Analog way SmartVu LE Quick Start page 3

Input & Output configuration
1/ In the menu section, press the EXIT/MENU button and select
Input in the menu by rotating the selection knob and press the
ENTER button to enter the Input sub-menu.
2/ Select Auto Setting and press enter to automatically configure
the inputs plugged into the SmartVu LE. The device will set all
input resolutions and frequencies to match the input sources
plugged to the device.
3/ Alternatively, you can configure all inputs of the SmartVu LE
individually, by navigating to the Input menu and setting each
input accordingly.
Once your inputs have all been configured, the output settings
of the SmartVu LE must be set according to the machines
plugged on your SmartVu LE Main and Preview outputs (video
projector, preview monitor...).
1/ In the menu section, press the EXIT/MENU button and select
Output in the menu by rotating the selection knob. Enter the
Output sub-menu and select the output type, resolution and
frequency, so that they match the viewing hardware plugged
into the unit.
2/ Press the ENTER button to enter each of the desired output
parameters.
Your SmartVu LE is now set up and ready to work with.
SmartVu LE layers
The SmartVu LE offers only one type of layer to work with :
Live Background. To work with a live background, simply select
a live input source (1-5) from the Input Selection section of the
SmartVu LE. The selected button will start to blink. Press the
TAKE button to view the results on your Main output.
It is possible to add an opening and closing transition type to
your live layer.
To parameter transitions for live layer, proceed as follows :
1/ In the Input Selection section, press the source button you
wish to add a transition effect to. The button will start blinking.
