6.
Gently lay the computer on its side as shown in the next step.
7.
Remove the two Phillips-head screws from the upper corners of the base
and put them where you will be able to Þnd them later.
These Phillips-head screws are for the base only; donÕt use the Phillips screws for the
cover, or the thumb screw for the base.
Phillips-head
screws
8.
Remove the base and set it aside.
For Technical Support, Call 1-800-708-6227
All manuals and user guides at all-guides.com
Installing PCI Expansion Cards
PowerCenter MT UserÕs Guide
41
