Black Under Desk Keyboard Tray with Swinging
Height Adjustment
Instruction Manual
SKU: MOUNT-KB08S
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-kb08s
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo MOUNT-KB08S
Summary of Contents for Vivo MOUNT-KB08S
- Page 1 Black Under Desk Keyboard Tray with Swinging Height Adjustment Instruction Manual SKU: MOUNT-KB08S Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-kb08s GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Assembly Steps
ASSEMBLY STEPS STEP 1 Assemble Keyboard Tray Set (A) by placing Connecting Plates (B) into the insets on underneathside of Tray. Secure with M5x12mm Screws (S-A) and a Phillips screwdriver. STEP 2 Install Keyboard Stop (D) onto assembled Keyboard Tray using M5x12mm Screws (S-A) and a Phillips screwdriver. - Page 4 STEP 3 Secure Height Adjustable Bracket Set (C) to the sides of Keyboard Tray (A) using M5x12mm Screws (S-A) and a Phillips screwdriver.
- Page 5 STEP 4 Unfold the Adjustable Brackets (C) by pressing down on the levers and pulling the top bracket up. Make sure the brackets are adjusted to the same level for installation.
- Page 6 STEP 5 Hold the keyboard tray assembly against the underside of the desk 0.5” (12mm) from the edge and mark drilling locations with a pencil. Drill 3/8” (10mm) deep holes using a 1/8” (3mm) drill bit. Mount keyboard tray assembly using M5x14mm Screws (S-B) and a Phillips screwdriver.
- Page 7 THIS PAGE INTENTIONALLY LEFT BLANK...
