AlphaESS SMILE-S5 Quick Installation Manual

64100186
QUICK INSTALLATION GUIDE
01 Product Overview
(1). Wi-Fi Port
(2). Grounding
(3). INV PV Switch
(2)
(4). INV PV Connectors
(3)
(5). Communication Ports
(4)
(6). Battery Breaker of Inverter
(5)
(7). Backup Connector
(6)
(8). Grid Connector
(7)
(9). Inverter LED Display
(8)
(10). Battery LED Display
(11). Battery Breaker
(12). Battery Power Switch
(13). Battery+ Power Connector
D
(14). Battery- Power Connector
(15). BMS COM Ports
02 Packing List
(X1) (X1) (X1)
(X1) (X1) (X1)
M4*12 (X5)
(X1)
M6*16 (X6)
03 Installation Tools
T20×150mm PH2×150mm
T20 Screwdriver Phillips Screwdriver
Network Wire Clamp Crimping Plier
5.1 Mount the PE cable
5.2 Connecting the Backup Power Cable
1
PE
N
L
4 to 6 mm²
L
AF2
N
0.8Nm
PE
3
1
Backup
SMILE-S5
(1)
*
(9)
H
(10) (13)
(14)
(15)
W
Dimension (W×H×D): 640×745×250mm
(X1) (X2)
Grid CT
(X1) (X1)
(X1)
(X8)
(X6) (X1)
1.2×75mm
Flat-Head Screwdriver Wire Stripper
Tape Measure
T20
2.5Nm
2
2 3
1
Click
2
V01
04 Mount the Product
1
1
2
(11)
(12)
05 Electrical Connections
RISK OF ELECTRIC SHOCK
(X2)
Before doing electrical connection, please ensure the PV switch & all AC and BAT circuit breakers
are switched OFF and cannot be reactivated.
DANGER
(X2)
You must protect each inverter with an individual grid/backup circuit breaker in order to ensure
that the inverter can be disconnected safely.
Description
Type
Grid Side
Backup Side
WARNING
The maximum allowable AC circuit breaker specification for grid side and backup side is 32A; meanwhile, the
cross section of the copper conductor must be 6mm², otherwise it would increase the danger of the circuit
breaker tripping under normal operating conditions.
NOTE:
Please see System Wiring Diagram for the detailed wiring method.
01 02
5.3 Connecting the Grid Power Cable
1
PE
N
L
6 mm²
PE
3
2
4
5
NOTE:
For the installation sites in Australia and New Zealand, the neutral cable of the grid side should be
connected in parallel to the backup side, or otherwise the backup output will fail to operate.
5.4 Connecting the PV Power Cable
1
7mm
7mm
4-6mm²
03 04
SW10
T20
≥ 1000mm*
*Depends on the quantity of the expansion batteries
3
T20
3Nm
M6*16(X6)
Max. Breaker Specification
S5
32A
32A
2
1
Click
L
AF2
N
0.8Nm
1
Grid
2
Click
2.6-2.9Nm
Click
(X6)
2 3
4
1 2
3
T20
2.5Nm
M4*12(X2)
2 3 4
5
3
Check the polarities of the PV strings
Ensure the open-circuit voltage of the
PV arrays is less than 600V.
