  • Page 1 XG2600 Hardware Guide Introduction TA41001-7426 Hardware Guide...

  • Page 2: Preface

    XG2600 Hardware Guide Preface You have purchased the XG2600, a compact, 26 port 10 Gigabit Ethernet layer 2 switch that achieves unsurpassed standards of high throughput and low-latency performance. This manual explains the procedures required to install your XG2600 and should be read and understood before you start using your XG2600.

  • Page 3: License Agreement

    Fujitsu's aggregate liability for such damages shall not exceed the amount equal to the total price of the Product. Further, Fujitsu shall not be liable for (i) damages to the extent they are caused by conditions not attributable to Fujitsu, or...
  • Page 4 XG2600 Hardware Guide c. if in Fujitsu's sole judgment it is not commercially reasonable to perform either of the above options, subject to the limitation of liability set forth in subsection (2) above, Fujitsu shall pay for any damages Customer has incurred due to nonuse of the Software.

  • Page 5: Table Of Contents

    Safety ..................................14 High safety ................................14 Laser Safety ................................15 Notes on Rack Mounting and Connecting a Powerstrip ..................15 About Fujitsu's Green Products ..........................15 Notes on Use ..............................16 Chapter 1 Getting Started ..................17 Items in the Package, Descriptions and Functions ................18 1.1.1...
  • Page 6 XG2600 Hardware Guide Contents 2.3.4 Plugging in the USB Memory ........................50 Connecting a Setup PC ..........................51 Time Setting ............................55 Set up IP address ............................56 Index..........................57...

  • Page 7: Organization And Usage Of This Manual

    Precautions" described in this manual before using this device. Furthermore, this manual should be kept in an easy-to- access location for quick reference while using this device. Fujitsu takes the utmost care to insure that our products can be used safely without causing injury to the customer or damage to their property Target Readers and Required Knowledge This manual is intended for persons who perform network management.

  • Page 8: Trademark Notification In This Manual

    XG2600 Hardware Guide Trademark Notification in This Manual Microsoft, MS-DOS, Windows, Windows NT, Windows Server and Windows Vista are registered trademarks of the Microsoft Corporation in the USA and other countries. Adobe and Reader are trademarks or registered trademarks of Adobe Systems Incorporated in the USA and other countries.

  • Page 9: How The Manuals For This Device Are Organized

    The manuals for this device are organized as follows. Use these manuals as necessary. Manual Name Description XG2600 Hardware Guide (This manual) This manual describes the hardware of the XG2600. User’s Guide This manual describes a variety of operations and procedures, including the installation and maintenance of the XG Series.

  • Page 10: Safety Precautions

    XG2600 Hardware Guide Safety Precautions About Warning Descriptions This manual contains precautions that must be taken in order to use this device safely and prevent personal injury or property damage. Please fully understand the meanings and contents of the following descriptions and symbols when reading this manual.
  • Page 11 XG2600 Hardware Guide Always follow the instructions for safe use of this device. Indicates that improper use can cause Warning severe damage to person, resulting in serious injury or death. Warnings Do not insert or drop any foreign objects into the If you notice abnormal conditions such as device through the vent.
  • Page 12 XG2600 Hardware Guide Indicates that improper use can cause light or moderate injury. Caution In addition, this symbol indicates a chance of damage to this device and other connected equipment. Cautions Do not touch this device for more than one Do not put objects on this device or use it as a minute while it is turned on.

  • Page 13: Notes On Maintenance

    Under certain conditions, twisted pair cables can become charged with static electricity. Connecting a statically charged twisted pair cable to the XG2600 can cause the device or its LAN port to operate falsely or to become damaged. Use a static removal tool to discharge twisted pair cables to ground prior to connecting them to the XG2600.

  • Page 14: Electromagnetic Compatibility (Usa)

    Do not use the XG2600 for High Safety Required applications without otherwise ensuring the safety level required. Fujitsu and its related companies assume no liability whatsoever for damages arising from use of the XG2600 by the user in High Safety Required applications, and for any claims or compensation for damages by the user or a third party.

  • Page 15: Laser Safety

    Even when cables are not connected, invisible laser light may still be emitted from the optical module’s port openings. To avoid possible injury, do not look directly into the optical module’s port openings. Optical transceiver modules intended for use in the XG2600 must be selected from the Optical Transceiver Approved Vendor List (obtainable from the vendor’s service department).

  • Page 16: Notes On Use

    Customers are required to store and maintain configuration information for the device, after the configuration is complete. The configuration information can be used by Fujitsu or Fujitsu’s certified support engineer to restore configurations in case of failure. Unless the configuration information is available, it may cause difficulties and delays for the support engineer to restore the device, Please backup the configuration information on a timely manner and always maintain it up to date.

  • Page 17: Chapter 1 Getting Started

    Chapter 1 Getting Started This chapter lists the items that should be in the product package, and describes the names and functions of the various components. Items in the Package, Descriptions and Functions ........18 1.1.1 Parts List.

  • Page 18: Items In The Package, Descriptions And Functions

    XG2600 The XG2600 switch. • Power Cables (Qty 2) Cables to connect the XG2600 to an AC power source. • SFP+ Dummy Caps (Qty 26) Dummy caps to prevent dust when the SFP+ slots are open and unplugged. The dummy caps come with the switch, installed on the slots at the time of purchase.

  • Page 19: Installation Of Switch: Front Access Or Rear Access (User Configured Airflow)

    Adobe Reader is required for viewing. • XG2600 Hardware Guide (with Licence Agreement) This manual describes the hardware of the XG2600. • RS232C Cable is not included in the product package Note • USB memory is not included in the product package 1.1.2...

  • Page 20: Switch Fan Unit Side

    XG2600 Hardware Guide Chapter 1 Getting Started 1.1.3 Switch Fan Unit Side PSU Slots for  model name,  MAC Firmware Label Fan Unit Front-Access Configuration serial number label XG2600 FAN2 FAN1 PSU2 PSU1 • MAC Firmware Label This indicates the MAC addresses and firmware revision assigned to the switch. •...
  • Page 21 XG2600 Hardware Guide Chapter 1 Getting Started LED Functions/Behaviors LED Name State Status READY Green Switch has started up correctly. Green Blinking Switch is being diagnosed or operating under backup firmware. (*) A problem has occurred. CHECK Orange A problem occurs which may require switch replacement.

  • Page 22: Switch Port Side

    XG2600 Hardware Guide Chapter 1 Getting Started 1.1.4 Switch Port Side Serial Port PSU Slots for  Reset Switch SFP+ Slots Rear-Access Installation Port1 Port25 Port2 Port26 PSU1 USB Port PSU2 Power Supply Unit Power Supply Unit Management Port Power Inlet • PSU Slots for Rear-Access Installation PSUs are plugged in the slots when the switch is used in Rear-Access configuration.
  • Page 23 XG2600 Hardware Guide Chapter 1 Getting Started LED Details FLASH READY CHECK ERROR PSU1 PSU2 POWER Port1 LINK/ Port2 SFP+ LINK/ACT Port1 SFP+ Port2 SFP+ Port1 SFP+  LINK/ACT Port2 • POWER LED Lights to indicate the status of PSU. • SFP+ LINK/ACT LED Lights to indicate the establishment of the link and status of the signal transmission.
  • Page 24 XG2600 Hardware Guide Chapter 1 Getting Started LED Functions/Behaviors LED Name State Status POWER Green PSU is in normal operation. Orange A problem has occurred with the PSU. SFP+ LINK/ACT Green SFP+ link is established. Green Blinking SFP+ is in communication.

  • Page 25: Top Surface

    XG2600 Hardware Guide Chapter 1 Getting Started 1.1.5 Top Surface Rating Label Warning Sticker • Warning Sticker This indicates the warning for safety use. • Rating Label This indicates the rated voltage of the switch. Items in the Package, Descriptions and Functions...

  • Page 26: Bottom Surface

    XG2600 Hardware Guide Chapter 1 Getting Started 1.1.6 BOTTOM Surface Product Manufacturing Label • Product Manufacturing Label This indicates the model name, serial number, manufacturing date, and Class 1 Laser Product, etc. Items in the Package, Descriptions and Functions...

  • Page 27: Option

    XG2600 Hardware Guide Chapter 1 Getting Started Option 1.2.1 SFP+ Modules SFP+ modules (10GBASE-SR/10GBASE-LR) are available for use. "2.3.3 Connecting Twisted Pair Cable / SFP+ Module" (pg.46) Reference User’s Guide " SFP+ Module" (pg.26) Option...

  • Page 28: Chapter 2 Installation

    Chapter 2 Installation This chapter describes how to install the switch and connect it to Console PC. Requirements for Installation Environment ..........29 2.1.1 Installation Requirements .

  • Page 29: Requirements For Installation Environment

    XG2600 Hardware Guide Chapter 2 Installation Requirements for Installation Environment Before installing the switch, please check the following: • Make sure that the switch and all the other options shown in this document are available for installation. • All the cables comply with the specifications of the interface connectors.

  • Page 30: Space Requirements

    XG2600 Hardware Guide Chapter 2 Installation Installation Requirements The product is specifically designed for rack-mounting. Check-list Check the following items. Check Item Check Result Nothing is put on the switch. Vents are not obstructed. The switch is not located on the table or not stuck on another switch.

  • Page 31: Installation Of The Switch

    XG2600 Hardware Guide Chapter 2 Installation Installation of the switch This section describes how to install the switch. 2.2.1 Decide Switch Access Configuration The switch is specifically designed for rack-mounting. The switch can be installed in two different switch access configurations (airflow directions) in a rack.
  • Page 32 XG2600 Hardware Guide Chapter 2 Installation Caution • Do not install PSUs to face the front side of the rack. They do not work properly. • Before installing the switch in the rack, check if the airflow direction of the fans is correct. If the air flows incorrectly, it may cause failure to the switch The diagram below shows in which slots PSUs need to be installed and airflow direction of the fans.
  • Page 33 XG2600 Hardware Guide Chapter 2 Installation Front-Access Configuration (User Configured) The port side (SFP+ slots) is facing forward in a rack. Rack Rear Exhaust FAN1 FAN2 PSU1 PSU2 (Caution) (Caution) Rack Front Intake XG2600 Caution • Do not install PSUs facing the front side of the rack. They do not work properly •...
  • Page 34 XG2600 Hardware Guide Chapter 2 Installation The diagram below shows in which slots PSUs need to be installed and airflow direction of the fans. : Installing : not installing – Power Supply Unit Fan Unit Switch Port Side Switch Fan Unit Side...

  • Page 35: Rear-Access Configuration (Factory Default)

    XG2600 Hardware Guide Chapter 2 Installation 2.2.2 Rear-Access Configuration (Factory Default) This section describes how to install switch in Rear-Access configuration (Factory Default). Decide positions for rack mounting brackets Decide positions of rack mounting brackets. It is possible to install the switch either in a standard front position of the rack or in an offset position of the rack.
  • Page 36 XG2600 Hardware Guide Chapter 2 Installation Install the switch in a 19” rack The switch can be installed and operated in the EIA standard 19" rack. Prepare the following rack mounting components attached. • Rack Mounting Rails (1 set): Rails for mounting the switch in a rack.
  • Page 37 XG2600 Hardware Guide Chapter 2 Installation Slide the switch between rails which are fixed to the rack, and fasten the 2 M6 screws to the front posts. M6 Machine Screws M6 Machine Screws Precautions Pre-occupied devices in the upper and/or lower row of the rack may interfere with the power cable of the switch from being properly installed.

  • Page 38: Change Switch Access Configurations From Rear-Access (Factory Default) To Front-Access And Install

    XG2600 Hardware Guide Chapter 2 Installation 2.2.3 Change Switch Access Configurations from Rear-Access (Factory Default) to Front-Access and Install This section describes how to change Rear-Access configuration (Factory Default) to Front-Access. For Front-Access configuration to Rear-Access, make the procedure reversed.
  • Page 39 XG2600 Hardware Guide Chapter 2 Installation Loosen two screws to remove fan unit. Screw Screw Remove fans (1) Remove two screws. (2) Unlock Cable Holder (which prevents cables from being pulled out). (3) Remove cables Change direction of fans. (1) Turn over the fan.
  • Page 40 XG2600 Hardware Guide Chapter 2 Installation (2) Check if the direction shown in Airflow Label matches the airflow direction required. (3) Unlock Cable Holder to which the cable is connected. (4) Lock the unused Cable Holders. Fix fans. (1) Fasten screws.
  • Page 41 XG2600 Hardware Guide Chapter 2 Installation Change PSU’s positions to meet different switch access configurations There are two types of PSU Slot Bezel. • PSU Bezel (Vents with Logo) Put it to empty PSU1 slot. • PSU Bezel (Vents without Logo) Put it to empty PSU2 slot right next to PSU1 slot.
  • Page 42 XG2600 Hardware Guide Chapter 2 Installation Put PSU Bezel (Vents with Logo) to PSU1-slot on the Port Side with screws. Put PSU Bezel (Vents without Logo) to PSU2-slot right next to PSU1 slot with screws. Slide PSUs into PSU1-slot and PSU2-slot and fix them to the switch with screws.
  • Page 43 XG2600 Hardware Guide Chapter 2 Installation Attach rack mounting brackets to the switch Attach rack mounting brackets to fit either a standard front position of the rack or a offset position of the rack. [STANDARD] Plug into the hole  [OFFSET] of the device. Rack Mounting Brackets Precautions PSUs have to always be located in the rear side of the rack.

  • Page 44: Connecting The Equipment

    XG2600 Hardware Guide Chapter 2 Installation Connecting the Equipment We recommend discharging static electricity of twisted pair cable before connecting it to the switch. Also see below for how to install USB memory. 2.3.1 Discharging Twisted Pair Cable Discharge static electricity of the twisted pair cable through the ground wire cable (ground wire for power supply, buildings, etc.) using static electricity removal tool, before connecting twisted pair cable to the switch.
  • Page 45 XG2600 Hardware Guide Chapter 2 Installation Cleaning of Optical Connector Remove the connector guard cap of optical fiber part, and check the connector end face. If the end face is not clean, clean it with a reel type fiber cleaner.

  • Page 46: Connecting Twisted Pair Cable / Sfp+ Module

    XG2600 Hardware Guide Chapter 2 Installation 2.3.3 Connecting Twisted Pair Cable / SFP+ Module Below is how to connect twisted pair cable and SFP+ module. Use the crossover cable when connecting with routers and terminals. Use the straight cable in case of cascading connection with other switching HUBs with transmission mode at fixed setting other than auto negotiation.
  • Page 47 XG2600 Hardware Guide Chapter 2 Installation Connecting SFP+ Module Firmly install SFP+ module to SFP+ slot and lock module to the switch. SFP+ module Precautions • Safely keep a guard cap of SFP+ module. • Make sure to clean the end face of SFP+ module / optical cable before connecting optical connector because the end face may possibly be contaminated.
  • Page 48 XG2600 Hardware Guide Chapter 2 Installation Precautions Cable length will be as below based on the specification of the optical fiber cable. Type Core/Cladding Diameter Minimum Transimission Band Cable Length (m) 62.5/125 µ m 160MHz/km 200MHz/km 50/125 µ m 400MHz/km...
  • Page 49 XG2600 Hardware Guide Chapter 2 Installation Connect optical cable and release the “disable status” of the SFP+ slot. • In case of using telnet or console Enter replacing SFP+ slot number in <port> # online ether <port> • In case of using www browser Make the SFP+ slot number at the selective state by "Setting of physical port"...

  • Page 50: Plugging In The Usb Memory

    XG2600 Hardware Guide Chapter 2 Installation 2.3.4 Plugging in the USB Memory USB memory can be plugged in from the port side of the switch. Caution Do NOT unplug out the memory stick during access. It may result in crashing setting data.

  • Page 51: Connecting A Setup Pc

    XG2600 Hardware Guide Chapter 2 Installation Connecting a Setup PC This is to connect a set up PC to the console port of the switch using RS232C cable. Necessary Hardware / Software Please prepare the hardware & software specified below to connect to the switch.
  • Page 52 XG2600 Hardware Guide Chapter 2 Installation Turn on the Power Caution • Please use the power cable included in this product. Also, please do NOT use this power cable on other products. • If the power outlet does not match with the power cable plug, please use the change plug adapter.
  • Page 53 XG2600 Hardware Guide Chapter 2 Installation POWER LED of PSU1 and PSU1 LED of the switch will light in green. Next, plug in the power cable to the power connecter of PSU2. The POWER LED of PSU2 and PSU2 LED of the switch will light in green.
  • Page 54 XG2600 Hardware Guide Chapter 2 Installation Confirm “#” is shown on screen. If the key in the wrong password, "invalid password." will be displayed, then the "Login :" will be displayed again. Please repeat your process from item 5. Connecting a Setup PC...

  • Page 55: Time Setting

    When setting time and date to be "Jan 1, 2011 12:30:00am" type in command # date 2011/01/01.12:30:00 XG2600# configure Switch to Configuration mode. XG2600(config)# time zone -0500 When setting time zone to be “-0500”. XG2600(config)# commit Apply the configuration. XG2600(config)# save Save the configuration.

  • Page 56: Set Up Ip Address

    XG2600(config)# oob ip address 192.168.1.1/24 3 XG2600(config)# commit XG2600(config)# exit XG2600# Command (When connecting through10GBASE-R (SFP+) port) XG2600# configure XG2600(config)# lan 0 ip address 192.168.1.1/24 3 XG2600(config)# lan 0 vlan 1 XG2600(config)# commit XG2600(config)# exit XG2600# Precautions • The IP address is not set at the initial state of the purchase. Please set the IP address through console.

  • Page 57: Index

    XG2600 Hardware Guide Index Index BOTTOM Surface ............ 26 Option ............... 27 organization of the manuals ........9 OUTFLOW LED ............. 20 CD-ROM ..............19 CHECK LED ............. 20, 23 Communication Software ......... 51 Power Cables ............18 Connecting the Equipment ........44 Power Inlet ...............
  • Page 58 XG2600 Hardware Guide Index USB Memory ............50 USB Port ..............22 Warning Sticker ............25...
  • Page 59 Printed in Japan • The contents may be revised without prior notice. • Fujitsu assumes no liability for damages to third party copyrights or other rights arising from the use of any information in this manual. • No part of this manual may be reproduced in any form without the prior written permission of Fujitsu.
