QuickSpecs
Overview
The HP 332T is a dual-port, low-cost, low profile 1Gb adapter featuring the BCM5720 Broadcom single-chip solution in a PCIe 2.0
compliant form factor designed for select HP ProLiant Gen8 and Gen7 ML/DL/SL servers.
It delivers full line-rate performance across all ports with low power consumption, providing Ethernet connectivity ideal for
virtualization, security, server consolidation, and network segmentation.
Supported advanced features include Large Send and Receive offload capability, TCP checksum and segmentation, VLAN tagging, MSI-
X, jumbo frames, IEEE 1588 (Precision Time Protocol - PTP), and virtualization features such as VMware NetQueue and Microsoft
Virtual Machine Queue (VMQ).
Support for HP Sea of Sensors 3D Technology enhances server performance while reducing energy use and expense.
Models
HP Ethernet 1Gb 2-port 332T Adapter
Kit Contents
HP Ethernet 1Gb 2-port 332T Adapter
Low profile bracket
Quick install card
Product warranty statement
DA - 14332 North America — Version 6 — September 10, 2013
HP Ethernet 1Gb 2-port 332T Adapter
615732-B21
Page 1

Advertisement

loading

  Related Manuals for HP 332T

  Summary of Contents for HP 332T

  • Page 1 HP Ethernet 1Gb 2-port 332T Adapter Overview The HP 332T is a dual-port, low-cost, low profile 1Gb adapter featuring the BCM5720 Broadcom single-chip solution in a PCIe 2.0 compliant form factor designed for select HP ProLiant Gen8 and Gen7 ML/DL/SL servers.
  • Page 2 QuickSpecs HP Ethernet 1Gb 2-port 332T Adapter Compatibility Servers ProLiant DL (rack-optimized): HP ProLiant DL160 Gen8 HP ProLiant DL165 G7 HP ProLiant DL320e Gen8 HP ProLiant DL320e Gen8 v2 HP ProLiant DL360e Gen8 HP ProLiant DL360p Gen8 HP ProLiant DL380e Gen8...
  • Page 3: Standard Features

    10 Gigabit Ethernet. NOTE: The port enumeration on the 332T is from the top down, i.e. the port near the top of the adapter is port #0 followed by port #1...
  • Page 4: High Availability

    PCI Express The x1 PCI Express interface on the HP 332T is compatible with x1, x4, x8, and x16 PCI slots. If installed in a x4, x8 or x16 slot, the adapter will operate at the x1 speed.
  • Page 5 Standard Features Configuration Utilities Each HP 332T ships with a suite of operating system-tailored configuration utilities that allow the user to enable initial diagnostics and configure adapter teaming. This includes a patented teaming GUI for Microsoft Windows operating systems. Additionally, support for scripted installations of teams in a Microsoft Windows environment allow for unattended OS installations.
  • Page 6: Service And Support

    Protect your business beyond warranty with HP Care Pack Services When you buy HP Options, it's also a good time to think about what level of service you may need. HP Care Pack services provide total care and support expertise with committed response choices designed to meet your IT and business need.
  • Page 7 Offers customers a single point of contact for server problem diagnosis, hardware problem resolution to return the hardware in operating condition within 6 hours of the initial service request to the HP Global Solution Center, and basic software problem diagnosis, fault isolation, and resolution if available to HP.
  • Page 8 The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives replaced by HP due to malfunction. It does not apply to any exchange of Disk or SSD/Flash Drives that have not failed. SSD/Flash Drives that are specified by HP as consumable parts and/or that have exceeded maximum supported lifetime and/or the maximum usage limit as set forth in the manufacturer's operating manual or the technical data sheet are not eligible for the defective media retention service feature option.
  • Page 9: Related Options

    HP NC373T PCI-E Multifunction Gigabit Server Adapter 394791-B21 HP NC375T PCI Express Quad Port Gigabit Server Adapter 538696-B21 HP NC382T PCI Express Dual Port Multifunction Gigabit Server Adapter 458492-B21 HP Ethernet 1Gb 4-port 331T Adapter 647594-B21 HP Ethernet 1Gb 2-port 361T Adapter...
  • Page 10: Technical Specifications

    QuickSpecs HP Ethernet 1Gb 2-port 332T Adapter Technical Specifications General Specifications Network Processor Broadcom NetXtreme BCM5720 chipset Data Rate Two ports, each at 1 Gbps full duplex (2 Gbps aggregate per port); 4 Gbps aggregate full duplex theoretical bandwidth. Data Path...
  • Page 11 Windows is a US registered trademark of Microsoft Corporation. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
