The NC112T LED indicators operate as described in the following table.
LED indicator
Status
Activity/Link
On
Off
Flashing
Speed
Off
Green
Yellow
Description
This mono-color green LED indicates that the
link to the adapter is established. The adapter is
receiving power and the cable connection is
working.
No link to the adapter is established. The
adapter is not receiving power or the cable
connection is faulty.
The adapter is sending or receiving network
data at 10/100/1000Mbps, as indicated by
the 10/100/1000 (speed) LED. The adapter is
receiving power, and the cable connection is
working.
The adapter is connected at 10Mbps.
The adapter is connected at 100Mbps.
The adapter is connected at 1000Mbps.
Introduction 7
