- Page 1 COMPLIANCE LISTING GUIDE XT75 Control Panel DIGITAL MONITORING PRODUCTS, INC.
- Page 2 MODEL XT75 CONTROL PANEL COMPLIANCE LISTING GUIDE © 2024 Digital Monitoring Products, Inc. Information furnished by DMP is believed to be accurate and reliable. This information is subject to change without notice...
-
Page 3: Table Of Contents
CONTENTS Before You Begin ..........1 Wiring Diagrams .......... 2 System Diagrams ..............2 Listed Compliance Specifications ..... 3 Bypass Reports ..............3 Current Draw ................3 Battery Standby ..............3 Auxiliary and Bell Current ........... 3 Cross Zoning ................3 App Key ................... -
Page 4: Before You Begin
BEFORE YOU BEGIN This guide provides compliance information for the DMP XT75 Control Panel. After this introduction, the remaining sections describe the functions along with the available options. Before starting, we recommend that you read through the contents of this guide. The information contained here allows you to quickly learn the operation, functionality, and programming options of the panel to meet specific applications. -
Page 5: System Components
Accessory Devices CELLULAR COMMUNICATOR CARDS 263LTE Series Cellular Communicator Allows you to connect the XT75 to the Verizon, AT&T, or FirstNet LTE network. 263EXT Cellular Extension Module Allows you to remote the cell module away from the panel. ZONE AND OUTPUT EXPANSION MODULES 710 Bus Splitter/Repeater Increases keypad wiring distance to 2500 feet. - Page 6 Fixed temperature heat detector. 1183-135R Heat Detector Fixed temperature and rate-of-rise heat detector. 1184 Carbon Monoxide Detector Carbon Monoxide Detector. * These devices have not been investigated and shall not be used in listed installations. XT75 Compliance Listing Guide | Digital Monitoring Products...
-
Page 7: Wiring Diagrams
Replace every 3 to 5 years. used for connection of all initiating, indicating, and supplementary devices. POWER LIMITED All circuits on the Model XT75 panel comply with the requirements for inherent power limitation and are Class 2. XT75 Compliance Listing Guide | Digital Monitoring Products... -
Page 8: Listed Compliance Specifications
Battery Standby Use battery Models 365 (12 VDC 9 Ah) or 366 (12 VDC 18 Ah) with the XT75 panel when installed in the 340, 349, or 349A enclosures. The Model 364 (12 VDC 1.3 Ah) battery is for use with the XT75 panel when using the 341 enclosure with the optional 341B Battery Bracket. -
Page 9: Compliance
Automatic Bell Test and Opening/Closing must be set to YES to enable Closing Wait. Closing Wait provides a delay time before a monitored system arms until the panel receives an acknowledgment of the closing report from the central station receiver. XT75 Compliance Listing Guide | Digital Monitoring Products... -
Page 10: Household Fire Warning System - Ansi/Ul 985 Nfpa 72 Specifications
Household Fire Warning System - ANSI/UL 985 NFPA 72 Specifications Bell Output Definition The bell output must be programmed to operate steady on burglary alarms and temporal on fire alarms. See the XT75 Installation and Programming Guide (LT-2894). Household System An alarm sounding device must be installed indoors so that it is clearly heard in all sleeping areas. -
Page 11: Evacuation Plan
A fire alarm system installation with smoke and carbon monoxide detectors in each room Window Ladder can greatly decrease your risk of loss or injury. Building Back Building Front Figure 1: Escape Route Map XT75 Compliance Listing Guide | Digital Monitoring Products... -
Page 12: Troubleshooting
TROUBLESHOOTING This section provides troubleshooting information for use when installing or servicing an XT75 system. PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTIONS Keypad displays “SYSTEM TROUBLE” RESET Jumper is installed. Remove the RESET reset jumper. Open or short on the green data wire to the Check for broken or shorted wires between the panel and keypad. -
Page 13: Led Status
LED Status Listed below are types of LED statuses and conditions. STATUS CONDITION Power AC Good (Steady Green) Power AC Bad (Steady Green) Bus XMIT Flashing Data Out Bus RCV Flashing Data In XT75 Compliance Listing Guide | Digital Monitoring Products... -
Page 14: Specifications
All circuits inherent power limited. Note: Please see the "Listed Compliance Specifications" section for certificated application requirements. Enclosure The XT75 ships standard in a 340 enclosure with EOL resistors, battery leads, and user’s guide. MODEL SIZE COLOR CONSTRUCTION (COLD ROLLED STEEL) 12.5 W x 9.5 H x 2.75 D in... -
Page 15: Number Of Zones
Outputs ▶ The XT75 provides four open collector outputs rated for 50 mA each. A Model 300 Output Harness is required. The open collector outputs provide the ground connection for a positive voltage source. XT75 Compliance Listing Guide | Digital Monitoring Products... -
Page 16: Certifications
CERTIFICATIONS ▶ FCC Part 15 Registration ID CCKPC0252 ▶ Industry Canada ID: 525IA-PC0252 ETL Listed ANSI/UL 1023 Household Burglar ANSI/UL 985 Household Fire Warning ANSI/UL 2610 Central Station Burglar FCC Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
