Installing expansion cards
Follow the procedure below to install expansion cards.
Required tools
A small Phillips-head screwdriver.
How to install a PCI card
1.
Remove the computerÕs cover.
See ÒRemoving the coverÓ starting on page 38 for instructions.
Make sure the computer is powered down before removing the cover.
WARNING!
Touch the metal plate over the hard disk drive to discharge any static
CAUTION!
electricity that might have built up on your clothes or body.
The system must be plugged in (see step 1 on page 39) for this to work
Use an anti-static grounding strap and handle cards by the non-metallic
edges only.
2.
Select an unoccupied slot on the riser card.
3.
Remove the metal slot cover from the back of the chassis for the slot you
want to use.
For Technical Support, Call 1-800-708-6227
All manuals and user guides at all-guides.com
Installing PCI Expansion Cards
PowerCenter MT UserÕs Guide
.
43
