Libi Digital Lock Keyed - Instructions
TM
Do not use an electric screwdriver during installation.
Use QR code for additional
installation information.
Package contents
Exterior Assembly Interior Assembly
1. Bolt adjustment
Determine if the bolt needs to be adjusted to the 70 mm backset.
To adjust, rotate the bolt until it stops.
Reverse the direction to return to the 60 mm backset.
60 mm
Drive-in Latch (optional configuration)
Change Bolt Face
method will be used
Determine which bolt mounting
and make necessary adjustments.
No adjustment required for square bolt face plate.
a. Use a flat screwdriver to separate the face plate.
b. Snap selected bolt face onto back plate.
Drive-in Latch
2. Prepare door and check dimensions
Use template enclosed to mark holes on door face.
Drill Ø54 mm holes from both sides of door.
Above the Ø54 mm from the exterior
side of the door drill Ø8 mm, 8 mm deep hole.
Drill Ø25.4 mm holes in door edge
for bolts.
ASSA ABLOY New Zealand Limited, 6 Armstrong Rd, Albany Auckland 0632, New Zealand
Part of ASSA ABLOY
yalehome.com/nz ©2024
WARNING
Mounting Plate Bolt
Drive-in
180°
70 mm
a
Drive-in Installation
Remove original bolt faceplate.
as illustrated and snap
Align the drive-in sleeve
into the bolt case.
Note. This is an optional fitting.
Install Drive-in Bolt
Drive the latch into the hole on edge of door.
Note. This is an optional fitting.
Ø8 mm ,
8 mm deep
b a
106 mm
c k
s e
t
Ø54 mm
WARNING
This Manufacturer advises that no lock can provide complete security by itself.
This lock may be defeated by forcible or technical means, or evaded by entry elsewhere on the property.
No lock can substitute for caution, awareness of your environment, and common sense.
Builder's hardware is available in multiple performance grades to suit the application.
In order to enhance security and reduce risk, you should consult a qualified locksmith or other security professional.
Strike Plate Wood Screws Length 31 mm Qty. 5
Wood Screws Length 76 mm Qty. 2
2 Keys Mounting Screws Length 18.5 mm
Mounting Screws Length 50 mm
3. Install bolt
a
b
c
b
4. Install strike
a
b
Backset
60 mm
or 70 mm
c
35 mm-45 mm
Ø25.4 mm
ASSA ABLOY Australia Pty Limited, 235 Huntingdale Rd, Oakleigh, VIC 3166
1300 LOCK UP (1300 562 587) yalehome.com/au | ABN 90 086 451 907 ©2024
Tools needed (not included)
Phillips Screwdriver
Tape Measure
Qty. 2
Qty. 2
a. Insert bolt in hole as shown and keep it parallel to door face.
Mark outline of face plate and remove bolt.
b. Chisel 4 mm deep inside traced outline or until
face plate is flush with door edge.
c. Insert bolt and tighten screws.
2 Wood screws 31 mm length.
a. Close the door so the latchbolt is against the door frame.
Mark the centre line on the door frame exactly opposite
the bolt hole in the door edge.
b. Measure one half of door thickness from door stop and
vertically mark center line of strike.
Drill Ø25.4 mm hole, 25.4 mm deep at intersection
of horizontal and vertical line of strike. Mark outline using
strike plate and chisel 2 mm deep for strike.
c. Install strike and tighten screws.
2 Wood screws 31 mm length.
2 Wood screws 76 mm length.
