No.
USB Connection:
Located in lower-right corner of the media tower. The CD/DVD/USB recognizes Hard Disk Drive
(USB drive) or USB key (Flash memory) with VFAT format. It does not recognize any hardware
with extension 3 format.
Supports connecting a USB storage device to save or restore scan files or Dicom image.
2
Supports connecting a USB storage device to export the data.
The Bar Code Reader may be connected to one of the USB ports.
The storage device should have a minimum size of 4 GB.
Only one USB for saving scan data can be connected at a time if there are multiple USB
ports.
Computer power on/off switch:
Located on the front of the console.
3
Use to start up the system.
Use to shut down the system.

Computer

The computer is located at the base of the console and it contains all the hardware necessary to operate the
system and perform image generation.
It uses a PC based computer system running a Linux based operating system.The system includes system,
image and scan data disks and stores up to 460,000 512 images and with 500 giga byte for scan data files.

Reconstruction Engine

The reconstruction engine provides advanced processing capabilities for the reconstruction of
routine imaging modes and ASiR-V/ASiR modes and SmartMAR mode.
Do not use the input-output interface (DVD drive, USB, ethernet, etc.) on HP workstation of the console.
Description
