Active: Toggle this rule index on or off with Yes or No, respectively.
Source IP Address: Enter the source IP address you wish to deny access to your system.
Subnet Mask: Enter the subnet mask of the source IP address.
Port Number: Enter the port number of the source IP address. Note that 0 means all that ports
are allowed.
Destination IP Address: Enter the destination IP address that you wish to deny access to your
system.
Subnet Mask: Enter the subnet mask of the destination IP address
Port Number: Enter the port number of the destination IP address. Note that 0 means that all
ports are allowed
Protocol: Select the protocol to filter. Choices are TCP, UDP, and ICMP.
Rule Unmatched: Choices are Forward and Next. Select what happens to the data in question
if the rule you are currently editing is unmatched. Next means that the data is then compared to
the next IP filter rule. Forward means that the data will be allowed into your system. Note that a
Forward rule should be the last rule, as no data will be compared to rules after a Forward rule.
IP Filter Set Index: Select the IP filter set you wish to view.
For Example
Please follow below steps to set your IP Filter:
1. IP Filter Set Editing:
Remember, Interface and Direction functions are affected with IP Filter Set
st
1 index set of IP filter set PVC0 as Interface and Outgoing as Direction, so the list of 1
Filter will be PVC0 and Outgoing as their settings.
2. IP Filter Rule Editing:
and choose Active option. As below example, Source IP Address is 192.168.1.4, Subnet
Mask is 255.255.255.255, Destination IP Address & Subnet Mask is 0.0.0.0, Port
Number is 80. And, Protocol sets TCP. From this setting, it filters 192.168.1.14, so it cannot
access the web. Notice, each IP Filter Set Index can has up to 6 filters IP. At "Rule
Unmatched" option, you must choose NEXT until the last filter IP choose Forward.
3. After every setting is done, click SAVE to continue next IP Filter Editing.
Choose your IP Filter Set Index, Interface and Direction options.
Select the IP Filter Rule Index (up to 6 numbers for each set index)
Index. EX: if your
