- Page 1 Installation Guide For HyPanel Smarter Home Sweeter Life...
- Page 2 Welcome! This guide applies to PS51-HEATING-EU model of HyPanel. Contents Before We Start ............................... In the Box ................................Check Compatibility ..........................Wiring ..................................Installation ................................Get Help ..................................
-
Page 3: Important Note
Your first time installing this product may take up to 40 minutes. You'll get faster after each installation. Warning The installation procedure involves handling high voltage wiring. Please be careful. To avoid serious personal injury, death, or property damage, turn OFF the power to the circuit and follow all safety precautions before proceeding. - Page 4 Flush Mounted Module x 1 HyPanel X 1 ST3x20mm Phillips Self Tapping NTC Thermistor X 1 Screw x 2...
-
Page 5: Product Dimensions (Mm)
Product dimensions (mm) BOTTOM VIEW 86.0 11.8 33.5 RIGHT VIEW FRONT VIEW LEFT VIEW BACK VIEW 51.0 TOP VIEW... -
Page 6: Working Space
WALL Working space Make sure HyPanel is compatible with the location where you want to install it. WALL WALL 50mm WALL HYPANEL FRONT VIEW 40mm SIDE VIEW: HYPANEL IN WALL A 50mm(2 inches) deep electrical box is highly recommended for ease of installation. In some scenarios, especially when the wires can be pushed back into the wall far enough, it may be possible to use a 40mm(1.6 inches) deep box. -
Page 7: Maximum Load
Maximum load The device has a maximum resistive load capacity of 16A, supporting a power load of up to 4000W at 250VAC. 90-250VAC, 50/60 Hz power required HyPanel can be used in countries with varying standard voltages, from 90V to 250 V AC, at a frequency of either 50Hz or 60Hz. Wire sizes for different connections RS485 and NTC: Recommended wire size is 0.14mm²-0.75mm²(26-18AWG). - Page 8 Warning Turn OFF the circuit breaker before wiring and proceeding! Always use a voltage detector to verify the power is OFF before wiring and installation!
- Page 9 Identify wires L1 N1 N L BELL NTC+ NTC- Neutral wire(N) typically comes from the wall. Line wire(L) provides 90-250 Volts of power to HyPanel. Load wires(L1) that connect the HyPanel to the heating thermostat or other devices. BELL and GND are used to link a door bell. Not required if no bell is used. NTC+ and NTC- are for the thermistor lead connections.
-
Page 10: Connect Wires
Connect wires Strip and straighten wires Wires connected to HyPanel should be 1.5mm² ~ 2.5mm² in size and have stripped and straight ends. Remove the plastic sheathing of the wire, and make sure the exposed wire ends measure approximately 8 mm (5/16 inch) in length. Connect all wires Always make sure the arrow on the front of the flush mounted module is pointing up. - Page 11 Plug the wires to the corresponding teminals on the back of the flush mounted module. Tighten the screws clockwise with a flat-head screwdriver until wires are secure. Double check by gently tugging on each wire. To use a thermistor, plug the NTC cable into the NTC+/- terminals. To connect with a door bell, connect the wires to the BELL and GND terminals respectively.
-
Page 12: Installation
Installation Insert screws Insert the supplied screws into the designated holes on the electrical box. Change the torque on the electric screwdriver to 5kgf.cm. Turn screws clockwise with the screwdriver. Do not fully tighten the screws. The screw head must protrude at least 3 mm (1/8 inch) from the wall surface. - Page 13 Install flush mounted module Attach the flush mounted module to the electrical box. The screws should go through the holes on the module. Adjust the module to be level and ensure it is flush against the wall. Tighten the screws to attach the module to the wall, taking care not to over-tightened them.
- Page 14 Test connected devices Turn on the circuit breaker to provide power to the flush mounted module. Press the button on the module to check if the connected devices can work. If the devices do not turn on/off, do NOT install the panel. Turn the power off...
-
Page 15: Install Panel
Install panel Turn OFF the circuit breaker before you install the panel. Position the panel at a tilt as the picture shows. Press the panel into the flush mounted module until it clicks. - Page 16 Install panel Turn OFF the circuit breaker before you install the panel. Position the panel at a tilt as the picture shows. Press the panel into the flush mounted module until it clicks.
- Page 17 Congratulations! You are done with the HyPanel installation! Start your smart home journey with Akubela now! Get Help For help or more assistance, contact us at: https://ticket.akuvox.com/ For videos, guides, and additional product formation, visit us at: https://knowledge.akuvox.com...
