1. Trim Components
Escutcheon Assembly
Lever is handed, RHR (shown)
or LHR.
Note: Lever return spring is universal
for easy field handing.
See page 5 to change handing
80-8470-0628-000 04/24
(2) #14 Finishing Washers
Copyright © 2005, 2013, 2023, 2024, ASSA ABLOY ACCENTRA™ Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is
2
Trim Spindle
Assembly
(2) 1/4-20 Oval Head
2 STUDS AWAY
FROM LOCK EDGE
1-855-577-5078 Ext. 2 • www.accentra-assaabloy.com
628F
Exit Device Trim
Installation Instructions
2 STUDS TOWARDS
LOCK EDGE
(2) 1/4-20 Pan Head
Machine Screws
Packed with device.
prohibited.
