use the machine in the outdoors, please pay attention to waterproof, moisture, lightning protection measures.
- Page 4 Contents 1. Product picture..........................5 1.1 Product picture.......................... 5 2. Introduction to features........................6 2.1 EVAC-6RM Features........................6 2.2 Main technical parameters......................7 3. Panel function instruction........................9 3.1 Front panel function instruction....................9 3.2 Rear panel function description....................11 4. Instructions............................12 5. Online upgrade instructions......................13 Accessories: DIP switch table......................
- Page 5 1. Product picture 1.1 Product picture Figure 1- 1VA-6ZRM Product picture...
- Page 6 2. Introduction to features 2.1 EVAC-6RM Features Support 160 zones, 6 groups paging Support configuring any zone to any group Support paging to any zone of any controller. Supports mix output / microphone priority output and adjustable output volume. ...
- Page 7 2.2 Main technical parameters Electrical indicators ① Power supply 24V DC power supply 24V power supply through network interface Performance ① Analog audio MIC. input Sensitivity 10MV ± 1mV Frequency 200Hz ~ 10KHz Input impedance 1kΩ ...
- Page 8 ③ Mechanical indicators Size (L × W × H) mm Net weight Aaround 1.1 Kg Installation desktop or 19-inch cabinet Color black ④ Environmental requirements Operating temperature +5 ℃ ~ +40 ℃ Storage temperature -20 ℃...
- Page 9 3. Panel function instruction 3.1 Front panel function instruction Front panel design sketch of VA-6ZRM 1. Panel indicator light Power indicator（DC POWER） ① Green: Normal input voltage Light is out: Unusual input voltage Zone grouping status indicator (Z/G) ②...
- Page 10 Light is out: Zone mode Green light flashing: on-line upgrading mode Red light flashing: on-line upgrading failed ④ Selecting all zones（ALL CALL） Grouping mode: cancel/select the corresponding 6 groups of the main controller. Zone mode: cancel/select the associated with 6 zones of the main controller. ...
- Page 11 3.2 Rear panel function description Figure 4- 2VA-6ZRM Rear panel renderings ① Switch ② Grounding post ③ DC voltage input ④ Line sound source input ⑤ Output volume adjustment ⑥ CAN communication network port ⑦ DIP setting: (up: enable down: off) PIN1: Can communication match resistance switch PIN2 ~ PIN6: Device address code set, using binary code address.
- Page 12 4. Instructions 1. In standby mode, users can associate with any host (host ID number: 1-20) through the panel 【page up】, 【page down】 key settings. In zone / group paging mode, default partition mode, if selecting group mode, the group indicator light is green. 2.
- Page 13 3. After completing the above steps, connect theVA-6ZRM to the controller, turn on the controller, re-power theVA-6ZRM ,VA-6ZRM will automatically enter into the upgrade state and upgrade process, the panel indicator flashes indicate the current update progress, and the group indicator light flashes means upgrade is completed;...
- Page 14 Accessories: DIP switch table Address code table (Address Code Description: Dial up: 0 Dial down: 1) PIN2 PIN3 PIN4 PIN5 PIN6 MIC_ID...
- Page 16 Version: 0.1...
