ox-m24c VESA adapter
Assembly
instructions
The VESA adapter is compatible with the following products MSI
(msi.com)
Modern series compatible:
Optix MAG240VC, Optix MAG24C, Optix MAG270CR, Optix MAG270VC,
Optix MAG271VCR, Optix MAG27C, Optix MAG27CQ
With the VESA adapter, you can easily attach your MSI monitor to a monitor arm
with a VESA hole pattern (100 x 100mm). Use the supplied screws and nuts for
this.
Direct wall mounting is NOT possible, as the VESA adapter already contains metric
threads through which no screws can be inserted for mounting to the wall.
www.3idee.eu
