CAUTION: Do not try to ad-
just heating levels by using the
equipment shutoff valve.
Control Knob
OFF
PILOT/IGN
LOW
MED
OFF
PILOT/IGN
LOW
MED
OFF
PILOT/IGN
LOW
MED
OFF
PILOT/IGN
LOW
MED
Turn control knob clockwise
OFF position.
1. Remove lower front panel.
2. Follow steps 1 through 5 under Lighting
Instructions, page 16.
3. With control knob pressed in, strike match.
Hold match to pilot until pilot lights.
4. Keep control knob pressed in for 30 sec-
onds after lighting pilot. After 30 seconds,
release control knob. Follow step 8 under
Lighting Instructions, page 16.
5. Replace lower front panel.
200045-03A
OPERATION
HIGH
HIGH
HIGH
HIGH
Figure 20 - Burner Patterns (Manual Control)
TO TURN OFF GAS TO APPLIANCE
Shutting Off Heater
to the
MANUAL LIGHTING PROCEDURE
www.usaprocom.com
Ignitor Electrode
Thermocouple
Figure 19 - Pilot
CAUTION: Do not try to ad-
just heating levels by using the
equipment shutoff valve.
Shutting Off Burner Only (pilot stays lit)
Turn control knob clockwise
PILOT position.
Ignitor Electrode
Thermocouple
Figure 21 - Pilot Assembly
Pilot Burner
LOW
MED
HIGH
OFF
to the
Pilot Burner
17
