The following table describes the labels in this screen.
LABEL
VPI
VCI
Connection Type
Your ISP should provide the above information. Click on BACK to return to the
previous screen, on NEXT to continue, or on EXIT to exit the wizard without saving.

5.3.2 Configuring Static IP Address

A static IP address connection uses the same IP each time you connect to your ISP.
The following table describes the labels in this screen.
LABEL
VPI
VCI
IP Address
Subnet Mask
ISP Gateway
Connection Type
Your ISP should provide this information. Click on BACK to return to the previous
screen, on NEXT to continue, or on EXIT to exit the wizard without saving.
Enter the VPI here. VPI can range from 0 to 255.
Enter the VCI here. VCI can range from 1 to 65535.
Select your connection type from the dropdown list.
Enter the VPI here. VPI can range from 0 to 255.
Enter the VCI here. VCI can range from 1 to 65535.
Enter the IP address here.
Enter the Subnet Mask here.
Enter the ISP Gateway here.
Select your connection type from the dropdown list.
DESCRIPTION
DESCRIPTION
