- Page 1 Installation Guide For HyPanel Smarter Home Sweeter Life...
- Page 2 Welcome! This guide applies to PS51-KNX-EU model of HyPanel. Contents Before We Start ............................... In the Box ................................Check Compatibility ..........................Wiring ..................................Installation ................................Get Help ..................................
- Page 3 Your first time installing this product may take up to 40 minutes. You'll get faster after each installation. Warning The installation procedure involves handling high voltage wiring. Please be careful. To avoid serious personal injury, death, or property damage, turn OFF the power to the circuit and follow all safety precautions before proceeding.
- Page 4 HyPanel X 1 Flush Mounted Module x 1 ST3x20mm Phillips Self Tapping Screw x2...
-
Page 5: Product Dimensions (Mm)
Product dimensions (mm) BOTTOM VIEW 86.0 11.8 31.0 RIGHT VIEW FRONT VIEW LEFT VIEW BACK VIEW 51.0 TOP VIEW... -
Page 6: Working Space
Working space Make sure HyPanel is compatible with the location where you want to install it. WALL WALL 50mm WALL HYPANEL FRONT VIEW 40mm SIDE VIEW: HYPANEL IN WALL A 50mm(2 inches) deep electrical box is highly recommended for ease of installation. In some... -
Page 7: Power Requirements
For HyPanel: A 21-30V DC power supply is required. For load devices: 100 - 240V AC power supply is needed. Support Wi-Fi and Ethernet connections HyPanel can operate with both wireless and wired networks. A wired connection is recommended for greater reliability and faster data exchange. - Page 8 Warning Turn OFF the circuit breaker before wiring and proceeding! Always use a voltage detector to verify the power is OFF before wiring and installation!
-
Page 9: Rear Connections
Rear connections L In L1 Out KNX+ KNX- AUX+ AUX-... - Page 10 The Line wire (L) connects to any one of the L terminals, providing 100-240 Volts of power to the load devices. L1 and L2 are Load wires that connect the HyPanel to the light bulbs or other devices, e.g., fans or curtain motors.
-
Page 11: Connect Wires
Connect wires Strip and straighten wires The Line and Load wires connected to HyPanel should be 1.5mm²~ 2.5mm² in size and have stripped and straight ends. Remove the plastic sheathing of the wire, and make sure the exposed wire ends measure approximately 8 mm (5/16 inch) in length. - Page 12 L L L2 L1 RJ45 AUX- AUX+ KNX- KNX+ Connect KNX and AUX cables to the corresponding terminals. If you need to link load devices Connect the Line wire to any one of the L terminals. Connect the Load wire(s) to the L1 and/or L2 terminals. Tighten the screws clockwise with a flat-head screwdriver until wires are secure.
-
Page 13: Installation
Installation Install flush mounted module Insert the supplied screws into the designated holes on the electrical box. Change the torque on the electric screwdriver to 5kgf.cm. Turn screws clockwise with the screwdriver. Do not fully tighten the screws. The screw head must protrude at least 3 mm (1/8 inch) from the wall surface. - Page 14 Install flush mounted module Attach the flush mounted module to the electrical box. The screws should go through the holes on the module. Adjust the module to be level and ensure it is flush against the wall. Tighten the screws to attach the module to the wall, taking care not to over-tightened them.
-
Page 15: Install Panel
Install panel Turn OFF the circuit breaker before you install the panel. Position the panel at a tilt as the picture shows. Press the panel into the flush mounted module until it clicks. - Page 16 If you need to remove the panel Insert a flat-head screwdriver with about 6mm width into the slot at the bottom edge. Gently pry the panel up.
- Page 17 Congratulations! You are done with the HyPanel installation! Start your smart home journey with Akubela now! Get Help For help or more assistance, contact us at: https://ticket.akuvox.com/ For videos, guides, and additional product formation, visit us at: https://knowledge.akuvox.com...
