Page 1: Installation Guide
Installation Guide 613-000974 Rev. B Stackable Gigabit Ethernet Switches AT-8000GS/24 AT-8000GS/POE AT-8000GS/48... - Page 2 Allied Telesis, Inc. reserves the right to make changes in specifications and other information contained in this document without prior written notice. The information provided herein is subject to change without notice. In no event shall Allied Telesis, Inc. be liable for any incidental, special, indirect, or consequential damages whatsoever, including but not limited to lost profits, arising out of or related to this manual or the information contained herein, even if Allied Telesis, Inc.
-
Page 3: Preface
AT-8000GS Series Gigabit Ethernet switch. This preface contains the following sections: “Safety Symbols Used in this Document” on page 4 “Where to Find Web-based Guides” on page 5 “Contacting Allied Telesis” on page 6 AT-8000GS Series Gigabit Ethernet Switch Installation Guide... -
Page 4: Safety Symbols Used In This Document
Preface Safety Symbols Used in this Document This document uses the safety symbols defined in Table 1. Symbol Table 1. Safety Symbols Meaning Caution Performing or omitting a specific action may result in equipment damage or loss of data. Warning Performing or omitting a specific action may result in electrical shock. -
Page 5: Where To Find Web-Based Guides
AT-8000GS Series Gigabit Ethernet Switch Installation Guide Where to Find Web-based Guides The installation and user guides for all Allied Telesis products are available in portable document format (PDF) on our web site at www.alliedtelesis.com. You can view the documents online or download... -
Page 6: Contacting Allied Telesis
Internet sites: Software Updates If you prefer to download new software from the Allied Telesis FTP server from your workstation’s command prompt, you will need FTP client software and you must log in to the server. Enter “anonymous” for the user name and your email address for the password. -
Page 7: Table Of Contents
RJ-45 Console Port ...15 LED Definitions ...16 System LEDS ...16 Stacking Port LEDs ...17 Mode LEDs...18 RJ-45 Port LEDs on AT-8000GS/24 & AT-8000GS/48 ...19 RJ-45 Port LEDs AT-8000GS/24POE ...21 SFP Port LEDs ...22 Stacking Port LEDs ...23 Chapter 2: Installation ...25 Reviewing Safety Precautions ...26... - Page 8 Contents Chapter 3: Stacking ...35 Stacking Overview ...36 Stacking Ring Topology...36 Stacking Chain Topology...37 Stacking Members and Unit ID ...37 Removing and Replacing Stacking Members...37 Exchanging Stacking Members ...39 Configuring Stacking...40 Chapter 4: Initial Configuration ...43 Configuration Overview...44 Configuration ...45 Static IP Address and Subnet Mask ...45 User Name ...46 Chapter 5: Troubleshooting ...47...
-
Page 9: Chapter 1: Overview
“Model Descriptions” on page 12 “Port Descriptions” on page 15 “LED Definitions” on page 16 AT-8000GS/24 Gigabit Ethernet Switch with 24 10/100/1000 Base-T ports with 4 1000Base-X SFP combo ports and 2 HDMI interface stacking ports. AT-8000GS/24POE Gigabit Ethernet Switch with 24 10/100/1000... -
Page 10: At-8000Gs Switch Series Features
Chapter 1: Overview AT-8000GS Switch Series Features The AT-8000GS/24, AT-8000GS/24POE, and AT-8000GS/48 features include the following: Wire speed switching traffic across all ports Auto MDI/MDIX enabled Jumbo frames 802.1d, 1w, 1s priority tags supported Broadcast storm control IEEE 802.1Q tagged VLANs supported... -
Page 11: Ieee Standards
AT-8000GS Series Gigabit Ethernet Switch Installation Guide IEEE Standards IEEE 802.3 — 10Base-T IEEE 802.3u — 100Base-TX IEEE 802.3ab — 1000Base-TX Gigabit Ethernet IEEE 802.3z — Full Duplex IEEE 802.3u — Auto-Negotiation IEEE 802.3x — Flow Control, Symmetric and Asymmetric... -
Page 12: Model Descriptions
Chapter 1: Overview Model Descriptions AT-8000GS/24 The following figure illustrates the AT-8000GS/24 front panel. The AT-8000GS/24 front panel is configured as follows: The following figure illustrates the AT-8000GS/24 back panel. The AT-8000GS/24 back panel is configured as follows: AT-8000GS/24 Gigabit Ethernet Switch Front Panel Figure 1 24 10/100/1000Mbps ports —... -
Page 13: At-8000Gs/24Poe
AT-8000GS/ The following figure illustrates the AT-8000GS/24POE front panel. 24POE Figure 3 The AT-8000GS/24POE front panel is configured as follows: 24 10/100/1000Mbps ports — RJ-45 ports designated as 10/100/ 1000Base-T. The RJ-45 ports are designated as Ports 1-24. 4 SFP Ports — There are four 1000Base-X SFP combo ports. These ports are associated with the RJ-45 copper ports: 21, 22, 23 and 24. -
Page 14: At-8000Gs/48
Chapter 1: Overview AT-8000GS/48 The following figure illustrates the AT-8000GS/48 front panel. The AT-8000GS/48 device front panel is configured as follows: The following figure illustrates the AT-8000GS/48 back panel. The AT-8000GS/48 back panel is configured as follows: AT-8000GS/48 Gigabit Ethernet Switch Front Panel Figure 5 10/100/1000Base-T Ports 10/100/1000Base-T Ports... -
Page 15: Port Descriptions
Port Descriptions 10/100/1000 Base- The 10/100/1000Base-T Gigabit ports are RJ-45 ethernet connectors. The 10/100/1000 Mbps ports support half- and full-duplex mode. T Gigabit Ethernet Ports SFP Port Small Form Factor Pluggable (SFP) Optical Transceivers are integrated duplex data links for bi-directional communication over optical fiber, designed for high-speed Fiber Channel data links. -
Page 16: Led Definitions
“Mode LEDs” on page 18 — These LEDs indicates the functional information that the RJ-45 port LED displays. These LEDs are only found on front panels of the AT-8000GS/24 Gigabit Ethernet Switch and AT-8000GS/48 Gigabit Ethernet Switch. Port LEDs — These LEDs indicate each port’s status. There are... -
Page 17: Stacking Port Leds
Power LED The PWR LED on the front panel of the device indicates the power supply status. The power supply port LED indications are described in the following table: Description Power SYS LED The SYS LED on the front panel of the device indicates the diagnostic results. -
Page 18: Mode Leds
RJ-45 port Mode LED. For example, if the mode selected is "COL", then the LED on each port indicates the collision status of that port. See “RJ-45 Port LEDs on AT-8000GS/24 & AT-8000GS/48” on page 19 for the location of the RJ-45 MODE LED on each port. -
Page 19: Port Leds On At-8000Gs/24 & At-8000Gs/48
RJ-45 Port LEDs Figure 10 on page 20 illustrates the RJ-45 port LEDs for the AT-8000GS/ 24 Gigabit Ethernet Switch and AT-8000GS/48 Gigabit Ethernet Switch. on AT-8000GS/24 & AT-8000GS/48 AT-8000GS Series Gigabit Ethernet Switch Installation Guide Front Panel Mode Selection LEDs... - Page 20 Each non-POE RJ-45 port has two LEDs, one for Link and one for Mode status. The Link and Mode Port LED indications are described in the following table: Table 6 Port LED Mode/Indications for AT-8000GS/24 & AT-8000GS/48 Port Left Right...
-
Page 21: Port Leds At-8000Gs/24Poe
RJ-45 Port LEDs Figure 11 on page 21 illustrates the 10/100/1000 Base-T RJ-45 port LEDs for the AT-8000GS/24POE Gigabit Ethernet Switch. AT-8000GS/ 24POE Each RJ-45 port on the AT-8000GS/24POE Gigabit Ethernet Switch has two LEDs, one for Link/Activity and one for POE status. The LED indications are described in the following table: Description Left LED -... -
Page 22: Sfp Port Leds
Chapter 1: Overview SFP Port LEDs The following figure illustrates the SFP port LEDs. The SFP ports have one LEDs for link and activity. The LED indications are described in the following table: Description LED- Link / SFP Port LEDs Figure 12 Table 8 SFP Port LED Indications Port... -
Page 23: Stacking Port Leds
Stacking Port The Stacking LEDs are located on the rear panel. The following figure illustrates the Stacking port LEDs. LEDs Figure 13: Stacking Port LEDs The HDMI ports have two LEDs, one is for Link and one is for Activity. The Stacking LEDs indications are described in the following table: Port Description... - Page 24 Chapter 1: Overview...
-
Page 25: Chapter 2: Installation
Chapter 2 Installation This chapter contains information for installing the device, and includes the following sections: “Reviewing Safety Precautions” on page 26 “Preparing for Installation” on page 29 “Installing the Device” on page 32 “Connecting the Device” on page 34... -
Page 26: Reviewing Safety Precautions
Note indicates that a translation of the safety statement is available in a PDF document titled “Translated Safety Statements” (613-000990) on the Allied Telesis website at www.alliedtelesis.com. Warning: Class 1 Laser product. Warning: Do not stare into the laser beam. - Page 27 AT-8000GS Series Gigabit Ethernet Switch Installation Guide Warning: Operating Temperature. This product is designed for a maximum ambient temperature of 40° degrees C. All Countries: Install product in accordance with local and National Electrical Codes. Circuit Overloading: Consideration should be given to the connection of the equipment to the supply circuit and the effect that overloading of circuits might have on overcurrent protection and supply wiring.
- Page 28 Chapter 2: Installation Warning: To reduce the risk of electric shock, the ports on this product must not connect to cabling that is routed outside the building where this device is located. Caution: The unit does not contain serviceable components. Please return damaged units for servicing.
-
Page 29: Preparing For Installation
Preparing for Installation This section provides an explanation for preparing the installation site, and includes the following topics: “Installation Precautions” on page 29 “Site Requirements” on page 30 “Unpacking” on page 30 Installation Please review the the following saftey precautions before you begin to install the AT-8000- XX Ethernet switch. -
Page 30: Site Requirements
Chapter 2: Installation Site The device should be placed on a table-top. Before installing the unit, verify that the location chosen for installation meets the following site requirements. Requirements Unpacking This section contains information for unpacking the device, and includes the following topics: Package Contents While unpacking the device, ensure that the following items are included:... - Page 31 To unpack the device perform the following: It is recommended to put on an ESD wrist strap and attach the ESD clip to a metal surface to act as ground. An ESD strap is not supplied with the device. Place the container on a clean flat surface and cut all straps securing the container. Open the container.
-
Page 32: Installing The Device
Chapter 2: Installation Installing the Device The device can be installed on a flat surface or mounted in a rack. This section includes the following topics: Desktop or Shelf When installing the switch on a desktop or shelf, the rubber feet included with the device should first be attached. - Page 33 • Disconnect all cables from the unit before mounting the device in a rack or cabinet. • When mounting multiple devices into a rack, mount the devices from the bottom up. To install the device in a rack, perform the following: It is recommended to put on an ESD wrist strap and attach the ESD clip to a metal surface to act as ground.
-
Page 34: Connecting The Device
Chapter 2: Installation Connecting the Device This section describes how to connect the device, and includes the following sections: Connecting the The device is connected to a terminal through a console port on the back panel of the 24/ 48 port devices. The console connection which enables a connection to a terminal desktop Switch to a system running a terminal emulation software for monitoring and configuring the device. -
Page 35: Chapter 3: Stacking
Chapter 3 Stacking This section describes the stacking control management and includes the following topics: “Stacking Overview” on page 36 “Configuring Stacking” on page 40... -
Page 36: Stacking Overview
Chapter 3: Stacking Stacking Overview Stacking provides multiple switch management through a single point as if all stack members are a single unit. All stack members are accessed through a single IP address through which the stack is managed. The stack can be managed using the following interfaces: Devices support stacking up to six units per stack, or can operate as stand-alone units. -
Page 37: Stacking Chain Topology
automatically switches to a Stacking Failover topology without any system downtime. An SNMP message is automatically generated, but no stack management action is required. However, the stacking link or stacking member must be repaired to ensure the stacking integrity. After the stacking issues are resolved, the device can be reconnected to the stack without interruption, and the Ring topology is restored. - Page 38 Chapter 3: Stacking manually configured as the Stacking Master, the manually configured member is elected Stacking Master. If two Master-enabled units are present and neither has been manually configured as the Stacking Master, the one with the longer up-time is elected Stacking Master.
-
Page 39: Exchanging Stacking Members
Units are reassigned Unit IDs Units toggle between Stacking mode and Stand-alone mode Each time the system reboots, the Startup configuration file in the Master unit is used to configure the stack. If a stack member is removed from the stack and then replaced with a unit with the same Unit ID, the stack member is configured with the original device configuration. -
Page 40: Configuring Stacking
Chapter 3: Stacking Configuring Stacking Configuring stacking is performed during the bootup process. To configure a device as part of a stack, the bootup process must be interrupted straight after the Power On Self Test (POST). To configure the device for stacking, perform the following: Autoboot in 2 seconds -press RETURN or Esc.to abort and enter prom. - Page 41 The Startup Menu is displayed and contains the following configuration functions: Startup Menu [1] Download Software [2] Erase Flash File [3] Password Recovery Procedure [4] Enter Diagnostic Mode [5] Set Terminal Baud-Rate [6] Stack menu [7] Back Enter your choice or press 'ESC' to exit: From the Startup Menu, press “6”.
- Page 42 Chapter 3: Stacking...
-
Page 43: Chapter 4: Initial Configuration
Chapter 4 Initial Configuration This chapter contains information for installing the device, and includes the following sections: “Configuration Overview” on page 44 “Configuration” on page 45... -
Page 44: Configuration Overview
Chapter 4: Initial Configuration Configuration Overview Before assigning a static IP address to the device, obtain the following information from the network administrator: There are two types of configuration: Initial configuration consists of configuration functions with basic security considerations, whereas advanced configuration includes dynamic IP configuration and more advanced security considerations. -
Page 45: Configuration
Configuration The initial configuration, which starts after the device has booted successfully, includes static IP address and subnet mask configuration, and setting user name and privilege level to allow remote management. If the device is to be managed from an SNMP-based management station, SNMP community strings must also be configured. -
Page 46: User Name
Chapter 4: Initial Configuration illustrated in the following example. User Name A user name is used to manage the device remotely, for example through SSH, Telnet, or the Web interface. To gain complete administrative (super-user) control over the device, the highest privilege (15) must be specified. -
Page 47: Chapter 5: Troubleshooting
Chapter 5 Troubleshooting This chapter contains information on how to troubleshoot the switch in the event that a problem occurs. Device not Check the PWR LED on the front of the switch. If the LED is OFF, indicating that the unit is not receiving power, do the following: operating correctly... -
Page 48: Forgot Or Lost The Password
Chapter 5: Troubleshooting Be sure the management station has an IP address in the same subnet as the switch’s IP interface to which it is connected. If you are trying to connect to the switch via the IP address for a tagged VLAN group, your management station, and the ports connecting intermediate switches in the network, must be configured with the appropriate tag. -
Page 49: Appendix A: Technical Specifications
Appendix A Technical Specifications Physical Specifications The different devices have the following physical specifications: Weight Environmental Specifications AT-AT-8000/24 — 440 x 257 x 43.2 mm (W x D x H) AT-AT-8000/24POE — 440 x 257 x 43.2 mm (W x D x H) AT-AT-8000/48—... -
Page 50: Power Specifications
For each station, the appropriate mode (Half/Full Duplex, Auto) is set. AT-8000GS/24 — 100-240 VAC, 1.0 A, 50/60 Hz, 65W max AT-8000GS/48 — 100-240 VAC, 1.5 A, 50/60 Hz, 125W max AT-8000GS/24POE —... -
Page 51: Pin Connections For The 10/100/1000 Ethernet Interface
AT-9400 Series Gigabit Ethernet Switches Installation Guide Pin Connections for the 10/100/1000 Ethernet Interface The following figure illustrates the pin allocation for the RJ-45 10/100/1000 Ethernet connectors. Figure 1: RJ-45 Pin Allocation... - Page 52 Appendix A: Technical Specifications...
