Argo Sasquatch XTX 2025 Operator's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
2025
OPERATOR'S
MANUAL
Sasquatch XTX
Do not remove this manual from this vehicle.
Part #: 100-0580
Effective Date 7/2024 Rev. A

Advertisement

loading
Need help?

Need help?

Do you have a question about the Sasquatch XTX 2025 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Argo Sasquatch XTX 2025

Summary of Contents for Argo Sasquatch XTX 2025

  • Page 1 2025 OPERATOR’S MANUAL Sasquatch XTX Do not remove this manual from this vehicle. Part #: 100-0580 Effective Date 7/2024 Rev. A...
  • Page 3 Read this manual before you operate your ARGO XTV. It contains safe operating instructions and warns the user about potential hazards that can result in personal injury. Warnings are identified in the text by the following symbol: WARNING Warning text warns the user about potential hazards that can result in person- al injury or death.
  • Page 4 Proper setup, maintenance and safe operating practices will help you get years of satisfactory use from this XTV. Your safety and the safety of all ARGO users is of the greatest concern to us. You will find numerous safety statements in this manual. Please read and follow them carefully.
  • Page 5 For maintenance and adjustment of the engine, refer to the manufacturer’s operation and maintenance manual included in your XTV’s information package. Before you drive your ARGO XTV, make sure you understand how to use all controls. Learn how to drive your XTV in an open level area, away from buildings, trees and other obstacles, until you are completely familiar with its operating char- acteristics.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS SECTION I - Safety Safety ......................... 1 Consumer Responsibilities ................. 5 Safety Label Locations ..................6 Warnings ......................8 SECTION 2 - Specifications and Technical Characteristics Engine ......................15 Specifications ....................15 SECTION 3 - Technical Description XTV Structure ....................
  • Page 7 Vehicle Info Screen................... 36 Manual Screen ....................38 Camera Screen ....................39 Diagnostic Screen ....................40 Engine ECU Faults ................... 40 Steering Control Faults ..................40 Cooling Fan Faults ................... 40 Input Screen ..................... 42 Output Screen ....................42 Night Screen ....................... 43 Zero Turn ......................
  • Page 8 Secondary Fuel Filter ..................71 Bleeding Fuel System..................71 Coolant Check / Fill ..................72 Air Filter Maintenance..................73 Brake Fluid Maintenance .................. 74 Windshield Washer Fluid Maintenance ............74 Wheels and Tires - General Provisions ............75 Dismounting Wheel Assembly ................. 76 Mounting Wheel Assembly ................

  • Page 9: Safety

    ■ Do not operate a XTV with damaged or defective parts. A damaged XTV should be evaluated, inspected and repaired by an authorized ARGO service center, and defective parts should be replaced before putting the XTV back into service.
  • Page 10 Safety TO AVOID SERIOUS INJURY OR DEATH: ■ Never allow operation of this XTV if a person is intoxicated by alcohol or drugs. ■ Operate this XTV from the driver’s seat only. ■ Always use the seat belt and fasten it securely. ■...
  • Page 11 Always stay clear of the tow line. ■ Assembly, maintenance and/or repair of this XTV should only be performed by authorized ARGO dealers or authorized engine centers (for engine repairs) to avoid unsafe conditions or modifications. ■ NEVER adjust, repair or clean the XTV while in motion or with the engine running.
  • Page 12 Safety ■ Engine must be allowed to cool before storage in any enclosure. ■ XTV must be stored where diesel fuel fumes will not reach an open flame, spark or other source of ignition. ■ For long-term storage, the fuel tank should be filled to capacity with diesel. Indicates a potential hazard that could WARNING result in a serious injury or death.

  • Page 13: Consumer Responsibilities

    Consumer Responsibility ■ Prior to each use, the operator shall perform the pre-operation checks specified by the manufacturer and further verify the following: - Smooth throttle operation and positive return of the throttle pedal to a closed throttle position when released. - Steering wheel rotates freely.

  • Page 14: Front View

    LABEL LOCATIONS IT IS VERY IMPORTANT TO READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS, CAUTIONS AND WARNINGS LOCATED ON THE DECALS ON YOUR XTV The following section has been prepared to instruct you in the safe and responsible operation of your XTV. Read and abide by all safety alert information about this XTV. If you do not understand any part of this section, contact your local dealer for additional information and clarification.
  • Page 15 Label Locations Indicates a potential hazard that could WARNING result in a serious injury or death.

  • Page 16: Warnings

    Warnings POTENTIAL HAZARD Operating this vehicle without proper instruction. WHAT CAN HAPPEN The risk of an accident is greatly increased if the operator does not know how to operate this vehicle properly in different situations and on different types of terrain.
  • Page 17 Warnings POTENTIAL HAZARD Operating or riding in the XTV without wearing a properly secured seat belt. WHAT CAN HAPPEN Serious injury or death. Occupants can strike objects in the passenger compartment, fall out of the XTV during operation, or be crushed or otherwise injured in the event of an accident.
  • Page 18 Warnings POTENTIAL HAZARD Failure to use caution when operating this XTV on unfamiliar terrain. WHAT CAN HAPPEN You may encounter hidden rocks, bumps, or holes without enough time to react, which could result in the vehicle going out of control. HOW TO AVOID THE HAZARD Use caution when operating on unfamiliar terrain.
  • Page 19 Warnings POTENTIAL HAZARD Climbing hills improperly. WHAT CAN HAPPEN You may lose control, which could result in an accident. HOW TO AVOID THE HAZARD Always follow proper procedures for climbing hills. Always check the terrain carefully before you start up any hill. Never climb hills with slippery or loose surfaces.

  • Page 20: What Can Happen

    Warnings POTENTIAL HAZARD Improperly operating in reverse. WHAT CAN HAPPEN You may contact an obstacle or person behind you, resulting in serious injury or death. HOW TO AVOID THE HAZARD Before you engage the reverse gear, make sure there are no obstacles or people behind you.
  • Page 21 Warnings POTENTIAL HAZARD Overloading the XTV. WHAT CAN HAPPEN You may lose control, which could result in an accident. HOW TO AVOID THE HAZARD Never exceed the stated load capacity for this XTV. Cargo should be properly distributed and securely attached. Reduce speed when carrying cargo.
  • Page 22 NOTES...

  • Page 23: Section 2 - Specifications And Technical Characteristics Engine

    Specifications and Technical Characteristics Engine The ARGO Sasquatch engine provides advanced performance in its class with the most demanding environmentally-conscious technologies. The diesel engine provides fuel efficiency with a low level of noise and vibration. The engines are adapted for work in any climate, which makes it possible to operate the XTV in most all conditions.
  • Page 24 SPECIFICATIONS / TECHNICAL CHARACTERISTICS Maximum Towing capacity 5180 lbs (2350 kg) Maximum Tongue Weight 330 lbs (150 kg) Brakes Hydraulic disc brake Parking brake system Mechanical handbrake Steering Steer by wire Tire size 71 x 23 - 25 in (1800 x 600 - 635) Type of tires XT 328 Tube less, extra-low pressure Suspension...

  • Page 25: Section 3 - Technical Description Xtv Structure

    SECTION 3 Technical Description XTV Structure All models of ARGO vehicles generally consist of the following main components: power train, transmission, control system, electrical equipment and bodywork. The cab includes the driver’s and passenger’s seat, seat belts, inner lining with sound...

  • Page 26: Xtv Dimensions

    XTV - Dimension 101 in (2565 mm) 46 in (1184 mm) 157 in (4002 mm)

  • Page 27: Location Of Controls And Devices

    Location of Controls and Cab Devices Display See Display section. Ignition Switch Switch has four positions: - Accy (rotate to left) - OFF - ON - Ignition, fuel pump, engine glow plugs and system power - Momentary starter switch Multi-Function Switch Left and Right Turn Signals Running / High Beam / Low Beam Horn...
  • Page 28 Location of Controls and Cab Devices Cab Air Filter Access Battery Disconnect Switch Main power switch - three positions - OFF - ON (BAT 1) (Normal Operation) - COMBINE BATTERIES (BAT1 / BAT2) NOTE: COMBINE BATTERIES to be used if BAT1 does not have enough power to start the vehicle.
  • Page 29 Location of Controls and Cab Devices Before operating this vehicle, become familiar with all control locations and their purposes. 1. Display 2. Ignition Switch 3. Multi-Function Switch 4. Shift Lever 5. Tilt Steering Lever 6. USB / USB-C 7. Bilge Pump Switch 8.
  • Page 30 Location of Controls and Cab Devices 10 11 14 15 16 17 9. Roof Hatch Release Levers 10. Windshield Wiper / Washer Switch 11. Hazard Switch 12. Strobe Light Switch 13. Cargo Light Switch 14. Interior Light Switch 15. Spare 16.
  • Page 31 Location of Controls and Cab Devices 20. Parking Brake Lever 21. Seat Adjustment Levers 22. Cab Air Filter Access 23. Battery Disconnect Switch 24. Front Door Release Lever 25. Front Window Release Lever...
  • Page 32 Location of Controls and Cab Devices 26. Rear Ladder 27. Rear Cargo Bed Door Latch 28. Fuel Fill 29. Rear Receiver Hitch Location 30. Rear Box Tie Down Locations...
  • Page 33 Location of Controls and Cab Devices 31. HVAC Power Fuse Panel 32. Main Power Fuse Panel 33. Engine Relay Panel 34. Chassis Power Fuse Panel 35. Fan Power Fuse Block 36. Steering Power Fuse Block 37. Steering Relay...
  • Page 34 Location of Controls and Cab Devices 38. Cab Power Fuse Panel 39. Battery Fuse 40. Schrader Valve...

  • Page 35: Fuse Panels Main Power Fuse Panel

    Fuse Panels Main Power Fuse Panel The Main Power Fuse Panel is located in the rear passenger area behind the closeout panel that is located below the driver and passenger seats. Chassis Power Fuse Panel The Chassis Power Fuse Panel is located in the rear passenger area behind the closeout panel that is located below the driver and passenger seats.

  • Page 36: Engine Relay Block

    Fuse Panels Engine Relay Block The Engine Relay Block is located in the rear passenger area behind the closeout panel that is located below the driver and passenger seats. Cab Power Fuse Panel The Cab Power Fuse Panel is located in the rear passenger area on the left hand side of the vehicle as you enter the door.

  • Page 37: Steering Power Fuse Block

    Fuse Panels Steering Power Fuse Block The Steering Power Fuse Block is located under the floor in the rear passenger area. Steering Fuse (5A) Steering Relay Diode Battery Fuse The Battery Fuse is located on top of each 12V positive battery post. Battery Fuse (175A)

  • Page 38: Display Features And Operation Soft Keys And Touch Screen

    Display - Features and Operation Soft Keys and Touch Screen There are 16 Soft Keys to navigate through menus and to set tire pressure. Menu items within specific pages can be changed or selected using the touch screen of the display.

  • Page 39: Vehicle Speed

    Display - Home Screen Vehicle Speed The vehicle speed will be displayed on the left-hand main gauge in both analog needle gauge format and digital format. Engine Oil Pressure The engine oil pressure will be displayed on the left-hand main gauge in analog gauge format.

  • Page 40: Gear Position

    Display - Home Screen Gear Position The gear position indicator will show the transmissions current gear, Overdrive (OD), Drive (D), Neutral (N) or Reverse (R). If the parking brake is engaged when the transmission is placed in OD, D or R, an alarm will sound and a warning will appear on the display.

  • Page 41: Tilt And Incline Gauges

    Display - Home Screen Tilt and Incline Gauges The Tilt gauge will display the measured angle of the vehicle from side to side. The Incline gauge will display the measured “UP” or “DOWN” incline the vehicle is being driven. When the vehicle’s tilt or incline angle has reached the operating limit, the incline numbers and gauge background color will change to red to warn the operator.

  • Page 42: Tire Inflation System And Tire Pressure Selection

    Display - Tire Inflation System Tire Inflation System and Tire Pressure Selection From the Home screen, you can change the tire pressure settings based on terrain conditions for optimum vehicle performance and appropriate traction required. Depress the desired “soft key” or display screen icon to adjust the terrain condition. The tire deflate system will operate with the engine in the “OFF”...

  • Page 43: Road

    Display - Tire Inflation System Tire Inflation System The Tire Inflation System can only be activated when the engine is running and will be in the “last known” setting when the vehicle is started. To adjust the tire pressure to the appropriate terrain, depress the desired softkey or display screen icon .

  • Page 44: Settings Screen

    Display - Settings Screen Settings Screen From the Settings screen, the date, time, softkey color, and display brightness can be changed. Any changes made in the settings screen will be saved when you exit the screen. Set Time/Date Press the up/down arrows with your finger to change the Month, Day, Year, Hour Minute or Second value, then press “SET”...

  • Page 45: Display - Settings Screen

    Display - Settings Screen To change one of the eight values shown in the list, tap the desired location, then select the item from to display by tapping on it from the list.

  • Page 46: Manual Screen

    Display - Settings Screen Display - Manual Screen Manual Screen The Manual Screen contains pre-loaded content that can be viewed and displayed on the monitor. To access stored content, click the “SELECT MANUAL” button. – Toggle through content using “UP” or “DOWN” buttons. –...

  • Page 47: Camera Screen

    Display - Manual Screen The display screen has touch functionality which will allow you to scroll through the content by sliding the scroll bar from left to right or by using the arrows. Once desired page is displayed, press “DESIRED PAGES” button. Display - Camera Screen Camera Screen The Camera Screen can be accessed at any time to display the rear facing camera.

  • Page 48: Diagnostic Screen

    Display - Diagnostic Screen Diagnostic Screen The Diagnostic Screen displays active faults from ECUs, Input values from sensors and Output functions to activate circuits. Faults can be generated from a fault in the Engine ECU, Steering Control Unit (SCU), and Cooling Fan Unit (CFU). If a fault becomes active, the display will automatically change to the Diag.
  • Page 49 Display - Diagnostic Screen Steering Control faults will be displayed when active in the lower portion of the screen. When a SCU fault is active, the text will be black, inactive faults are gray in color. There will also be an icon displayed at the top of the screen to indicate an active fault exists.

  • Page 50: Input Screen

    Display - Diagnostic Screen The Inputs Screen displays current values of sensors or circuits that communicate with one or more of the ECUs on the vehicle. The Outputs Screen displays current state of the outputs. To change one of the three gauges shown on the left side of the screen, tap the gauge and then select the item to display by tapping on it from the list.

  • Page 51: Night Screen

    Display - Night Screen Night Screen The Night Screen changes the display color and brightness settings to allow for different colors or screen brightness level. Press the soft key to the left of the Night icon to activate or deactivate Night mode. To change the soft key Backlight Color or Display Brightness for Night mode, first activate Night mode by pressing the soft key to the left of the Night icon.

  • Page 52: Zero Turn

    Display - Zero Turn Zero Turn The Zero Turn function activates the vehicle steering when the vehicle is NOT moving. Press the Zero Turn icon or soft key to the left of the zero turn icon to activate. The engine must be running, the brake pedal depressed and the transmission in D, OD, or R gear position to perform a zero turn.

  • Page 53: Section 4 - Xtv Operation

    SECTION 4 XTV Operation ATTENTION! THE PARKING BRAKE MUST BE RELEASED BEFORE DRIVING Pre-Operation Check and After-Operation Maintenance .– Check fuel level, fill if necessary – Check the coolant level and add coolant if necessary (engine should be cold). – Check brake fluid level, add if necessary. –...

  • Page 54: Entrance To The Xtv Cab From Front

    Entering and Exiting the XTV Cab 1 - Front windshield 2 - Front door/ladder 3 - Tire tread 4 - Side door/step 5 - Side window/door 6 - Emergency hatch To Enter the XTV Cab from the Front – Push button and lift front window. –...

  • Page 55: Emergency Exit From The Cab

    Emergency Exit from the XTV Cab In an emergency, you can exit the cab through the main door, side door or emergency hatch. To open the emergency exit hatch, turn the hatch handles to unlock the hatch. Then lift the hatch window open until it rests back on the vehicle roof.

  • Page 56: General Driving

    General Driving To operate the XTV, once the engine has been started and allowed to warm up: – Ensure driver and passenger seat belts are fastened and cargo is secured. NOTE: The engine must be at idle before attempting to shift the transmission. –...

  • Page 57: Fueling The Xtv

    Fueling the XTV To add fuel to the XTV: – Remove fuel cap. – SLOWLY add desired amount of diesel fuel - DO NOT OVERFILL. – Replace fuel cap and tighten securely. WARNING – NEVER fill the fuel tank while the engine is running or hot. –...

  • Page 58: Engine Start

    Engine Start – Engage parking brake lever. – Place gearshift lever in the “N” neutral position. – Turn “ON” battery disconnect switch. – Insert the key into the ignition switch and turn it to the “ON” position. – If the the glow plug lamp is illuminated on the display, allow adequate time for the glow plug lamp to go out.

  • Page 59: Cold Weather Starting

    Cold Weather Starting If the ambient temperature is below 23°F (-5°C) and the engine is very cold, start in the following manner: – Engage parking brake lever. – Place gearshift lever in “N” neutral position. – Turn “ON” battery disconnect switch. –...

  • Page 60: Reverse Engine Operation

    Reverse Engine Operation (Crankshaft rotation in the opposite direction) Reversed engine operation during crankshaft rotation in the opposite direction must be stopped immediately since engine oil circulation is cut quickly, leading to engine failure. CAUTION Signs of reversed engine operation: –...

  • Page 61: General Cases Of Xtv Operation

    General Cases of XTV Operation Proper XTV operation is one of the most important factors for increasing its service life and trouble-free operation. XTV operation is possible only after engine is warmed up and display is checked for any error codes, proper engine oil pressure, proper engine RPM, adequate fuel level, etc.

  • Page 62: Driving On Sandy Areas, Loose Soil And Snow

    Driving on Sandy Areas, Loose Soil and Snow WARNING DO NOT OVERLOAD THE VEHICLE. SEE SPECIFICATIONS SECTION. SERIOUS INJURY OR DEATH MAY RESULT. Depending on soil or snow cover density, it is necessary to select the appropriate tire pressure. Drive should be the gear used for operation in these conditions. It is necessary to keep a smooth moving XTV, avoiding jerks and stops.

  • Page 63: Driving On Waterlogged Terrain

    Driving on Waterlogged Terrain XTV is able to overcome all kinds of waterlogged areas. Operating skills are required. It is recommended to overcome the waterlogged terrains using the shortest ways possible. The corresponding tire pressure must be observed. Passing Water Barriers WARNING DO NOT OVERLOAD THE VEHICLE.
  • Page 64 – Avoid getting the wheels on only one side onto the ice surface as water could enter over the opposite side of the vehicle. – Avoid turning as the Argo is climbing out of the water to avoid vehicle tip-over. – Be wary of currents which may affect the vehicle operation.

  • Page 65: Section 5 - Technical Maintenance Types And Frequency

    If, at any time, abnormal noises, vibrations, or improper functioning of any component of this vehicle is detected, DO NOT OPERATE THE VEHICLE. Take the vehicle to an authorized ARGO Commercial dealer for inspection, adjustment or repair. If the owner/operator does not feel qualified to perform any of these maintenance procedures or checks, take the vehicle to an authorized ARGO dealer for professional service.
  • Page 66 Technical Maintenance Types and Frequency (continued) Engine Hours or Frequency Maintenance Procedure Daily 1000 1500 1750 2000 2250 2500 2750 3000 Check main braking √ √ system and parking brake Check engine and √ √ transmission performance Check transmission √ √...
  • Page 67 The intervals shown on the schedule are based on average operating conditions. Vehicles which are subjected to severe use and wet or dusty conditions will require more frequent servicing. Use only Argo replacement parts to ensure safe operation of the vehicle and to comply with the warranty coverage.

  • Page 68: Measurements For Adjustments And Control

    Measurements for Adjustments and Control Parameters Measurement limits Engine idle RPM 1100 rpm Oil pressure in the engine lubrication system at 11.6 psi (0.8 kPa) idle Oil pressure in the engine lubrication system at 43.5 psi (3.0 kPa) maximum RPM Coolant temperature under normal operating 180°F-207°F (82°С-97°C) conditions...

  • Page 69: Filling Volumes

    Filling Volumes, Petroleum Products and Lubricants Junction Point Quantity (L, gal.) Filling Name Name (Number of Points) Fuel Diesel fuel №2-D Fuel Tank (ASTM D975) EURO 26.5 gal (100 L) (EN 590:2004) Engine Oils Engine oil of API quality degree: not less than CJ.

  • Page 70: Engine Oil Level Check

    Engine Oil Level Check WARNING To avoid personal injury, be sure to stop the engine and engage parking brake before checking oil level and/or changing engine oil. – Park the vehicle to a flat surface. – Start the engine and run until it reaches normal operating temperature. –...

  • Page 71: Engine Oil Change

    – Turn the ignition switch to the “RUN” position to allow the display to fully power up. – Start the engine, check to ensure the oil pressure gauge indicator is within the operating range. CAUTION If oil pressure is NOT within operating range within 10 seconds, turn the engine off. Contact your Argo dealer.
  • Page 72 Engine Oil Change – Remove the engine oil dipstick. – Clean any oil from the dipstick and reinsert. NOTE: If the dipstick doesn’t slide in, rotate it 180°. – Remove the engine oil dipstick and ensure engine oil is between the upper and lower operating range dimples.

  • Page 73: Checking / Changing Transmission Oil

    – If the fluid is below the lower operating range hash mark, remove the transmission breather vent at the top/front of the transmission. – Add the required amount of 75W-90 Argo Transmission Oil to bring the fluid within the upper and lower operating range hash marks.
  • Page 74 This may take several minutes. – Remove the transmission breather vent at the top/front of the transmission. – Add the appropriate type and amount of 75W-90 Argo Transmission Oil to bring the fluid within the upper and lower operating range hash marks.

  • Page 75: Cvt Belt And Clutch Removal/Cleaning

    CVT Belt and Clutch Removal/Cleaning WARNING Ensure XTV is parked on a flat level surface, transmission in “N” neutral gear with parking brake engaged and wheels chocked. CVT Belt and Clutch Removal/Cleaning: – Remove fasteners securing the engine compartment close off panel and remove the panel.

  • Page 76: Chain Case Fluid Check

    Chain Case Fluid Check WARNING Ensure XTV is parked on a flat level surface, transmission in the “N” (Neutral) position with parking brake engaged and wheels chocked. – Remove the six (6) fasteners securing the rear floor panel in the rear of the cab. –...

  • Page 77: Chain Case Fluid Drain / Fill

    Chain Case Fluid Drain / Fill Ensure XTV is parked on a flat level surface, transmission in the “N” (Neutral) position with parking brake engaged and wheels chocked. Drain: – Raise and block the front corners of the chassis or hull. –...

  • Page 78: Fuel Filter Maintenance

    Fuel Filter Maintenance Ensure XTV is parked on a flat level surface, transmission in “N” neutral gear with parking brake engaged and wheels chocked. Remove the fasteners securing the Engine Main Access Panel (entire main panel) and remove the panel. WARNING To prevent personal injury, use CAUTION as surfaces may be hot and may cause serious injury.

  • Page 79: Secondary Fuel Filter

    Fuel Filter Maintenance Secondary Fuel Filter Replacement: – Disconnect the fuel heater connector from the secondary fuel filter housing. – Disconnect the fuel temp sensor connector from the secondary fuel filter housing. – Loosen the secondary fuel filter. Clean any spilled fuel from the engine compartment.

  • Page 80: Coolant Check / Fill

    Coolant Check/Refill WARNING To prevent personal injury, DO NOT remove the radiator cap or expansion tank cap while coolant is hot. – Remove the four (4) thumb screws securing the engine radiator access panel located in the rear interior section of the cab. –...

  • Page 81: Air Filter Maintenance

    Air Filter Maintenance WARNING Ensure XTV is parked on a flat level surface, transmission in the “N” Neutral position with parking brake engaged and wheels chocked. – Remove the four (4) thumb screws securing the Engine Mid Access Panel and remove the panel.

  • Page 82: Brake Fluid Maintenance

    Brake Fluid Maintenance Remove the front (drivers side) floorboard by rotating the three (3) quarter-turn fasteners. – Clean any debris from the brake master cylinder cap and surrounding area. – Remove the cap. – Ensure the brake fluid level is within 1/2” from the top of the master cylinder reservoir.

  • Page 83: Wheels And Tires - General Provisions

    Wheels and Tires - General Provisions Mounting tires on the drive wheel can be performed by a qualified installer in compliance with generally accepted mounting safety regulations. Only serviceable, clean and dry tires and rims can be mounted. Before installation, tires stored at temperatures below 32°F (0ºC) shall be kept at temperatures above 32°F (0ºC) for 3-5 hours.

  • Page 84: Dismounting Wheel Assembly

    Dismounting Wheel Assembly – Raise vehicle using suitable lift so desired tire is off the ground. – Deflate tires – Remove contents from wheel canister (if installed). – Remove wheel canister (if installed). – Remove wheel lug nuts. – Remove wheel/tire assembly from drive hub. (Assistance may be required). NOTE: Account for large O-ring that seals rim to the hub.

  • Page 85: Tire Maintenance

    – Carefully inspect tires and rims. Remove any foreign objects (stones, nails, etc.). – It is recommended to have tire repairs performed by an authorized ARGO dealer. – Ensure all bolts attaching the beadlocks are present and ensure they are properly torqued.

  • Page 86: Xtv Storage

    XTV Storage CLEANING THE VEHICLE Wash the vehicle body with a suitable outer body automotive detergent and rinse with water. Flush dirt out of the lower body by using a high pressure sprayer or garden hose after removing the drain plugs. Ensure the hold drain is dry and plugs are replaced.

  • Page 87: Steering Controller Dtcs

    SECTION 6 WARNING IMMEDIATELY STOP OPERATION IF A FAULT IS DISPLAYED. CONTACT YOUR ARGO DEALER FOR MORE INFORMATION OR POSSIBLE SERVICE. Fault Codes - Steering Controller DTCs RESET FAULT DESCRIPTION POSSIBLE CAUSES PROCEDURE Controller The steering motor Short circuit of the...

  • Page 88: Reset Procedure

    Fault Codes - Steering Controller DTCs RESET FAULT DESCRIPTION POSSIBLE CAUSES PROCEDURE The steering The steering Turn the vehicle Controller Severe motor controller motor controller ignition off, allow Overtemperature temperature has temperature must the system to power exceed the allowable be below 203 F down for 60 seconds.
  • Page 89 Fault Codes - Steering Controller DTCs RESET FAULT DESCRIPTION POSSIBLE CAUSES PROCEDURE The steering motor Internal error in Turn the vehicle Motor Not Stopped controller has steering motor ignition off, allow detected the steering controller. The the system to power motor is still in motion steering motor down for 60 seconds.
  • Page 90 Fault Codes - Steering Controller DTCs RESET FAULT DESCRIPTION POSSIBLE CAUSES PROCEDURE The steering The steering Turn the vehicle Controller motor controller motor controller ignition off, allow Overtemperature temperature temperature must the system to power Cutback has exceed the be below 185 F down for 60 seconds.
  • Page 91 Fault Codes - Steering Controller DTCs RESET FAULT DESCRIPTION POSSIBLE CAUSES PROCEDURE Motor Temp Hot The steering motor The steering motor Turn the vehicle Cutback temperature has temperature must be ignition off, allow exceed the allowable below 248 F (120 C) the system to power temperature of 284 F for normal operation.
  • Page 92 Fault Codes - Steering Controller DTCs RESET FAULT DESCRIPTION POSSIBLE CAUSES PROCEDURE Pump Driver The Pump driver Open or short on Turn the vehicle circuit in the steering the driver load, dirty ignition off, allow motor controller has connector pins at the system to power detected an over/ controller, loose...
  • Page 93 Fault Codes - Steering Controller DTCs RESET FAULT DESCRIPTION POSSIBLE CAUSES PROCEDURE Motor Open The steering motor Loose connection Turn the vehicle controller has of the motor phase ignition off, allow detected an open wires from the the system to power circuit in one of the controller to the down for 60 seconds.
  • Page 94 Fault Codes - Steering Controller DTCs RESET FAULT DESCRIPTION POSSIBLE CAUSES PROCEDURE Motor Setup Needed The steering motor Internal programming Turn the vehicle controller setup has is required, the ignition off, allow not been completed. controller must be the system to power When this code is replaced.
  • Page 95 Fault Codes - Steering Controller DTCs RESET FAULT DESCRIPTION POSSIBLE CAUSES PROCEDURE HPD Sequencing The steering motor Faulty wiring or Turn the vehicle controller detected an component in inputs ignition off, allow incorrect sequence to the steering the system to power of receiving signals controller of the down for 60 seconds.
  • Page 96 Fault Codes - Steering Controller DTCs RESET FAULT DESCRIPTION POSSIBLE CAUSES PROCEDURE Steering Sensor NO The steering motor Open or short circuit Turn the vehicle controller has not in the steering angle ignition off, allow received a message sensor circuit or the system to power from the steering sensor.
  • Page 97 Fault Codes - Steering Controller DTCs RESET FAULT DESCRIPTION POSSIBLE CAUSES PROCEDURE PDO Timeout The steering motor Chassis controller, Turn the vehicle controller has not steering sensor ignition off, allow received expected or wiring between the system to power CAN messages from the components down for 60 seconds.
  • Page 98 Fault Codes - Steering Controller DTCs RESET FAULT DESCRIPTION POSSIBLE CAUSES PROCEDURE PDO Mapping Error The steering motor Reset the steering Turn the vehicle controller has controller module, if ignition off, allow detected an internal the code does not the system to power error.

  • Page 99: Fan Controller Dtcs

    Fault Codes - Fan Controller DTCs RESET FAULT DESCRIPTION POSSIBLE CAUSES PROCEDURE Controller Over The fan controller Loose 54 volt battery Turn the vehicle Voltage supply voltage has cable connections, ignition off, allow exceeded the limit faulty 16 volt battery the system to power of 90 VDC.
  • Page 100 Fault Codes - Fan Controller DTCs RESET FAULT DESCRIPTION POSSIBLE CAUSES PROCEDURE Controller Under The fan controller Loose 54 volt battery Turn the vehicle Voltage supply voltage is cable connections, ignition off, allow under the required faulty 16 volt battery the system to power minimum of 13.5 or faulty 54 volt...
  • Page 101 Fault Codes - Fan Controller DTCs RESET FAULT DESCRIPTION POSSIBLE CAUSES PROCEDURE Instantaneous The fan controller Loose 54 volt battery Turn the vehicle Controller Over supply voltage has cable connections, ignition off, allow Voltage exceeded the limit faulty 16 volt battery the system to power of 90 VDC.
  • Page 102 Fault Codes - Fan Controller DTCs RESET FAULT DESCRIPTION POSSIBLE CAUSES PROCEDURE Hall Stall Internal fan motor Internal fan motor Turn the vehicle fault. When this code fault, fan motor must ignition off, allow is active, the fan be replaced. the system to power controller will shut down for 60 seconds.

  • Page 103: Engine Dtcs

    Fault Codes - Engine DTCs CODE DESCRIPTION P0002 Maximum positive deviation of rail pressure exceeded P0003 Fuel Metering unit plausibility error in idle mode 1076 P0004 Fuel Metering unit plausibility error in overrun mode 1076 P000F Common rail pressure relief valve is open 5571 P0072 Environment Temperature Sensor Signal Low...
  • Page 104 Fault Codes - Engine DTCs CODE DESCRIPTION P018C Fuel filter pressure low fault 1382 P018D Fuel filter pressure high fault 1382 Common rail pressure relief valve reached maximum allowed open P018F 5571 time P0192 Rail pressure sensor Low fault 5313 P0193 Rail pressure sensor High fault 5313...
  • Page 105 Fault Codes - Engine DTCs CODE DESCRIPTION P02E3 Throttle valve H-Bridge Driver Short circuit to battery 5419 P02E4 Throttle valve Position Open jammed fault P02E5 Throttle valve Position Closed jammed fault P02E7 Throttle valve Close Position Learning Drift Fault P02E8 Throttle valve Position Sensor Low Fault P02E9 Throttle valve Position Sensor High Fault...
  • Page 106 Fault Codes - Engine DTCs CODE DESCRIPTION P0545 Turbine inlet temperature sensor Low fault 2789 P0546 Turbine inlet temperature sensor High fault 2789 P055B Oil Pressure Warning Lamp Open circuit 5099 P055C Short circuit to ground error of oil pressure lamp 5099 P055D Oil Pressure Warning Lamp Short to Battery...
  • Page 107 Fault Codes - Engine DTCs CODE DESCRIPTION P0C17 EGR Close Position Learning Range Over Fault P0C18 EGR Close Position Learning Drift Fault for long time P0C19 EGR Close Position Learning Drift Fault for short time P1013 MoF(Monitoring of Function) Engine speed error 520797 P101A MoF(Monitoring of Function) Over Run error...
  • Page 108 Fault Codes - Engine DTCs CODE DESCRIPTION P12F6 NCD inducement Fault Level1 (Group 5 – Tampering) 520740 P12F7 NCD inducement Fault Level2 (Group 5 – Tampering) 520741 NCD inducement Fault Level3 Final inducement (Group 5 – P12F8 520742 Tampering) P12F9 NCD inducement Fault Warning (Group 5 –...
  • Page 109 Fault Codes - Engine DTCs CODE DESCRIPTION P1611 ECU Shut−off path test error 520700 P1612 ECU Wrong set response time error during shut off path test 520701 ECU Too many SPI (Serial Peripheral Interface Bus) errors during P1613 520702 shut off path test P1614 ECU Undervoltage error during Shut-off path test 520707...
  • Page 110 Fault Codes - Engine DTCs CODE DESCRIPTION P2043 DEF Temperature Sensor Open circuit 4365 P2046 DEF Temperature Sensor Short circuit 4365 P2047 DEF dosing valve actuator Short circuit to battery Fault 3361 P2048 DEF dosing valve actuator Short circuit to ground Fault 3361 P2049 DEF dosing valve actuator Open Circuit Fault...
  • Page 111 Fault Codes - Engine DTCs CODE DESCRIPTION DEF Supply module heater relay output Short circuit to battery P20BC 7416 Fault P20BD DEF Pressure line heater relay output Open circuit Fault 5491 P20BE DEF Pressure line heater feedback plausibility Fault 5491 P20BF DEF Pressure line heater relay output Short circuit to ground Fault 5491 P20C0...
  • Page 112 Fault Codes - Engine DTCs CODE DESCRIPTION P2203 NOx sensor Open circuit fault (Upstream NOx sensor) 3224 P2215 NOx sensor Short circuit fault (Downstream NOx sensor) 3234 P2216 NOx sensor Open circuit fault (Downstream NOx sensor) 3234 DEF Pressure line heater circuit Open circuit or Short circuit to P221C 4354 ground Fault...
  • Page 113 Fault Codes - Engine DTCs CODE DESCRIPTION DPF regeneration failure (DPF regeneration is not performed well P246B 3715 during machine operation mode) P246C DPF differential pressure too high fault 5629 P24A3 DPF Soot mass too high status (> 120%) 4781 P2505 ECU over temperature for SCR Monitoring 1867...
  • Page 114 Fault Codes - Engine DTCs CODE DESCRIPTION P2671 ECU Sensor Supply (5V)2 Over voltage fault 3510 P2684 ECU Sensor Supply (5V)3 Short circuit to ground 3511 P2685 ECU Sensor Supply (5V)3 Under voltage fault 3511 P2686 ECU Sensor Supply (5V)3 Over voltage fault 3511 P268C Injector Code(IQA) Program Missing Fault (Cylinder#1)
  • Page 115 Fault Codes - Engine DTCs CODE DESCRIPTION Message Check Sum Error of CAN Receive Frame SMVCU U013C 65400 (Pedal & Engine speed demand from VCU) U01B7 (Status of regeneration initiate and inhibit switches) 57344 Timeout Error of CAN-Receive-Frame DPM9 (Multiple torque Map U01B8 65402 select switch)
  • Page 116 NOTES...

  • Page 117: Section 7 - Ratings

    SECTION 7 Ratings XTV ratings include product identification numbers (PIN) and numbers of its component parts, the body and the engine. 1 - XTV PIN plate is located below the Battery Disconnect Switch on the drivers side of the vehicle. 2 - Product identification number (PIN) is engraved on the passenger side frame tube in the cab under the passenger side floorboard.
  • Page 118 NOTES...

  • Page 119: Section 8 - Warranty

    Ontario Drive & Gear Limited (hereinafter “ARGO”) extends a limited warranty on each new ARGO XTV and on each genuine ARGO part and accessory sold by an authorized ARGO dealer. The limited warranty on an ARGO XTV is provided to the original retail purchaser;...

  • Page 120: Warranty Procedure/Owner Responsibility

    At the time of sale, a Training Certificate (if applicable) or an Owner Registration form is to be completed by the selling dealer and consumer. The receipt of the form by ARGO is a condition precedent to warranty coverage. It is the selling dealer’s responsibility to retain and/or submit appropriate electronic registration to initiate warranty coverage.

  • Page 121: Epa Emission Warranty

    If the part fails during the period of warranty coverage, the part will be repaired or replaced by ARGO. Any such part repaired or replaced under warranty will be warranted for the remainder of the period.
  • Page 122 U.S. EPA & CARB EVAPORATIVE EMISSIONS WARRANTED PARTS The repair or replacement of any warranted part otherwise eligible for warranty coverage may be excluded from such warranty coverage if ARGO demonstrates that the XTV has been abused, neglected, or improperly maintained, and that such abuse, neglect, or improper maintenance was the direct cause of the need for repair or replacement of the part.

  • Page 123: Customer Information/Customer Checklist

    Customer Information / Customer Checklist Customer Information Name Address City, State, Zip Code Phone Number E-MAIL Customer Checklist Initial Date Visual Inspection Received Service Instructions Shown All Engine Controls Warranty Fully Explained Received Owner’s / Engine Manual Dealer Demonstrated All Controls Received Keys I have reviewed and understand the warranty policy...

  • Page 124: Pre-Ride Inspection

    Pre-Ride Inspection ITEM INSPECTION PROCEDURE ACTION Engine Oil Level Add oil if necessary. DO NOT Refer to operator’s or engine manual. overfill. Replace filler cap securely. Fuel Level Add fuel (Diesel) if necessary. Refer to operator’s or engine DO NOT mix oil with diesel. manual.
  • Page 125 ARGO RETAILER - Please complete this page at the time of sale to the new owner so your customer has all pertinent information that may be required. ARGO MODEL __________________________________________________ ARGO SERIAL NO._______________________________________________ ENGINE SERIAL NO. _____________________________________________ TRANSMISSION SERIAL NO. ______________________________________...
