New Connection Profile Configuration
Use the Connection Profile Configuration menu to change the following parameters:
Profile Name
Connection Type
When all the changes have been made, click on the OK button. You will be prompted to save the changes and
reboot the device.
To return to the Connection Profile Screen, click the Exit icon.
Note: The VPI and VCI numbers are assigned by the network service provider. These
values should not be changed unless you are instructed to do so. Incorrect VPI or VCI
settings will not allow the device to connect to the WAN.
DSL-502G ADSL Router User's Guide
Figure 14. Connection Profile Configuration
Type in a new name for this profile.
VPI
Type in the new VPI setting (0-255)
VCI
Type in the new VCI setting (32-65535)
From the drop-down menu select Router with PPPoA, Router with
PPPoE, Router with IPoA, or Bridge with RFC 1483
32
