ox-g27 VESA adapter
Assembly
instructions
The VESA adapter is compatible with the following products from MSI
(msi.com)
compatible:
G271C-E2, G271CP E2, G271CQP E2, G271CQR E2, Optix G271C, Optix
G271CP, Optix G271CQP, Optix G274, Optix G274R, Optix G274RW, Optix
G321C, Optix G321CQP
With the VESA adapter, you can easily attach your MSI monitor to a monitor arm
with a VESA hole pattern (100 x 100mm). Use the supplied screws and nuts for
this.
Direct wall mounting is NOT possible, as the VESA adapter already contains metric
threads through which no screws can be inserted for mounting to the wall.
www.3idee.eu
Advertisement
Table of Contents
Related Manuals for 3idee ox-g27
Summary of Contents for 3idee ox-g27
- Page 1 VESA adapter Assembly instructions The VESA adapter is compatible with the following products from MSI (msi.com) compatible: G271C-E2, G271CP E2, G271CQP E2, G271CQR E2, Optix G271C, Optix G271CP, Optix G271CQP, Optix G274, Optix G274R, Optix G274RW, Optix G321C, Optix G321CQP With the VESA adapter, you can easily attach your MSI monitor to a monitor arm with a VESA hole pattern (100 x 100mm).
-
Page 2: Important Safeguards
Assembly instructions Important Safeguards Please read these instructions carefully and keep them for future reference. If you pass the product on to third parties, these instructions should always be included. Failure to follow these instructions may result in injury or damage to persons or the product, for which we cannot accept any liability. -
Page 3: Waste Disposal
For the disposal of this product we recommend to contact the responsible local authorities or disposal services. They can provide you with detailed information on available disposal options and recycling centers in your area. 4. Manufacturer Information 3idee S.à r.l. 19 Rue de Bitbourg L-1273 Luxembourg Luxembourg mail: info@3idee.eu... -
Page 4: Scope Of Delivery Accessories
Assembly instructions Scope of Delivery Accessories 4x M4x14 screw with cross recess 4x M4x25 screw with cross recess (SP2) (SP41) -
Page 5: Horizontal Mounting
Assembly instructions Horizontal / Vertical Alignment Please note: Not all VESA adapters and monitors are designed for vertical (upright) orientation. This limitation is often due to the specific geometry of the adapter or monitor. Do not ignore this information, as the load limit of the adapter can quickly be exceeded if not installed properly. We are continuously working on developing monitors and adapters that are also suitable for vertical orientation. -
Page 6: Assembly Instruction
Assembly instructions Assembly Instruction Step 1 Take the SP41 screw bag with the 4 screws and attach the adapter to the back of your monitor (Figure 1) Figure 1 Step 2 Check that all screws have been tightened correctly. (Figure Figure 2 Step 3 ⚠... - Page 7 Assembly instructions Step 4 Make sure that you have correctly screwed in and tightened all screws. (Figure 4) Figure 4...
