ARB AC54 Fitting Instructions Manual

DUAL CAB CENTRAL LOCKING CANOPY
Ascent Canopy AC54 - Ford Ranger PX
FITTING KIT: 6173597 Carton Kit and 668PD011 Front Mount Rail
! PLEASE PROVIDE A COPY OF THESE INSTRUCTIONS TO THE CUSTOMER !
IMPORTANT:
 Vehicle bodies and vehicle specific installation can vary, so please read the following
instructions as they refer to important information, which could affect the quality of the
final installation.
 It is advisable to have the canopy fitted by an authorised dealer.
 The majority of installation can be completed by one person, (however 4 people will be
required to lift the canopy onto the vehicle).
FITMENT:
 For Bed liners additional time for fitting is required. Fitment can be undertaken with
Under rail bed liners such as ARB bed liner P/N: KUL1408, ARB Sport Guard P/N:
10051688, or Ford OEM Genuine accessories Ford PXI and PXII P/N: UC9P-65-YA0F
for the bed liner and UC9P-65-YV0A for the tailgate liner and for Ford PXIII released
September of 2018 for P/N: KTAB39262606BA for the bed liner and GB3B2140726AB.
The canopy fitment is NOT suitable for over rail bed liners.
 Cabin Guards and Sports bars must be removed prior to canopy fitment. These
components can be returned to the customer if required.
1-10-2018
If you have any queries regarding the installation of this product please contact the distributor from whom it was purchased, or alternatively the ARB office in your state.
Head Office – ARB Corporation Ltd VIC: 42-44 Garden Street, Kilsyth, Victoria, 3137 Tel: (03) 9761 6622 Fax: (03) 9761 6807
WA:(08) 9244 3553 NSW: (02) 9821 3633 ACT: (02) 6280 7475 SA: (08) 8244 5001 QLD: (07) 3872 3872 NT: (08) 8947 2262 TAS: (03) 6331 4190
(2011 Vehicle Production Onwards)
Page 1 of 54 ARB Copyright 2018 3789194
