6. Slide the switch with the rails (A) and ears (C) installed on it into the left and right
rails (B) on the rack. Use four M6 screws (E) to x the rack mount ears (C) to the rack.
Do not tighten the screws yet.
Sliding the Blades in the Rails
NVIDIA Spectrum-2 SN3000 1U and 2U Switch Systems Hardware User Manual
81
