Rugged Ridge 13592 Series Manual

Jeep® JK Wrangler Roll Bar Island Topper ( 4dr )
Contents:
1. Island Topper
(Roll Bar Top)
Caution - This product is designed to enhance the appearance of the vehicle and to shield the
occupants from ordinary weather conditions, DO NOT rely on product to contain occupants
within the vehicle, or to protect against injury or death in the event of an accident. This
top will not protect the occupants from falling objects. Never operate vehicle in excess of
manufacture's specification. SEAT BELTS ARE TO BE WORN AT ALL TIMES.
Before installing Summer Top read installation instructions. Failure to do so may result in a poor tting top
and could place occupants in a potentially dangerous situation. After installation of summer to, check to
make sure it has been properly secured before driving.
(Step 1) - Insert windshield header into top as shown. This top will work with most aftermarket (JK)
headers. Brand of aftermarket header should not affect fitment.
(Step 2) - Place header and top onto windshield channel. Follow manufactures installation instructions for
header.
(Step 3) - Place Island topper over center roll bar and loop center swivel hooks around the back side of
speaker bar. Push swivel hooks up into center roll bar (Freedom top mounting holes). Do Not
tighten straps at this time. Pull straps tight enough to only keep top in place.
(Step 1)
(Step 2)
Page 1 of 3
Part Number: 13592.XX
(Step 3)
