INSTALLATION & OPERATION MANUAL
ENERGY STORAGE SYSTEM (ESS)
Storion-SMILE-B3
V12
Advertisement
Table of Contents
Related Manuals for AlphaESS Storion-SMILE-B3
Summary of Contents for AlphaESS Storion-SMILE-B3
- Page 1 @AlphaESS www.alphaess.com ENERGY STORAGE SYSTEM (ESS) Alpha ESS Co., Ltd. Alpha ESS Suzhou Co., Ltd. +86 513 8060 6891 +86 512 6828 7609 Storion-SMILE-B3 info@alpha-ess.com info@alpha-ess.com www.alphaess.com www.alphaess.com JiuHua Road 888, Nantong High-Tech Building 10-A, Canal Town Industrial Park, Industrial Development Zone, Nantong City,...
-
Page 2: Table Of Contents
2.1 Parts List 2.2 System Appearance 2.3 Limitation of Liability 2.4 System Installation 2.4.1 Installation Site and Environment 2.4.2 Installation Tools 2.4.3 Storion-SMILE-B3 Installation 2.4.4 Battery Expansion 2.4.5 Electricity Meter Wiring EMS INSTRUCTION 3.1 Switch On 3.2 Switch Off 3.3 Emergency Procedure 3.3.1 Emergency Handling Plan... -
Page 3: Introduction
1.1 System Introduct on DANGER Storion-SMILE-B3 is an AC coupled all-in-one battery energy storage system (BESS). It Danger to life due to high voltages of battery and electric shock. can help to achieve the optimal usage of renewable energy. Storion-SMILE-B3 can control the bi-directional flow of electric power, work under auto/manual &... -
Page 4: Installation
INSTALLATION INSTALLATION INSTALLATION 2.2 System Appearance 2.1 Parts List Check the following parts list for completeness. AlphaESS provides a complete set of system for on-site customers, including: Table 1 Parts List of B3 Normal Fault SMILE5-B3 Battery Display 2 x M4*12 screw Figure 2.1 Storion-SMILE-B3 Exterior View... -
Page 5: Limitation Of Liability
INSTALLATION INSTALLATION 2.3 Limitation of Liability Table 5 Storion-SMILE-B3 WIFI (Yilian) Display AlphaESS shall not be liable directly or indirectly for any product damage or property loss Status Description caused by any of the following conditions. The product has been modified, the design modification or the change of parts without Normally on: normally communicate with EMS the authorization of AlphaESS;... -
Page 6: Installation Site And Environment
Figure 2.6 Remove Storion-SMILE-B3 Packaging t. The product is to be installed in a high traffic area where the fault is likely to be seen. Step 1 Take out Storion-SMILE-B3 from the packaging box, as shown in Figure 2.6 NOTE: NOTE: Please check whether the parts quantity is consistent with the parts list a ~ e rules are set according to AS/NZS5139. - Page 7 fixed at each of the four corners. And please use leveling instrument to confirm that the hang-ing bracket is installed on a Step 6 Install Storion-SMILE-B3 on the wall bracket, as shown in Figure 2.11. horizontal line to ensure that the equipment will not deflect.
- Page 8 INSTALLATION INSTALLATION Step 8 Conditions for the AC Connection WIFI AC breakers must be installed on the AC side of the Storion-SMILE-B3 to ensure that the COM1 Grid system can be safely disconnected from the power grid and the load.
-
Page 9: Battery Expansion
The system and the Demand Figure 2.18 Parts List of M4856-P Accessory Package Response Enabling Device (DRED) must be connected in the same network. Only DRM0 is available for Storion-SMILE-B3. - Page 10 Figure 2.18 Figure 2.22 Install the Positioning Bracket Step 5 After installing the expansion bracket, match the wall bracket with Storion-SMILE-B3, Figure 2.19 Remove the Decoration of M4856-P use M5*10 screws to lock and fix, then locate and and trace.
- Page 11 1. Please use the leveling instrument to confirm the hanging bracket installed on a horizontal line to ensure the equipment not to be deflected. 2. If the positioner is not removed, Storion-SMILE-B3 can not be removed separately. Figure 2.27 Fix the Wall Bracket and the Expansion Bracket Step 10 If you want to install more battery modules, please take out the wall bracket and expansion bracket and fix them referring to Step 1- Step 3.
- Page 12 INSTALLATION INSTALLATION NOTE: It is not required to to fix the expansion bracket to the previous wall bracket, just place them together for positioning; and then remove the expansion bracket after tracing points. Figure 2.29 Holes for Fixing Bracket Figure 2.31 Install the Battery Step 12 Drill holes at the position using a percussion drill (M12 drill, depth of holes: 70mm).
- Page 13 INSTALLATION INSTALLATION Figure2.33 Remove the Maintenance Cover of M4856-P Step 16 Remove the maintenance cover (Figure 2.33) Figure 2.36 Connect the Negative Power Line Step 19 Connect negative power line for expansion (Figure 2.36). Figure 2.34 Confirm Circuit Breaker Status Step 17 Confirm that the status of circuit breaker is OFF.
- Page 14 Step 24 Install the maintenance cove with the torque being 2.8 N.m±10%. NOTE: If there is only one M4856-P to be connected, switch off the DIP2 in Storion-SMILE-B3 and switch on the DIP2 in M4856-P. If there are more than two batteries to be connected, please refer to DIP switch...
-
Page 15: Electricity Meter Wiring
The CTs connection is as shown in Figure 2.43.: NOTE: Please pay attention to the CT directions. Figure 2.43 CT Connection 2.4.5.2 Electricity Meter ADL-3000 (if optional) ADL-3000 connection (without CT, without Meterplug): AlphaESS Grid Meter PV Meter RS485 PIN RS485 PORT RS485 PORT AlphaESS... -
Page 16: Meter Setting
5.1.2. NOTE: This function is released in Storion-SMILE-B3 EMS firmware version V1.00.33 or above. In AC system and the mixed installation of CT and meter situation, the meter address should be also set in the meter, please refer to 2.4.5.5.1 (ADL3000) and 2.4.5.5.2 (ACR10R). -
Page 17: Operation
OPERATION Please double check the following before operation. 1. Storion-SMILE-B3 is firmly fastened to the mounting bracket on the wall; 2. The polarity of battery wires is correct, battery wires are firmly connected; Step 11 Click the "Enter" button and the setting ends. -
Page 18: Emergency Procedure
(Figure 4.1), and directly connect to Storion-SMILE-B3 by WiFi module. 3. Please record every detail related to the fault, so AlphaESS can analyse and solve the fault. Any operation of equipment during a fault is strictly forbidden, please contact Alpha as soon as possible. -
Page 19: System Registration
Installers who haven't yet registered need to click “Register” to visit the registration page. Please refer to “AlphaCloud Online Monitoring Webserver Installers User Manual”, Next which you can get from AlphaESS sales and get license number from relevant sales from Alpha ESS Submit Figure 4.7 WiFi Setting... -
Page 20: System Setup In Monitoring
After that you must specify whether you have installed a CT or an electricity meter (ADL3000 or ACR10R) and in the case of electricity meters, please further select with or The system settings of the Storion-SMILE-B3 must be carried in the installer without CT were connected. -
Page 21: Other Information
In this form, all fields with a red star - Time zone are compulsory, and you can select - Data upload frequency: Storion-SMILE-B3 has second level data, you can choose it as the finally users or installation 10s data if you wish. -
Page 22: Maintenance Checklist
Storion-SMILE-B3 VI status this check when the product is running. In this manual, the Storion-SMILE-B3 will represent all the model number of the energy storage system becasue they share the same topologic. 1. Cables should be securely Perform the first connected. -
Page 23: Appendix 3: Block Diagram
Appendix Appendix Appendix 4: Regional Application Standard Appendix 3: Block Diagram Please check with your local grid company and choose the correspond Regional Application Standard, the power quality modes Volt-VAR and Volt-Watt will be running automatically. (Only for regions with AS/NZW 4777.2 safety regulations). -
Page 24: Appendix 5: Technical Data
Appendix Appendix 5: Technical Data...
