    CONTENT CONTENT DISCLAIMER ......................1 COPYRIGHT STATEMENT ................... 2 CONTENT ......................3 1. Function Overview ................... 4 2. AUX Interface Introduction ................4 2.1. Product model: SMILE5-INV/DE .............. 4 2.2. Product model: SMILE-B3 ................ 6 2.3. Product model: SMILE-T10 ..............6 2.4.

  • Page 5: Function Overview

    Function Overview 1. Function Overview The Aux contact is a passive switch with two statuses, closed and open. There is no polarity between the contacts. This function is designed to control the closing or opening of the contacts between the set conditions to achieve the effect of turning the load on or off.
  • Page 6 AUX Interface Introduction The pin definition of the Aux ports: The pin definition of the Aux ports:...

  • Page 7: Product Model: Smile-B3

    AUX Interface Introduction 2.2. Product model: SMILE-B3 The pin definition of the Aux ports: 2.3. Product model: SMILE-T10...

  • Page 8: Product Model: Smile-B3-Plus

    AUX Interface Introduction 2.4. Product model: SMILE-B3-PLUS The pin definition of the Aux ports: 2.5. Product model: SMILE-S5/B5 (AIO) Open the COM cover on the lower left of the inverter, as shown in the figure below.

  • Page 9: Product Model: Smile-S6-Inv-Hv

    AUX Interface Introduction The pin definition of the Aux ports: 2.6. Product model: SMILE-S6-INV-HV Open the COM cover on the middle left of the inverter, as shown in the figure below.

  • Page 10: Product Model: Smile-T10-Hv-Inv

    AUX Interface Introduction The pin definition of the Aux ports: 2.7. Product model: SMILE-T10-HV-INV Open the COM cover at the bottom of the inverter, as shown in the figure below.
  • Page 11 AUX Interface Introduction The pin definition of the Aux ports: The pin definition of the Aux ports:...

  • Page 12: Product Model: Smile-G3-S5/S3.6/B5-Inv

    AUX Interface Introduction 2.8. Product model: SMILE-G3-S5/S3.6/B5-INV Open the COM cover on the lower left of the inverter, as shown in the figure below. The pin definition of the Aux ports: Take the green terminal and connect it to the corresponding Aux ports. Close the Inner cover or COM Cover.

  • Page 13: Aux Contact Settings

    AUX Contact Settings 3. AUX Contact Settings After wiring the Aux contact, its function can be set on AlphaCloud or APP. 3.1. Setting process 1. Open the monitoring website. 2. Click “System setup” and click “AUX Contact setting”. The following interface will appear: 3.
  • Page 14 AUX Contact Settings a. Control Mode On When Control Mode ON is selected, the normally open contact will close during the set time period. Outside the time period, the normally open contact will stay open. If you don’t set a time period, this function won’t work. In this mode, the normal self-consumption logic will be applied.
  • Page 15 AUX Contact Settings c. Control Mode Auto When Control Mode AUTO is selected, normally open and normally closed contact will be triggered according to the settings below. After setting, the period control function will not work. When the SOC is set to ">=" mode, the Aux contact of the load needs to be connected to the N/O point.
  • Page 16 AUX Contact Settings In this mode, the normal self-consumption logic will be applied.
