ITC VA-6000RT Quick Start Manual

Remote Paging Microphone
VA-6000RT
Descriptions
VA-6000RT is used for remote operating VA-6000 system, allowing users
to remotely control system voice information and zones paging. Support
system zones/groups selection, zones monitoring, zones volume
adjustment, zones status display.
Features
* IPS HD full view display, graphical touch operation, what you see is
what you get.
* System synchronizes the zones/groups name display, simple
operation.
* The icon partition status display, more images, more content.
* It can adjust the volume for each zone and monitor the current
playing content of each zone.
* The rear panel can be used for external audio source and can be
broadcast to any zone.
* Standard Ethernet digital transmission can extend the transmission
distance through optical fiber.
* The priority and emergency voice operating privileges of the VA-
6000RT can be configured by the system.
www.itctech.com.cn
Specifications
Model
Screen
Size
Resolution
Visual Angle
Touch Screen Type
Power Supply
Voltage
Max Current
Max Power Consumption
Standby Power Consumption
Performance Index
Line Input
Sensitivity
Input Impedance
MIC Input
Microphone Type
MIC Type
Sensitivity
Impedance
Monitor Audio Output
Rated Output
Output Power
Frequency Response
THD
SNR
Monitor Speaker
Output Power
Impedance
Mechanical Data
Dimension(Length x Width x Deep)
weight
Installation Type
Color
Environment Requirement
Working Temperature
Storage Temperature
Relative Humidity
info@itc-pa.com.cn
VA-6000RT
7inch
1024 x 600
Full Angle
capacitive screen
24V DC, ±20%
0.5A
12W
9W
775mV
10KΩ
415mm Goose Neck MIC
Standing in
10mV
250Ω
600mV
10mW (Drive 16-32Ω earphone)
100Hz~20KHz
<1% (Rated Output), 1KHz
>70dB
1.5W
4Ω
245 x 71 x 154mm
Machine: 1.44KG Power Supply: 0.3KG
Desktop
Black
+5℃ ~ +40℃
-20℃ ~ +70℃
<95% (without condensation)
