  • Page 1 HyPanel Lux Quick Guide...

  • Page 2: Table Of Contents

    Welcome This guide applies to RT61-D1-US model of HyPanel Lux. Contents Before We Start In the Box Check Compatibility Wiring Installation Get Help...

  • Page 3: Before We Start

    Before We Start Your first time installing this product may take up to 40 minutes. You’ll get faster after each installation. WARNING The installation procedure involves handling high voltage wiring. Please be careful. To avoid serious personal injury, death, or property damage, turn OFF the power to the circuit and follow all safety precautions before proceeding.

  • Page 4: In The Box

    In the Box HyPanel Lux x 1 Flush Mounted Module x 1 #6-32x1-1/4" Phillips Machine Screw x 2 M2x5mm Phillips Machine Screw x 2...

  • Page 5: Check Compatibility

    Check Compatibility Product dimensions(mm) BOTTOM VIEW RIGHT VIEW LEFT VIEW FRONT VIEW BACK VIEW TOP VIEW...
  • Page 6 Working space Make sure HyPanel Lux is compatible with the location where you want to install it. A 50mm(2 inches) deep electrical box is highly recommended for ease of installation. In some scenarios, especially when the wires can be pushed back into the wall far enough, it may be possible to use a 40mm(1.6 inches) deep box.
  • Page 7 Maximum load The total load of the device(s) connected to HyPanel Pro must be less than 400W(Max load). The wattage of a resistive load appliance, e.g., an incandescent bulb, must be less than 200W at 110V or 400W at 220V. The wattage of a LED lamp or compact fluorescent lamp (CFL) must be less than 150W.

  • Page 8: Wiring

    Wiring WARNING Turn OFF the circuit breaker before wiring and proceeding! Always use a voltage detector to verify the power is OFF Identify wires before wiring and installation! L In(100-260V AC) L1 Out A Neutral wire (N) typically comes from the wall. The Line wire (L) provides 100-260 Volts of power to the HyPanel Lux.
  • Page 9 Connect wires 1.Strip and straighten wires Wires connected to your HyPanel Lux should be 1.5mm² ~ 2.5mm² in size and must have stripped and straight ends. Remove the plastic sheathing of the wire, and make sure the exposed wire ends measure approximately 8 mm (5/16 inch) in length.

  • Page 10: Installation

    Installation Confirm installation direction HyPanel Lux can be either vertically or horizontally installed. If you want to mount the flush mounted module vertically, we strongly recommend that you have its clips on the top and the screw holes at the bottom.
  • Page 11 Install flush mounted module Push all wires into the electrical box. Make sure the module is level and flush against the wall. Change the torque on the electric screwdriver to 5kgf.cm. Use the provided screws to attach the module to the wall, taking care not to over-tightened them.
  • Page 12 Test connected devices Test Button WARNING Ensure proper wiring connections and reliable grounding before turning on the circuit breaker. Turn on the circuit breaker to provide power to the flush mounted module. Press the button on the module to check if the connected device can work properly. Press the button once to turned on/off...
  • Page 13 WARNING Turn OFF the circuit breaker before you install the panel. Install panel Line up the two clips on the flush mounted module with the notches on the panel. Snap the panel into place and press it down.
  • Page 14 Since the HyPanel Lux can be mounted either vertically or horizontally, the screw holes would be in different positions depending on the direction you choose. Check the panel is properly clipped onto the module and is flush against the wall. Use two Phillips machine screws to secure the panel.
  • Page 15 If you need to remove the panel We strongly recommend detaching a panel from the screwing side. 1.Remove the machine screws. 2.Press one hand above the panel on the clips side. 3.With your other hand, grasp the panel from the screwing side and pull it outwards.

  • Page 16: Get Help

    Congratulations! You are done with the HyPanel Lux installation! Start your smart home journey with Akubela now! Get Help For help or more assistance, contact us at: https://ticket.akuvox.com/ For videos, guides, and additional product formation, visit us at: https://knowledge.akuvox.com...
