Assa Abloy ACCENTRA 630F Installation Instructions

630F & 634F
Exit Device Trim
Installation Instructions
WARNING
This product can expose you to lead which is known to the state of California to cause cancer and birth defects or other
reproductive harm. For more information go to www.P65warnings.ca.gov.
WARNING
Attention Installer: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and ASSA ABLOY makes no rep-
resentations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire-rated opening, or specifying
and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applica-
ble codes and ratings.
1-855-557-5078 Ext. 2 • www.accentra-assaabloy.com
Copyright © 2005, 2013, 2023, 2024, ASSA ABLOY ACCENTRA™ Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express
written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
2-3/4
(70)
15-1/4
(337)
630F Trim
2-3/4
(70)
15-1/4
(337)
634F Trim
(Push-Pull Door
when dogged)
80-8470-0634-000 04/24
