维修手册
（本图片为参考示意图，具体外观和配置以实物为准）(The picture is only for reference, and
specific appearance and configuration are subject to the real product)
本维修手册仅用于具有适当电气、电子和机械经验背景的维修人员使用。
任何修理主要装置的测试均可能导致人身伤害和财产损失。
制造商或经销商不对本资料的内容和解释负责。
保留全部版权。未经美的环境电器外销书面批准，不得以任何形式全部或部分复制本手册。
维修手册
Service Manual
Applicable Models
适用机型
FZ10-23PXL
Prepared by
编制
Reviewed by
审核
Approved by
批准
重要安全通知
美的环境电器
技术手册
版权@2017
Service Manual, 2019 v1.0
谢新艳
范超
吴孔升
1 / 16
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Midea FZ10-23PXL
Summary of Contents for Midea FZ10-23PXL
- Page 1 维修手册 Service Manual, 2019 v1.0 Service Manual 维修手册 Applicable Models 适用机型 FZ10-23PXL （本图片为参考示意图，具体外观和配置以实物为准）(The picture is only for reference, and specific appearance and configuration are subject to the real product) Prepared by 编制 谢新艳 Reviewed by 审核 范超 Approved by 批准...
-
Page 2: Important Safety Notice
Midea Environment Appliance Technical Maintenance Manual Copyright @2017 All rights reserved. Replication of all or part of the Manual in any forms shall not be allowed without written approval by the Overseas Sales of Midea Environment Appliance. 安全警示规范 Safety Warning Code WARNING Read these instructions. - Page 3 维修手册 Service Manual, 2019 v1.0 damaged, liquid has been spilled or objects have fallen into the appliance, the appliance has been exposed to rain or moisture, does not operate normally, or has been dropped. 16 To reduce the risk of fire or electric shock, do not expose this appliance to rain, moisture, dripping, or splashing.
- Page 4 维修手册 Service Manual, 2019 v1.0 防尘网拆卸 Removal of dust screen Use a screwdriver to remove the screws on the dust screen and remove the dust screen. 后壳拆卸 Removal of rear cover 用螺丝刀拆开 6 颗后壳固定螺钉，取下后壳 Use a screwdriver to remove 6 fixing screws of the rear cover and remove the rear cover.
- Page 5 维修手册 Service Manual, 2019 v1.0 防火盒组件拆卸 Removal of fire box assembly 取下 2 颗 ST2.9*13 螺钉，将防火盒组件拿出。 Remove two ST2.9 * 13 screws and take out the fire box assembly 电源板拆卸 Power board removal 拆开防火盒， 拿出电源板， 用回形针撬开线束。 Remove the fire box, take out the power board, and pry the harness with a paper clip.
- Page 6 维修手册 Service Manual, 2019 v1.0 2.11 控制板拆卸 Removal of control board 取掉 2 颗 ST3.9*13 螺钉， 将控制板固定压条取 下。 Remove two ST3.9 * 13 screws, and remove the control board fixing strip. 2.12 盖板拆卸 Removal of cover plate 松开下盖板的三颗螺钉，取下下盖板。 Loosen the three screws of the lower cover plate and remove the lower cover plate.
- Page 7 维修手册 Service Manual, 2019 v1.0 2.15 电机罩拆卸 Motor cover removal 松开电机保护罩螺钉三颗 Loosen three screws of the motor protective cover. 2.16 转头板拆卸 Removal of turn round plate 用螺丝刀拆下转头板螺钉，取下转头板 Remove the screws of the turn round plate with a screwdriver and remove the turn round plate 2.17 底座组件拆卸...
-
Page 8: Function And Operation
维修手册 Service Manual, 2019 v1.0 2.19 转动盘拆卸 Removal of rotating disc 取掉卡簧，将转动盘拿出 Remove the circlip and take out the rotating disc 整机的安装 Function and operation 转动盘安装 Installation of rotating disc 1、取 1 转动盘，用毛刷涂抹硅脂油 2、取 1 装配好的钢珠盘，放在转动盘上，取 1 摇头支座，涂抹硅脂油后套入转动盘上 3.取 1 卡簧，将转动盘固定好 1. - Page 9 维修手册 Service Manual, 2019 v1.0 底座组件安装 Installation of base assembly 1、取 1 支撑座，将装配好的摇头线件，按定 位入入支撑座，取 4 颗 ST3.9*13 螺钉将摇头 组件固定在支撑座上。 2、取 1 电源线，从孔中穿入底座上并将尾卡 卡在底座上，取 1 配重块，按方向放在底座 上。 3、取 1 底座盖，扣在底座上取 4 颗 ST3.9*13 螺钉将底座盖固定好 1. Take 1 support base, position the assembled wobble wire into the support base, and take 4 ST3.9 * 13 screws to fix the wobble assembly on the support base.
- Page 10 维修手册 Service Manual, 2019 v1.0 2.14 显示板安装 Installation of display board 将显示板组件安装在电机罩上 Install the display board assembly on the motor cover 2.13 开关安装 Installation of switch 将微动安装在开关支架上面 Install the inching on the switch bracket 2.12 盖板安装 Installation of cover plate 用螺丝刀打...
- Page 11 维修手册 Service Manual, 2019 v1.0 2.10 风机电容安装 Fan capacitor installation 将风机电容线的一端插入接线端子中，然后将 风机电容插入支撑座的卡扣位置中 Insert one end of the fan capacitance wire into the terminal block, and then insert the fan capacitance into the snap position of the support base 电源板安装 Power board installation 将将线束插入电源板，再将电源板放入防火盒...
- Page 12 维修手册 Service Manual, 2019 v1.0 Installation of air duct components 风道组件安装 1、用螺丝刀打一颗螺钉将轴销固定在轴承 上； 2、将卡簧卡入轴承组件中； 3、用螺丝刀拧紧轴承座的 3 颗螺钉； 4、用螺丝刀打一颗螺钉固定风轮； 5、装上挡风板； 6、 用螺丝刀打 6 颗螺钉将风道组件固定在前 壳上 1. Fix the shaft pin on the bearing with a screw driver; 2. Clip the circlip into the bearing assembly; 3.
- Page 13 维修手册 Service Manual, 2019 v1.0 按键安装 Button installation 用手将按键插入上机身相应卡槽中 Insert the key into the corresponding slot of the upper body by hand 顶盖安装 Top cover installation 将顶盖与前后壳扣紧，完成安装 Fasten the top cover with the front and rear shells to complete the installation 常见故障及解决方法...
- Page 14 维修手册 Service Manual, 2019 v1.0 3. Check whether the harness on the power board is tripped 4. Replace the motor 运行异音 线束压进线扣拉紧 Abnormal The harness crimping wire buckle is tightened running sound Appendix: 附录 Electrical Schematic Diagram 整机接线图 风扇维修常用工具、设备和材料 refrigerator maintenance tooling and equipment and material 工具...
- Page 15 维修手册 Service Manual, 2019 v1.0 平口螺丝刀 拆卸螺钉和铆钉 slotted screw and screwdriver rivet assemble and disassemble 斜口剪钳 拆卸扎带 Remove the tie Bevel cutting pliers 活动扳手 拆卸风轮螺母 Remove the monkey wrench wheel nut 钳子 拆卸风叶 pliers Remove the blades 15 / 16...
- Page 16 如需获得厂家详细技术咨询，请联系： xxx@midea.com 环境电器事业部 外销 地址：中国广东省中山市东凤镇东阜路和穗工业园东区 28 号 Midea Environment Appliance If you need to get detailed technical information from the manufacturer, please contact: xxx@midea.com Environment Appliance Division Overseas Sales Address: Eastern 28th, Hesui industrial Park, Dongfu Road, Dongfeng Town, Zhongshan City,...
