ox-mag VESA adapter
Assembly
instructions
The VESA adapter is compatible with the following products from MSI
(msi.com)
compatible:
Optix AG321CQRDE, Optix MAG301CR2, Optix MAG342CQR, Optix
MAG342CQRV, Optix MAG342CQRVDE
The VESA adapter allows you to conveniently mount your MSI brand monitor to a
monitor arm with a VESA hole pattern (75 x 75mm). Use the included screws and
nuts for this.
If you want to mount your VESA adapter directly to the wall, use suitable screws
and dowels. (not included in the scope of delivery)
www.3idee.eu
Advertisement
Table of Contents
Related Manuals for 3idee ox-mag
Summary of Contents for 3idee ox-mag
- Page 1 VESA adapter Assembly instructions The VESA adapter is compatible with the following products from MSI (msi.com) compatible: Optix AG321CQRDE, Optix MAG301CR2, Optix MAG342CQR, Optix MAG342CQRV, Optix MAG342CQRVDE The VESA adapter allows you to conveniently mount your MSI brand monitor to a monitor arm with a VESA hole pattern (75 x 75mm).
- Page 2 Assembly instructions Horizontal / Vertical Alignment Not all VESA adapters and monitors are suitable for vertical alignment. This is due to the geometry of the adapter / monitor, which is sometimes not otherwise feasible. We would like to point out that this information should not be disregarded in any case, because the adapter comes very quickly to its durability limit if the mounting is not specified.
- Page 3 Assembly instructions Important Safeguards Please read these instructions carefully and keep them for future reference. If you pass the product on to third parties, these instructions should also always be given. Failure to follow these instructions may result in injury or damage to people and the product, for which we cannot accept any liability.
- Page 4 For the disposal of this product we recommend to contact the responsible local authorities or disposal services. They can provide you with detailed information on available disposal options and recycling centers in your area. 4. Manufacturer Information 3idee Technologies S.à r.l. 5 Um Lenster Bierg L-6125 Junglinster Luxembourg 5.
- Page 5 Assembly instructions Assembly instruction Step 1 Place your MSI monitor on a safe, soft surface to avoid damaging it during installation. Take the M4x20 screws (screw bag SP14) and attach the VESA adapter to the back of your monitor using a screwdriver.
- Page 6 Assembly instructions Step 4 Please make sure that all 4 screws are tight. (Figure 4) Figure 4...
