- Page 1 USER MANUAL Telescopic lifting towers ELC-765 ELC-775 ELC-785 You can also download: ANNEX A: Exploded drawings DIVISIÓN EVENTOS / MÚSICA DIVISIÓN ELEVACIÓN INDUSTRIAL EVENTS / MUSIC DIVISON MATERIAL LIFTER DIVISION ...
-
Page 2: Table Of Contents
GUIL – ELC telescopic lifting towers INDEX INTRODUCTION ................................2 OWNER AND USER’S OBLIGATIONS ..........................2 SAFETY RECOMMENDATIONS ............................2 SET-UP AND WORKING AREA SAFETY ......................3 LIFTING TOWER USE SAFETY INSTRUCTIONS....................3 PRE-OPERATION INSPECTION ............................4 OPERATING INSTRUCTIONS ............................5 SET-UP ................................ -
Page 3: Introduction
Before putting the tower into service please make sure that there is no damage caused during transportation. Should there be any, consult your distributor or the manufacturer (GUIL) and do not use the tower until it is in prefect working condition. -
Page 4: Set-Up And Working Area Safety
• Do not exceed the rated load capacity established by the manufacturer GUIL. • Do not raise the tower unless the load is correctly positioned, centred and secured. The centre of gravity should always be along a vertical line. -
Page 5: Pre-Operation Inspection
• Never raise objects that make a large surface for the wind. If it is absolutely necessary, please contact your dealer or the manufacturer (GUIL) for safety advice. • If you are going to leave the tower unattended with a raised load, make sure it can’t be used by unauthorized personnel. -
Page 6: Operating Instructions
GUIL – ELC telescopic lifting towers OPERATING INSTRUCTIONS WARNING! Always use logic and common sense when using the lifter. This is a complex product designed for professional use and should not be operated by amateurs. Ensure all personnel are correctly trained and instructed on the content of the manual and the dangers related with operating the lifter. -
Page 7: Function Test
GUIL - ELC telescopic lifting towers FUNCTION TEST 1.- Install your chosen adaptor on the tower and secure it. Place a load on the adaptor. 2.- Raise and lower the tower to check the following functions. 2.1.- Check that the winch is working correctly: 2.1.1.- It must operate smoothly and free of hesitation, binding or strange noises. -
Page 8: Blocking The Load
GUIL – ELC telescopic lifting towers 1.- Turn the safety bolt knob blocking the first section (telescopic 1) to the position with the arrow pointing to the right. 2.- Turn the winch handle lifting this telescopic section, which will automatically block when it reaches the top. -
Page 9: Lowering The Load
GUIL - ELC telescopic lifting towers LOWERING THE LOAD To lower the load, follow the steps in the previous section in reverse. 1.- Turn the safety bolt knob of the bottom telescopic section (telescopic 3) to the position with the arrow pointing to the right. -
Page 10: Transport
• A regular technical inspection of the lifting tower must be carried out (depending on the regulations in your country and the frequency of use of the tower) by a GUIL authorised technician, to establish the condition of all its parts. -
Page 11: Risk Assesment
GUIL - ELC telescopic lifting towers RISK ASSESMENT Likelihood Medium High Slightly Damaging Severity Damaging Extremely Damaging Insignificant Risk Tolerable Risk Consequence Moderate Risk High Risk Intolerable Risk TASK PRE-OPERATION INSPECTION ELC-765 ELC-775 ELC-785 EVALUATED MACHINE: Likelihood Severity... -
Page 12: Using The Lifter
GUIL – ELC telescopic lifting towers BAD WEATHER CONDITIONS. DO NOT SET UP. UNPREDICTABLE WEATHER USE EXTRA SAFETY PRECAUTIONS. CONDITIONS. THE LEGS DO NOT LOCK INTO THE 1.- DO NOT LIFT. HORIZONTAL POSITION. 2.- CONSULT A GUIL TECHNICIAN. 1.- DO NOT LIFT. - Page 13 GUIL - ELC telescopic lifting towers TASK MAINTENANCE OF THE TOWER ELC-765 ELC-775 ELC-785 EVALUATED MACHINE: Likelihood Severity Consequence Identified Risk Corrective Measures To Mo Hi CLEAN IT AND GREASE THE THE TOWER IS DIRTY. APPROPRIATE PARTS. DAMAGED OR WORN WINCH.
-
Page 14: Guarantee
4. In the case of special products manufactured by GUIL to customer specifications, or from drawings or models, GUIL takes no responsibility for the technical quality of such special products. In any case, the products in question are not covered by the guarantee. -
Page 15: Technical Specifications
GUIL - ELC telescopic lifting towers TECHNICAL SPECIFICATIONS TECHNICAL SPECIFICATIONS REFERENCE ELC-765 ELC-775 ELC-785 5.22 m 5.22 m 5.22 m MAX. HEIGHT 17.1 ft 17.1 ft 17.1 ft 230 kg 270 kg 300 kg MAX. LOAD 507 lb 595 lb... -
Page 16: Ec Declaration Of Conformity
GUIL – ELC telescopic lifting towers EC DECLARATION OF CONFORMITY www.guil.es - GUIL -... -
Page 17: Maintenance Record
GUIL - ELC telescopic lifting towers MAINTENANCE RECORD Referencia: Número de serie: Reference: Serial number: Servicio realizado por: Fecha: Checked by: Date: Elementos revisados: Tested elements: Referencia: Número de serie: Reference: Serial number: Servicio realizado por: Fecha: Checked by: Date:... - Page 18 GUIL – ELC telescopic lifting towers Referencia: Número de serie: Reference: Serial number: Servicio realizado por: Fecha: Checked by: Date: Elementos revisados: Tested elements: Referencia: Número de serie: Reference: Serial number: Servicio realizado por: Fecha: Checked by: Date: Elementos revisados:...
- Page 19 GUIL - ELC telescopic lifting towers Referencia: Número de serie: Reference: Serial number: Servicio realizado por: Fecha: Checked by: Date: Elementos revisados: Tested elements: Referencia: Número de serie: Reference: Serial number: Servicio realizado por: Fecha: Checked by: Date: Elementos revisados:...
- Page 20 C.I.F. B96498829 VAT No ES- B96498829 P.I. La Creu C/ Ismael Tomás Alacreu, 28 46250 L’Alcúdia (VALENCIA) SPAIN Tel: + 34. 96 299 65 00 E-mail: info@guil.es Web: www.guil-lifters.com Manual edition date: 01/2024...
