Huawei LUNA2000-2.0MWH-4H1 Quick Manual

Huawei LUNA2000-2.0MWH-4H1 Quick Manual

On-grid utility-scale energy storage solution
Hide thumbs Also See for LUNA2000-2.0MWH-4H1:

Advertisement

Quick Links

On-Grid Utility-Scale Energy Storage Solution
Quick Guide
Issue
05
Date
2024-06-01
HUAWEI TECHNOLOGIES CO., LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LUNA2000-2.0MWH-4H1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Huawei LUNA2000-2.0MWH-4H1

  • Page 1 On-Grid Utility-Scale Energy Storage Solution Quick Guide Issue Date 2024-06-01 HUAWEI TECHNOLOGIES CO., LTD.
  • Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...
  • Page 3: About This Document

    Indicates a potentially hazardous situation which, if not avoided, could result in equipment damage, data loss, performance deterioration, or unanticipated results. NOTICE is used to address practices not related to personal injury. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 4: Change History

    1.1.1.2 Low-Voltage Coupling Scenario. Added 1.2.1.2 Low-Voltage Coupling Scenario. Modified 1.2.2 Grid Forming Scenarios. Modified 3 Check and Preparation Before Power-On. Modified 4.4 Commissioning Using the Deployment Wizard. Updated A Reference Documents. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 5 On-Grid Utility-Scale Energy Storage Solution Quick Guide About This Document Issue 01 (2023-07-30) This issue is used for first office application (FOA). Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 6: Table Of Contents

    5 Powering Off the System....................47 6 System Power-On........................49 A Reference Documents......................50 B List of Alarms Affecting Topology Identification............53 C Contact Information......................56 D Acronyms and Abbreviations..................... 58 Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 7: Solution Introduction

    1 Solution Introduction Solution Introduction 1.1 Networking Architecture NO TICE The equipment must meet the local environment requirements. 1.1.1 Non-Grid Forming Scenarios 1.1.1.1 Medium-Voltage Coupling Scenario Figure 1-1 Networking in medium-voltage coupling scenario Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 8 ● LUNA2000-2.0MWH-1H1 ● LUNA2000-2.0MWH- HE1H1 ● LUNA2000-2.0MWH-1H0 ● LUNA2000-2.0MWH-2H0 with the BOM number 01075958 ● LUNA2000-2.0MWH-2H1 with the BOM number 01075975-011, 01075958-002, or 01075975-001 ● LUNA2000-2.0MWH-4H1 with the BOM number 01076385-002 Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 9 ● SmartPVMS Plant V600R024C00 and later versions SPPC ● SPPC2000-A01 (current Purchased from the Company sampling level: 1 A) (optional). ● SPPC2000-A02 (current sampling level: 5 A) Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 10: Low-Voltage Coupling Scenario

    ● LUNA2000-2.0MWH-4H1 Purchased from the Company. ● LUNA2000-2.0MWH-2H1 Each array supports a maximum of one ● LUNA2000-2.0MWH-1H1 LUNA2000-1.0MWH-1H1. ● LUNA2000-2.0MWH- HE1H1 ● LUNA2000-1.0MWH-1H1 Smart PCS ● LUNA2000-200KTL-H1 Purchased from the Company. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 11 License Management in the SmartLogger3000 User Manual . ● SmartACU2000D-D-03 for the double-split transformer ● SmartACU2000D-D-01 for the double-winding transformer SUN2000 ● SUN2000-330KTL-H1 Purchased from the Company. ● SUN2000-330KTL-H2 Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 12: Grid Forming Scenarios

    The grid forming function is supported in the ESS-only scenario and PV+ESS medium-voltage AC coupling scenario. Figure 1-3 uses the ESS-only scenario as an example. The PV+ESS medium-voltage AC coupling mode is the same as Figure 1-1. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 13 Purchased from the Company. ● The grid forming function is supported only by the LUNA2000-200KTL-H1 with the BOM number 01076613. ● In grid forming scenarios, the capacity ratio of PCS to ESS is 2.4:1. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 14 ESS is one of the following models. The DCBOX is not required for other ESS models. ● LUNA2000-2.0MWH-1H1 ● LUNA2000-2.0MWH- HE1H1 ● LUNA2000-2.0MWH-2H1 with the BOM number 01075975-011 ● LUNA2000-2.0MWH-4H1 with the BOM number 01076385-002 Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 15 & control dual ring networks, the third- party transformer station must be configured with two network switches with four optical ports and eight electrical ports and the recommended model is IES6300-8GP2GS2HS-2DI2D O-2P48. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 16 ● SmartPVMS Plant V600R024C00 and later versions SPPC ● SPPC2000-A01 (current Purchased from the Company sampling level: 1 A) (optional). ● SPPC2000-A02 (current sampling level: 5 A) Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 17 LUNA2000 -2.0MWH- -2.0MWH- -2.0MWH- -2.0MWH- -2.0MWH- LUNA2000 LUNA2000 -2.0MWH- -2.0MWH- HE1H1 HE1H1 Number of ESSs a: In solution 3, the active power overload capacity is achieved through ESS C- rate overconfiguration. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 18: Communication Logic

    The array consists of no more than 4 ESSs and no more than 34 PCSs (no requirement on communication latency). ● The SACU model is SmartACU2000D-D-00, and the SACU must be configured with the Ethernet switch and the SmartModule. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 19 ● The ESSs form a fiber ring network. The CMU of one ESS functions as the RSTP central node and connects to the SmartModule of the SACU over FE. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 20 A maximum of 15 PCSs can be connected into one FE ring network. Figure 1-6 uses three FE ring networks as an example. ● The STS communicates with the SACU over FE/RS485. Figure 1-6 uses FE communication as an example. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 21: Low-Voltage Coupling Scenario

    The array consists of no more than 10 ESSs, no more than 30 PCSs, and no more than 30 SUN2000s. ● The SACU model is SmartACU2000D-D-01, which should be configured with the SmartModule and five-port switch. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 22 The array consists of no more than 10 ESSs, no more than 30 PCSs, and no more than 30 SUN2000s. ● The SACU model is SmartACU2000D-D-03, which should be configured with the SmartModule and five-port switch. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 23: Grid Forming Scenarios

    FE ring networks as an example. ● It is recommended that the SmartLogger be installed close to the network switch. The network cable length depends on the installation position and cannot exceed 100 m. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 24 The ESSs form a fiber ring network. The CMU of one ESS functions as the RSTP central node and connects to the 5-port electrical switch of the SACU over FE. ● The SmartModule and 5-port electrical switch must be configured. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 25: O&M Methods

    User Manual alarm reporting, analysis, deployment and ● SmartPVMS Plant diagnosis, and O&M. commissioning V600R024C00 User Manual -ESS (SmartPVMS Plant) ● SmartPVMS Plant V600R024C00 User Manual -PV+ESS (SmartPVMS Plant) Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 26 Manual CMU of the ESS, and the a single device SUN2000 to locally manage locally a single PCS, ESS, and ● Upgrading the SUN2000. software version of a single device locally Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 27: Installation And Cable Connections

    PCS on a support. If the PCS needs to be installed on a wall, you need to prepare M12x60 stainless steel expansion anchor bolts. Installing the SUN2000 Installing the SACU Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 28 ● Preinstall nuts with the recommended torque of 27 N·m. ● After installing nuts, check that the torque is 27 N·m. Use a marker to mark the nuts after the torque is verified. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 29: Check And Preparation Before Power-On

    Ensure that the switches on the medium-voltage and low-voltage sides of the STS are off. Ensure that the switch between the PCS AC side and the transformer is off. Ensure that the switches on both sides of the DTS are off. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 30 Screw the reset device into the solenoid valve so that the plunger of the valve is not activated, as shown in the following figure. Remove the reset device and visually check that the plunger of the solenoid valve is not activated. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 31 Figure 3-2 Resetting the plunger of the solenoid valve Install the solenoid valve. WARNING For non-emergency manual operations, do not remove the safety pull ring. A safety pin is equipped only for certain models. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 32 On-Grid Utility-Scale Energy Storage Solution Quick Guide 3 Check and Preparation Before Power-On Figure 3-3 Installing the solenoid valve ----End Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 33: System Power-On And Commissioning

    In low-voltage coupling scenarios, PV arrays and ESSs share the same SACU. Power on PV arrays first and then ESSs, and skip repeated operations (such as powering on the STS and SACU). Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 34: Powering On The Ess Array

    4. Turn on the SACU three-phase input switch. (Skip this step for the SmartACU2000D- D-06.) ● Turn on switch FU01 for the SmartACU2000D-D-00 and SmartACU2000D-D-01. ● Turn on switches FU01 and FU02 for the SmartACU2000D-D-03. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 35 ● The smoke sensor starts, the green indicator blinks slowly, and no alarm sound is generated. ● The transformer temperature sensor starts and displays the current transformer temperature. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 36 5FCB3. d. Turn on the PSU AC input switch 6FCB1. e. Turn on the DC input switches 7FCB1 and (optional) 7FCB2, exhaust fan controller Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 37: Preparations And Webui Login

    SmartLogger3000 User Manual . ''Preparations and WebUI Login'' in the Step 1 Log in to the SmartLogger WebUI, and choose Monitoring > Logger(Local) > About to check the SmartLogger software version. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 38: Commissioning Using The Deployment Wizard

    4.4 Commissioning Using the Deployment Wizard Step 1 Set basic parameters. Figure 4-2 Setting basic parameters Step 2 Click Maintenance, choose Device Mgmt. > Connect Device, and check that the devices are connected. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 39 ● If the STS model is STS-3000K-H1 or STS-6000K-H1, perform the following steps to check and upgrade the STS software version after step Step 9 complete. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 40 Figure 4-5 Changing the device name Step 5 Clear alarms. Clear the alarms that affect topology identification by referring to B List of Alarms Affecting Topology Identification, and then search for the devices. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 41 ● After a device is added or deleted, you need to click Search for Device again in Deployment Wizard. Otherwise, the system topology will not be updated. Step 7 After the device search is complete, set the following parameters based on the site requirements. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 42 Parameter Configuration Grid Code Set the grid code of Set the grid code of the country or region the country or region where the devices are where the devices are used. used. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 43 Param. > Temper And Hum to view and set the control mode. ● If the air conditioner control mode is manual, choose Monitoring > HAVC > Running Param., and click to start the air conditioner. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 44 ● If a high-rate system is used in the low-rate scenario, it is prone to low efficiency, high power consumption, and current limiting. ● The Company is not liable for any system exception or Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 45 Stop Bit Set this parameter to 1. Start Start address ≤ STS Retain the default value 1. address communications address ≤ End address Retain the default value address 247. Add an STS. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 46 STS-(3000K, 6000K)-H1 Smart Transformer Station User Manual . – JUPITER-9000K-H0 or JUPITER-3000K-H1-GF: See Setting STS Parameters WLAN Wakeup in the corresponding user manual. Choose Monitoring > STS to check whether the STS data is correct. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 47 Step 12 Connect to the meter. Set related parameters by referring to "Setting Meter Parameters" in the SmartLogger3000 User Manual . Figure 4-8 Setting meter parameters Step 13 Connect environment monitoring devices. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 48 On-Grid Utility-Scale Energy Storage Solution Quick Guide 4 System Power-On and Commissioning Figure 4-9 Setting environmental monitoring instrument (EMI) parameters Step 14 Set battery control parameters. Figure 4-10 Setting battery control parameters Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 49 SOC settings will be overridden so that the ESS can be fully charged or discharged. ● If this parameter is set to Disable, automatic charge and discharge calibration is not allowed for battery racks. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 50 The default value is recommended. Set this parameter as communication required. disconnection NOTE In the low-voltage coupling scenario, if the PV+ESS capacity exceeds the transformer station capacity, you are advised to set this parameter to Enable. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 51 On-Grid Utility-Scale Energy Storage Solution Quick Guide 4 System Power-On and Commissioning Step 15 Connect to a Huawei network management system (NMS). Set related parameters by referring to "Setting Parameters for Connecting to the Management System" (content related to a Huawei NMS) in the SmartLogger3000 User Manual .
  • Page 52 4 System Power-On and Commissioning Figure 4-13 Third-party devices Step 18 Click Finish. NO TICE Do not click Batch configurations to issue an array startup or shutdown command. Figure 4-14 Configuration completed ----End Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 53: Powering Off The System

    DC voltage to verify that the shutdown is successful. Choose Monitoring > CMU > Running Info. Check the rated power and total output voltage of the rectifier to ensure that the shutdown is successful. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 54 For details, see JUPITER-(3000K, 6000K, 9000K)-H1 Smart Transformer Station User Manual. NO TE To prevent local operations on switches during subsequent power-on, you are advised not to turn off the auxiliary power switches. Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 55: System Power-On

    Send a startup command to the SUN2000, PCS, and Smart Rack Controller. Method 1 (array-level): Choose Maintenance > Connect Device, and click Method 2 (bus-level): Choose Overview > Plant Running Info., and click Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 56: Reference Documents

    LUNA2000-2.0MWH and 1.0MWH Series Smart String ESS Maintenance Manual ● LUNA2000-2.0MWH and 1.0MWH Series Smart String ESS Alarm Reference ● LUNA2000-2.0MWH-4H1 Smart String ESS Quick Guide ● LUNA2000-2.0MWH Series Smart String ESS Quick Guide ● LUNA2000-1.0MWH Series Smart String ESS Quick Guide ●...
  • Page 57 SPPC2000 Smart Power Plant Controller User Manual ● SPPC2000 Smart Power Plant Controller Quick Guide SmartLogger SmartLogger3000 User Manual FusionSolar FusionSolar App User Manual iMaster iMaster NetEco V600R023C00 SmartPVMS (Plant) User NetEco Manual Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 58 On-Grid Utility-Scale Energy Storage Solution Quick Guide A Reference Documents Device Document SmartPVMS ● SmartPVMS Plant V600R024C00 User Manual -ESS (Plant) (SmartPVMS Plant) ● SmartPVMS Plant V600R024C00 User Manual -PV+ESS (SmartPVMS Plant) Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 59: B List Of Alarms Affecting Topology Identification

    Bus Side Overvoltage on Rack Controller 3020 Bus Side Reverse Polarity on Rack Controller 3021 Insulation Resistance of Rack Controller Abnormal 3022 Rack Controller Temperature High 3023 Battery Terminal Overtemperature on Rack Controller Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 60 Connection of Rack Controller Abnormal 3044 Battery Pack Overcurrent 3045 Battery Pack Temperature High 3046 Battery Pack Temperature Low 3047 Battery Pack Undervoltage 3052 External DC Auxiliary Power Supply of Rack Controller Fault Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 61 Control Malfunction 3849 Air Exhaust Malfunction 1, 2 3850 Combustible Gas Detection Malfunction 3856 Battery Fault Protection 1, 2 3858 48 V DC Auxiliary Power Supply Faulty 3859 Forced Dehumidification Started Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 62: Contact Information

    To ensure faster and better services, we kindly request your assistance in providing the following information: ● Model ● Serial number (SN) ● Software version ● Alarm ID or name ● Brief description of the fault symptom Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 63 On-Grid Utility-Scale Energy Storage Solution Quick Guide C Contact Information NO TE EU Representative Information: Huawei Technologies Hungary Kft. Add.: HU-1133 Budapest, Váci út 116-118., 1. Building, 6. floor. Email: hungary.reception@huawei.com Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 64: Acronyms And Abbreviations

    D Acronyms and Abbreviations Acronyms and Abbreviations central monitoring unit Smart Rack Controller energy storage rack (battery rack) fast Ethernet power control system power supply unit RSTP Rapid Spanning Tree Protocol Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
  • Page 65 On-Grid Utility-Scale Energy Storage Solution Quick Guide D Acronyms and Abbreviations SACU Smart Array Controller state of charge state of health SPPC Smart Power Plant Controller Smart Transformer Station Issue 05 (2024-06-01) Copyright © Huawei Technologies Co., Ltd.
