114, 115, and 117
True-rms Multimeters
Users Manual
PN 2572573
July 2006, Rev. 1, 2/07
© 2006, 2007 Fluke Corporation, All rights reserved. Printed in China
All product names are trademarks of their respective companies.

Advertisement

loading
Need help?

Need help?

Do you have a question about the FLUKE-117/323KIT and is the answer not in the manual?

Questions and answers

Related Manuals for Fluke FLUKE-117/323KIT

Summary of Contents for Fluke FLUKE-117/323KIT

  • Page 1 ® 114, 115, and 117 True-rms Multimeters Users Manual PN 2572573 July 2006, Rev. 1, 2/07 © 2006, 2007 Fluke Corporation, All rights reserved. Printed in China All product names are trademarks of their respective companies.

  • Page 2: Limited Warranty And Limitation Of Liability

    LIMITED WARRANTY AND LIMITATION OF LIABILITY This Fluke product will be free from defects in material and workmanship for three years from the date of purchase. This warranty does not cover fuses, disposable bat- teries, or damage from accident, neglect, misuse, alteration, contamination, or abnor- mal conditions of operation or handling.
  • Page 3 True-rms Multimeters Introduction Unsafe Voltage The Fluke Model 114, Model 115, and Model 117 are To alert you to the presence of a potentially hazardous voltage, the Y symbol is displayed when battery-powered, true-rms multimeters (hereafter "the the Meter measures a voltage ≥30 V or a voltage Meter") with a 6000-count display and a bar graph.
  • Page 4 114, 115, and 117 Users Manual Safety Information A "XWWarning" statement identifies hazardous conditions and actions that could cause bodily harm or death. A "WCaution" statement identifies conditions and actions that could damage the Meter or the equipment under test. To avoid possible electric shock or personal injury, follow these guidelines: •...
  • Page 5 Double Insulated Hazardous voltage Important Information; Refer to manual Battery (Low battery when shown on the Earth ground display.) Do not dispose of this product as unsorted AC and DC municipal waste. Contact Fluke or a qualified recycler for disposal.
  • Page 6 114, 115, and 117 Users Manual Display VoltAlert edy02f.eps Symbol Meaning Model The Meter is in the VoltAlert™ non-contact voltage detect mode. The Meter function is set to Continuity. 114, 115, & 117 The Meter function is set to Diode Test 115 &...
  • Page 7 True-rms Multimeters Display Display hold enabled. Display freezes present reading. 114, 115, & 117 MIN MAX AVG mode enabled. 114, 115, & 117 Maximum, minimum, average or present reading displayed (Red LED) Voltage presence through the non-contact VoltAlert sensor The Meter is measuring voltage or capacitance with a low input 114, 115 &...
  • Page 8 114, 115, and 117 Users Manual Terminals 10 A FUSED edy01f.eps Description Model Input terminal for measuring ac and dc current to 10 A. 115 & 117 Common (return) terminal for all measurements. 114, 115, & 117 Input terminal for measuring voltage, continuity, resistance, capacitance, 114, 115, &...

  • Page 9: Rotary Switch Positions

    True-rms Multimeters Rotary Switch Positions Rotary Switch Positions Switch Measurement Function Model Position Automatically selects ac or dc volts based on the sensed input with a low 114 & 117 impedance input. AC voltage from 0.06 to 600 V. 114, 115 & 117 Frequency from 5 Hz to 50 kHz.
  • Page 10 114, 115, and 117 Users Manual Battery Saver ("Sleep Mode") Display HOLD XWWarning The Meter automatically enters "Sleep mode" and blanks the display if there is no function change, range change, or To avoid electric shock, when Display button press for 20 minutes. Pressing any button or HOLD is activated, be aware that the turning the rotary switch awakens the Meter.

  • Page 11: Power-Up Options

    True-rms Multimeters Power-Up Options When you turn the Meter on, it defaults to Autorange and Button Power-Up Options Auto is displayed. 1. To enter the Manual Range mode, press Turns on all display segments. Manual is displayed. Disables beeper. bEEP is displayed when 2.
  • Page 12 114, 115, and 117 Users Manual Measuring Resistance Testing for Continuity edy06f.eps Note edy04f.eps XWWarning The continuity function works best as a fast, To avoid electric shock, injury, or convenient method to check for opens and damage to the Meter, disconnect shorts.

  • Page 13: Making Basic Measurements

    True-rms Multimeters Making Basic Measurements This function also sets the Meter’s input impedance to Measuring AC and DC Voltage approximately 3 kΩ to reduce the possibility of false Volts AC Volts DC readings due to ghost voltages. Measuring AC and DC Millivolts Millivolts AC Millivolts DC edy03f.eps...
  • Page 14 114, 115, and 117 Users Manual Measuring AC or DC Current (115 & 117) XWWarning To avoid personal injury or damage to the Meter: • Never attempt to make an in-circuit current measurement when the open- circuit potential to earth is >600 V.
  • Page 15 Meter. Make sure the Meter has the correct function selected, AC or DC, for your current probe. Refer to a Fluke catalog or contact your local Fluke representative for compatible current clamps. edy05f.eps...
  • Page 16 114, 115, and 117 Users Manual Press g to turn the frequency measurement function Measuring Frequency (115 & 117 only) on and off. Frequency works with ac functions only. XWWarning In frequency, the bar graph and range annunciator indicate To avoid electrical shock, disregard the bar the ac voltage or current present.
  • Page 17 True-rms Multimeters Making Basic Measurements To detect the presence of ac voltage, place the top of the Testing Diodes (115 & 117) Meter close to a conductor. The Meter gives an audible as Good Diode Good Diode well as visual indication when voltage is detected. There are two sensitivity settings.
  • Page 18 114, 115, and 117 Users Manual Using the Bargraph Testing the Fuse (115 & 117 only) The bar graph is like the needle on an analog meter. It has Test fuse as shown below. an overload indicator (>) to the right and a polarity indicator (+)to the left.

  • Page 19: Maintenance

    True-rms Multimeters Maintenance Maintenance Maintenance of the Meter consists of battery and fuse replacement, as well as case cleaning. Replacing the Battery and Fuse XWWarning To avoid shock, injury, or damage to the Meter: • Remove test leads from the Meter before opening the case or battery door.
  • Page 20 5. Remove the fuse from its holder and replace it with an 11 A, 1000 V, FAST fuse having a minimum interrupt rating of 17,000 A. Use only Fluke PN 803293. 6. To re-assemble the Meter, first attach the case bottom to the case top, then install the two screws.

  • Page 21: General Specifications

    Surge Protection ............. 6 kV peak per IEC 61010-1 600V CAT III, Pollution Degree 2 W Fuse for A input (115 & 117 only): ....11 A, 1000 V FAST 17 kA Fuse (Fluke PN 803293) Display ..............Digital: 6,000 counts, updates 4/sec Bar Graph: 33 segments, updates 32/sec Temperature.............
  • Page 22 114, 115, and 117 Users Manual Certifications ............UL, , CSA, TÜV, N10140), VDE IP Rating (dust and water protection) IP42 ......Table 1. Accuracy Specifications Accuracy Function Range Resolution Model ± ([% of Reading] + [Counts]) 114, DC millivolts 600.0 mV 0.1 mV 0.5 % + 2 115, 117...
  • Page 23 True-rms Multimeters General Specifications Table 1 Accuracy Specifications (cont.) Accuracy Function Range Resolution Model ± ([% of Reading] + [Counts]) Beeper on < 20 Ω, off > 250 Ω; 114, 115, 600 Ω 1 Ω Continuity detects opens or shorts of 500 μs or longer.
  • Page 24 114, 115, and 117 Users Manual Table 1 Accuracy Specifications (cont.) Accuracy Function Range Resolution Model ± ([% of Reading] + [Counts]) 6.000 A 0.001 A AC Amps True- 10.00 A 0.01 A 1.5 % + 3 115, 117 20 A for 30 seconds max., (45 Hz to 500 Hz) 10 minutes rest min.
  • Page 25 True-rms Multimeters General Specifications Table 2. Input Characteristics Input Impedance Common Mode Rejection Ratio Normal Mode Function (Nominal) (1 kΩ Unbalanced) Rejection Volts AC >5 MΩ <100 pF >60 dB at dc, 50 or 60 Hz >10 MΩ <100 pF >100 dB at dc, 50 or 60 Hz >60 dB at 50 or 60 Volts DC...
  • Page 26 114, 115, and 117 Users Manual...
  • Page 27 323/324/325 Clamp Meter Users Manual May 2012 Rev.1, 06/15 © 2012-2015 Fluke Corporation. All rights reserved. Specifications are subject to change without notice. All product names are trademarks of their respective companies.
  • Page 28 LIMITED WARRANTY AND LIMITATION OF LIABILITY This Fluke product will be free from defects in material and workmanship for two years from the date of purchase. This warranty does not cover fuses, disposable batteries, or damage from accident, neglect, misuse, alteration, contamination, or abnormal conditions of operation or handling.

  • Page 29: Table Of Contents

    Table of Contents Title Page Introduction ......................... 1 How to Contact Fluke ....................1 Safety Information ...................... 2 How to Clean the Product ..................9 Specifications ......................10 Electrical Specifications ..................10 Mechanical Specifications ..................12 Environmental Specifications ................. 12...
  • Page 30 323/324/325 Users Manual...

  • Page 31: Introduction

    Introduction The Fluke 323/324/325 Clamp Meter (the Product) measures ac and dc voltage, ac current, resistance, and continuity. The 324 and 325 can also measure capacitance and contact temperature. The 325 can also measure dc current and frequency. Note that the 325 is shown in all of the illustrations.

  • Page 32: Safety Information

    Japan: +81-03-6714-3114 • Singapore: +65-6799-5566 • Anywhere in the world: +1-425-446-5500 Or, visit Fluke's website at www.fluke.com. To register your product, visit http://register.fluke.com. To see, print, or download the latest manual supplement, visit http://us.fluke.com/usen/support/manuals. Safety Information A Warning identifies conditions and procedures that are dangerous to the user. A Caution identifies conditions and procedures that can cause damage to the Product or the equipment under test.
  • Page 33 Clamp Meter Safety Information Warning To prevent possible electrical shock, fire, or personal injury: • Use the Product only as specified, or the protection supplied by the Product can be compromised. • Use only correct measurement category (CAT), voltage, and amperage rated probes, test leads, and adapters for the measurement.
  • Page 34 323/324/325 Users Manual • Do not apply more than the rated voltage, between the terminals or between each terminal and earth ground. • Comply with local and national safety codes. Use personal protective equipment (approved rubber gloves, face protection, and flame- resistant clothes) to prevent shock and arc blast injury where hazardous live conductors are exposed.
  • Page 35 Clamp Meter Safety Information • Connect the common test lead before the live test lead and remove the live test lead before the common test lead. • Remove all probes, test leads, and accessories before the battery door is opened. •...
  • Page 36 323/324/325 Users Manual • Remove batteries to prevent battery leakage and damage to the Product if it is not used for an extended period. • Remove batteries to prevent battery leakage and damage to the Product if is to be stored above its operating temperature. •...
  • Page 37 Clamp Meter Symbols Symbols Table 1. Symbols Symbol Meaning Symbol Meaning   AC (Alternating Current) Earth   DC (Direct Current) AC and DC Current Conforms to European Union   WARNING. RISK OF DANGER. directives.   Consult user documentation. Battery WARNING.
  • Page 38 323/324/325 Users Manual Table 1. Symbols (cont.) Symbol Meaning Symbol Meaning Measurement Category II is applicable to test and MEASUREMENT CATEGORY III is measuring circuits connected applicable to test and measuring directly to utilization points circuits connected to the distribution ...

  • Page 39: How To Clean The Product

    Clamp Meter How to Clean the Product Note The Measurement Category (CAT) and voltage rating of combinations of test probes, test probe accessories, current clamp accessories, and the Product is the LOWEST rating of individual components. How to Clean the Product Regularly wipe the case with a damp cloth and weak detergent.

  • Page 40: Specifications

    323/324/325 Users Manual Specifications Maximum voltage between any Terminal and Earth Ground ....600 V Range 323 ............ 400.0 A 324, 325 ..........(40.00, 400.0) A Batteries ..........2 AAA, NEDA 24A, IEC LR03 Operating Temperature ......-10 °C to +50 °C Storage Temperature ......
  • Page 41 Clamp Meter Specific ations Weight 323 ............. 265 g 324 ............. 208 g 325 ............. 283 g Safety ............IEC 61010-1, Pollution Degree 2 IEC 61010-2-032: CATIV 300V / CATIII 600V IEC 61010-2-033:CAT IV 300V / CAT III 600V IP Rating ..........IEC 60529: IP30, non-operating Electromagnetic Compatibility (EMC) International IEC 61326-1: Portable, Electromagnetic Environment, IEC 61326-2-2...

  • Page 42: Mechanical Specifications

    323/324/325 Users Manual Emissions that exceed the levels required by CISPR 11 can occur when the equipment is connected to a test object. Korea (KCC) Class A Equipment (Industrial Broadcasting & Communication Equipment) Class A: Equipment meets requirements for industrial electromagnetic wave equipment and the seller or user should take notice of it.
  • Page 43 Clamp Meter Specific ations DC Current with Jaw (325) Range ............. (40.00, 400.0) A Resolution ..........(0.01, 0.1) A Accuracy ..........2.0 % ± 5 digits AC Voltage Range ............. 600.0 V Resolution ..........0.1 V Accuracy (45 Hz– 400 Hz) ...... 1.5 % ± 5 digits DC Voltage Range ............
  • Page 44 323/324/325 Users Manual Continuity Beeper 323 ............ ≤70 Ω 324/325 ..........≤30 Ω Capacitance (324, 325) Range............(100.0, 1000) μF Resolution ..........(0.1, 1) μF Accuracy ..........1 % ±4 digits Frequency with Jaw (325) Range............5.0 to 500.0 Hz Resolution ..........

  • Page 45: The Meter

    Clamp Meter The Meter The Meter gtq008.eps...
  • Page 46 323/324/325 Users Manual MAXMIN 324/325 gtq001.eps...
  • Page 47 Clamp Meter The Meter 2:00 2:00 gtq002.eps...
  • Page 48 323/324/325 Users Manual 600 V 600 V 300 V 300 V 323, 324 TRUE RMS CLAMP METER TRUE RMS CLAMP METER 600 V 300 V 600 V 300 V gtq003.eps...
  • Page 49 Clamp Meter The Meter 323 V dc - 323 V ac - 324, 325 V dc & V ac - >30 V 300 V gtq004.eps...
  • Page 50 323/324/325 Users Manual 600 V 600 V 300 V 300 V TRUE RMS CLAMP METER TRUE RMS CLAMP METER 600 V 600 V 300 V 300 V <70 324/325 <30 gtq005.eps...
  • Page 51 Clamp Meter The Meter HOLD TRUE RMS CLAMP METER 600 V 300 V > 30 V 20 V AC/DC & ZERO ZERO ZERO ZERO 2 sec AC/DC AC/DC AC/DC gtq006.eps...
  • Page 52 323/324/325 Users Manual 324, 325 TRUE RMS CLAMP METER 600 V 300 V gtq009.eps...
  • Page 53 Clamp Meter The Meter gtq007.eps...
  • Page 54 323/324/325 Users Manual...
